PCV System
The PCV system
- uses intake manifold vacuum to ventilate blow-by gases from the crankcase.
- returns the gases to the intake manifold for combustion.
The PCV valve
- varies the amount of blow-by gases returned to the intake manifold based on available engine vacuum.
- is integral to the LH valve cover.
Scheme 19
| Item | Part Number | Description |
|---|---|---|
| 1 | 6582 | RH valve cover |
| 2 | 9A589 | Air Cleaner (ACL) outlet pipe-to-Throttle Body (TB) adapter |
| 3 | Four-Wheel Drive (4WD) vacuum solenoid assembly | |
| 4 | 6A505 | LH valve cover |
| 5 | 9F624 | PCV fitting |
| 6 | Brake booster | |
| 7 | 9Y451 | Intake manifold |
| 8 | 9C915 | Evaporative Emission (EVAP) canister purge valve |
| 9 | 9D653 | EVAP canister assembly |
| 10 | 9F675 | EVAP canister vent solenoid and dust separator assembly |
| 11 | 9K007 | Fuel tank |
| 12 | Fuel vent valve |
PART NUMBER REFERENCE
Refer to the INTRODUCTION - GASOLINE MODELS .
Scheme 20
| Item | Part Number | Description |
|---|---|---|
| 1 | Throttle Body (TB) adapter-to-air intake resonator assembly clamp | |
| 2 | W505427 | Air intake resonator assembly bolt |
| 3 | 9F763 | Air intake resonator assembly |
| 4 | 6K817 | PCV tube |
| 5 | W701724 | PCV fitting bolt (2 required) |
| 6 | 9F624 | PCV fitting |
PART NUMBER REFERENCE
