Overview
The active park assist system is a supplementary parking aid that assists the operator in detecting an available parallel parking space and automatically steering the vehicle into the space while the operator controls the accelerator, gearshift and brakes.
The system visually and/or audibly instructs the operator to park the vehicle through messages in the centerstack infotainment display and warning chimes.
Scheme 2
Normal Operation and Fault Conditions
REFER to Active Park Assist Switch .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B129C:14 | Left Front Side Sensor: Circuit Short To Ground Or Open | A continuous and on-demand DTC that sets when any of the left front active park assist sensor circuits are open or the sensor signal line is shorted to ground. |
| B129D:14 | Right Front Side Sensor: Circuit Short To Ground Or Open | A continuous and on-demand DTC that sets when any of the right front active park assist sensor circuits are open or the sensor signal line is shorted to ground. |
DTC FAULT TRIGGER CONDITIONS
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B129C:12 | Left Front Side Sensor: Circuit Short To Battery | A continuous and on-demand DTC that sets when the left active park assist sensor signal line is shorted to battery voltage. |
| B129D:12 | Right Front Side Sensor: Circuit Short To Battery | A continuous and on-demand DTC that sets when the right active park assist sensor signal circuit is shorted to battery voltage. |
DTC FAULT TRIGGER CONDITIONS
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B129C:96 | Left Front Side Sensor: Component Internal Failure | A continuous and on-demand DTC that sets when the left front active park assist sensor has internally failed or has an incorrect attenuation time. |
| B129D:96 | Right Front Side Sensor: Component Internal Failure | A continuous and on-demand DTC that sets when the right front active park assist sensor has internally failed or has an incorrect attenuation time. |
DTC FAULT TRIGGER CONDITIONS
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1303:11 | Park Assist Switch: Circuit Short To Ground | Sets when the active park assist switch signal circuit is shorted to ground, the normally open switch is stuck closed or the switch is pressed and held for more than 10 seconds. |
DTC FAULT TRIGGER CONDITIONS
REFER to Active Park Assist System .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| U0100:00 | Lost Communication With PCM : No Sub-Type Information | Sets in the PAM if data messages received from the PCM over the HS-CAN are missing after the active park assist system is activated. |
DTC FAULT TRIGGER CONDITIONS
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| U0101:00 | Lost Communication With TCM : No Sub-Type Information | Sets in the PAM if data messages received from the PCM over the HS-CAN are missing after the active park assist system is activated. |
DTC FAULT TRIGGER CONDITIONS
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| U0121:00 | Lost Communication With ABS Control Module: No Sub-Type Information | Sets in the PAM if data messages received from the ABS module over the HS-CAN are missing after the active park assist system is activated. |
DTC FAULT TRIGGER CONDITIONS
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| U0131:00 | Lost Communication With PSCM : No Sub-Type Information | Sets in the PAM if data messages received from the PSCM over the HS-CAN are missing after the active park assist system is activated. |
DTC FAULT TRIGGER CONDITIONS
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| U0155:00 | Lost Communication With IPC : No Sub-Type Information | Sets in the PAM if data messages received from the IPC over the HS-CAN are missing after the active park assist system is activated. |
DTC FAULT TRIGGER CONDITIONS
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| U0212:00 | Lost Communication With SCCM : No Sub-Type Information | Sets in the PAM if data messages received from the SCCM over the HS-CAN are missing after the active park assist system is activated. |
DTC FAULT TRIGGER CONDITIONS
