Parking Aid System - Active Park Assist: Removal & Installation Ford Explorer V

Collision/avoidance 3 illustrations ~116 words

Installation

  1. After installing the sensor(s), use the scan tool to verify that the active park assist sensor PIDs responding correctly. Carry out the Azimuth System check. For more information, REFER to «Azimuth System Check»(ref-517588-S11756959462012121200000) . If the parking aid sensor does not respond correctly. REFER to «DTC AND SYMPTOM CHART(S)»(ref-517588-S29637723912012121200000) for the Active Park Assist system in the Diagnosis and Testing portion of this information.
  2. To install, reverse the removal procedure.

Scheme 21

Scheme 21: Exploded View
Scheme 21: Exploded View
ItemService Part NumberDescription
114401Active park assist switch electrical connector
213D730Active park assist switch
37804338Lower LH instrument panel trim panel
4W705289Lower LH instrument panel trim panel clip

Scheme 22

Scheme 22: Removal
Scheme 22: Removal

Scheme 23

Scheme 23
Scheme 23
  1. Remove the lower LH instrument panel trim panel. Disconnect the 2 electrical connectors.
  2. Release the retainers and remove the active park assist switch.
  1. To install, reverse the removal procedure.
