SERVICE VALVE LOCATIONS
For service valve locations, see SERVICE VALVE LOCATIONS table.
| Vehicle | High | Low |
|---|
| "E" Series | (2) | (3) |
| Explorer, Mountaineer & Ranger | (2) | (4) |
| F150/250, Expedition & Navigator | (2) | (4) |
| Villager | (6) | (1) |
| Windstar | (5) | (4) |
| (1) On low pressure line, near accumulator. (2) On high pressure line, between compressor and condenser, near front of engine compartment. (3) On low pressure line from accumulator, near windshield washer reservoir. (4) On accumulator/receiver-drier. (5) On high pressure line, between compressor and condenser, near accumulator. (Scheme 10) (6) On high pressure line extension from compressor. |
| (1) | On low pressure line, near accumulator. |
| (2) | On high pressure line, between compressor and condenser, near front of engine compartment. |
| (3) | On low pressure line from accumulator, near windshield washer reservoir. |
| (4) | On accumulator/receiver-drier. |
| (5) | On high pressure line, between compressor and condenser, near accumulator. (Scheme 10) |
| (6) | On high pressure line extension from compressor. |
Scheme 10
