REFRIGERANT OIL & REFRIGERANT CAPACITY SPECIFICATIONS
Note. DO NOT exceed A/C system refrigerant oil capacity when servicing system.
| Application | (1) Oil/Ounces | Refrigerant/Ounces |
|---|
| "E" Van Series |
| With Rear Unit | 13.0 | 64.0 |
| Without Rear Unit | 9.0 | 44.0 |
| Expedition & Navigator | (2) | (2) |
| Explorer & Mountaineer | 7.0 | 30.0 |
| F150/F250 Pickup Series | 9.0 | 32.0 |
| F250HD/F350 Pickup Series |
| Ford FS-10 Compressor |
| With Rear Unit | 10.0 | (3) |
| Without Rear Unit | 7.0 | (3) |
| Sanden SD-7H15 Compressor | 10.0 | (3) |
| Ranger | 7.0 | 30.0 |
| Villager |
| With Rear Unit | 10.0 | 53.0 |
| Without Rear Unit | 7.0 | 32.0 |
| Windstar |
| With Rear Unit | 13.0 | 56.0 |
| Without Rear Unit | 9.0 | 44.0 |
| (1) Total system capacity, unless otherwise noted. (2) Refrigerant oil and refrigerant capacity not available at time of publication. Refer to underhood A/C specification label in engine compartment. (3) Manufacturer specifies maximum refrigerant capacity as 38.0 ounces. Refer to underhood A/C specification label in engine compartment for specific application. |
| (1) | Total system capacity, unless otherwise noted. |
| (2) | Refrigerant oil and refrigerant capacity not available at time of publication. Refer to underhood A/C specification label in engine compartment. |
| (3) | Manufacturer specifies maximum refrigerant capacity as 38.0 ounces. Refer to underhood A/C specification label in engine compartment for specific application. |
REFRIGERANT OIL & R-134a REFRIGERANT CAPACITY
Underhood A/C Specification Labels
Most R-134a based systems will be identified through the use of underhood labels with R-134a refrigerant clearly printed on labels. (Scheme 2) The underhood label used on Ford Motor Co. vehicles is Yellow. (Scheme 3) Most manufacturers will identify refrigerant type with labels affixed to compressor. Before servicing an A/C system, always determine which refrigerant is being used.
Scheme 2
Scheme 2: Underhood A/C Specification Labels
Scheme 3
