Torque Specifications
| Description | Part Number | Torque |
|---|
| CMP sensor bolt - 3.5L | W503275 | 10 Nm (89 lb-in) |
| CMP sensor bolt - 2.0L GTDI | W701219 | 10 Nm (89 lb-in) |
| CMS - 3.5L | 9G444 | REFER to Catalyst Monitor Sensor - 3.5L Ti-VCT |
| CMS - 2.0L GTDI | 9G444 | REFER to Catalyst Monitor Sensor - 2.0L GTDI |
| CKP sensor bolt - 3.5L | W712315 | 10 Nm (89 lb-in) |
| CKP sensor bolts - 2.0L GTDI | W701219 | REFER to Crankshaft Position (CKP) Sensor - 2.0L GTDI |
| CKP sensor heat shield bolt - 3.5L | W701669 | 10 Nm (89 lb-in) |
| CKP sensor heat shield nut - 3.5L | W701542 | 10 Nm (89 lb-in) |
| CHT sensor - 3.5L | 6G004 | 10 Nm (89 lb-in) |
| CHT sensor - 2.0L GTDI | 6K004 | 4 Nm (35 lb-in) |
| Engine plug bolt - 2.0L GTDI | W700115 | 20 Nm (177 lb-in) |
| FRP sensor - 2.0L GTDI | 9F972 | REFER to Fuel Rail Pressure (FRP) Sensor - 2.0L GTDI |
| HO2S sensor - 3.5L | 9F472 | REFER to Heated Oxygen Sensor (HO2S) - 3.5L Ti-VCT |
| HO2S sensor - 2.0L GTDI | 9F472 | REFER to Heated Oxygen Sensor (HO2S) - 2.0L GTDI |
| KS sensor bolts - 3.5L | W704749 | 20 Nm (177 lb-in) |
| KS sensor bolts - 2.0L GTDI | W500310 | 20 Nm (177 lb-in) |
| MAF sensor screws - 3.5L | W709287 | 2 Nm (18 lb-in) |
| MAF sensor screws - 2.0L GTDI | W711655 | 2 Nm (18 lb-in) |
| MAPT sensor bolt - 2.0L GTDI | W506976 | 8 Nm (71 lb-in) |
| MAP sensor bolt - 2.0L GTDI | 9F479 | 6 Nm (53 lb-in) |
| PCM nuts - 3.5L | W707137 | 8 Nm (71 lb-in) |
| PCM bracket bolts - 2.0L GTDI | W713759 | 8 Nm (71 lb-in) |
| PCM bracket nuts - 2.0L GTDI | W707137 | 8 Nm (71 lb-in) |
| RH halfshaft bracket bolts- 2.0L GTDI | | 25 Nm (18 lb-ft) |
| RH halfshaft bracket nuts - 2.0L GTDI | W701731 | 25 Nm (18 lb-ft) |
| VCT oil control solenoid bolt - 3.5L | W500215 | REFER to Variable Camshaft Timing (VCT) Oil Control Solenoid - 3.5L Ti-VCT |
| VCT oil control solenoid bolt - 2.0L GTDI | W500211 | REFER to Variable Camshaft Timing (VCT) Oil Control Solenoid - 2.0L GTDI |
Scheme 1
Scheme 1: PCM Location - 2.0L And 3.5L
| Item | Service Part Number | Description |
|---|
| 1 | 12A650 | PCM |
Scheme 2
Scheme 2: Front Engine Sensor Locations - 2.0L
| Item | Service Part Number | Description |
|---|
| 1 | 12K073 | Exhaust CMP sensor |
| 2 | 12K073 | Intake CMP sensor |
| 3 | 12B579 | MAF sensor |
| 4 | 9F479 | MAPT sensor |
| 5 | 12A699 | LH KS |
| 6 | 9F479 | MAP sensor |
| 7 | 9F972 | FRP sensor |
| 8 | 12A699 | RH KS |
| 9 | 6M280 | Intake VCT oil control solenoid |
| 10 | 6M280 | Exhaust VCT oil control solenoid |
Scheme 3
Scheme 3: Rear Engine Sensor Locations - 2.0L
| Item | Service Part Number | Description |
|---|
| 1 | 6K004 | CHT sensor |
| 2 | 6C315 | CKP sensor |
| 3 | 9G444 | CMS |
| 4 | 9F472 | HO2S |
| 5 | 12A648 | ECT sensor |
Scheme 4
Scheme 4: Sensor Locations - 3.5L
| Item | Service Part Number | Description |
|---|
| 1 | 6M280 | VCT oil control solenoids |
| 2 | 6G004 | CHT sensor |
| 3 | 6B288 | CMP sensor |
| 4 | 12A699 | KS |
| 5 | 12B579 | MAF sensor |
| 6 | 6C315 | CKP sensor |
| 7 | 9G444 | CMS |
| 8 | 9F472 | HO2S |
