Starting System: Other Ford Escape III

Remote Start

The remote start feature allows the operator to remotely start the engine from up to 100 meters (328 feet) away and is activated using the IKT. Once started, the engine runs for 10 minutes. The run time can be extended by the operator.

Network Message Chart

NETWORK INPUT MESSAGES PCM

Note. This vehicle is equipped with PATS that disables the engine from cranking and starting if an unprogrammed PATS key is used or an invalid PCM ID is received. PATS is controlled by the BCM. If there is a PATS concern that disables the engine, the IPC message center displays "STARTING SYSTEM FAULT". For additional information, refer to PATS, ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS), WITHOUT INTELLIGENT ACCESS (IA) .

When the ignition is turned to START, the PCM receives the following inputs

1. Voltage signal on the crank detect circuit from the ignition switch
2. PATS is enabled message from the BCM
3. Correct transaxle PARK or NEUTRAL input from the automatic transmission

When the PCM receives the correct inputs, voltage and ground is supplied to the starter relay coil. The starter relay coil is energized causing the relay contacts to close providing voltage to the starter solenoid, allowing the starter motor to crank and start the engine. The PCM disengages the starter once an engine RPM threshold is reached, a set crank time is exceeded or the ignition is turned OFF.

The factory remote start system (if equipped) does not operate if the ignition is in the RUN/START position or the hood is not closed.

The remote start system can be enabled or disabled by the customer. When enabled, the customer can set the engine run time for 5, 10 or 15 minutes. For information on setting the engine run time, refer to the Owner's Literature or INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .

When equipped with remote start, a remote start event is initiated when the IKT transmits a remote start request signal to the PATS transceiver, which sends a remote start request message to the BCM. The BCM sends a crank request message to the PCM. The factory equipped remote start system does not operate if the ignition is in the RUN/START position or the hood is not closed.

The remote start system allows the operator to start the engine from up to 100 meters (328 feet) away, by pressing a sequence of buttons on the IKT. The remote start system is activated by pressing the lock button on the IKT once to make sure the doors are locked, followed by 2 presses of the remote start button. The 3 button presses must occur within 3 seconds of each other. The BCM acknowledges the remote start request by flashing the exterior lights twice. Once started, the engine runs for 10 minutes (default run time is 10 minutes; the time can be programmed by the customer to 5, 10 or 15 minutes) and the parking lights remain illuminated until the cycle is complete. The remote start duration can also be extended by initiating remote start while the first timer is still running or by initiating a completely independent start cycle when the first has completed. No more than 2 remote start sequences can occur within a one hour period, unless the ignition is set to the RUN/START position between the remote start requests. During the remote start cycle the power windows are inhibited and the radio will not turn on automatically but may be turned on manually from inside the vehicle. If the remote start system fails to start the horn chirps twice.

To transition from remote start mode to drive mode, use a programmed IKT to switch the ignition to the RUN position. If a programmed IKT is not used, the engine shuts off.

To deactivate the remote start system, press the remote start button once. When deactivating the remote start system the parking lights turn off to give a visual indication that the engine and climate control features have turned off. It may be necessary to be closer to the vehicle to deactivate the remote start feature than it was to initiate it due to ground deflections and added noise from the engine running.

The remote start system conditions the cabin temperature during remote start based on the outside temperature. For information on cabin temperature conditioning during remote start, refer to CLIMATE CONTROL SYSTEM - ELECTRONIC MANUAL TEMPERATURE CONTROL (EMTC) or CLIMATE CONTROL SYSTEM - DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) .

BCM

The BCM is the gateway module, translating HS-CAN messages to the MS-CAN. This allows a message to be distributed throughout both networks.

Ignition Switch

The ignition switch is controlled by the ignition lock cylinder with a key. When the ignition lock cylinder is turned using the key, a mechanical connection positions the ignition switch to the selected position and allows the ignition switch to send voltage to specific components. The ignition switch sends voltage to the PCM during engine cranking.

IKT

The RKE system uses an IKT. The IKT incorporates both the PATS and RKE functions into a single device. The factory installed remote start (if equipped), is controlled by the IKT function and allows the engine to be started from outside the vehicle. The RKE functions control the door lock/unlock features.

PCM

The PCM receives input signals from sensors and other components (switches, relays). Based on this information, the PCM generates output signals to control various relays, solenoids and actuators, including the starter relay.

PATS Transceiver

The PATS transceiver is a receiving antenna that receives high frequency signals. When a remote start request is initiated from the IKT the PATS transceiver receives the signal and communicates that remote start request message to the BCM. For additional information, refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS), WITHOUT INTELLIGENT ACCESS (IA) .

TR Sensor

The TR sensor is located inside the transaxle and indicates gearshift position to the PCM. The PCM uses that information to enable the starting system to start the engine in PARK or NEUTRAL. For additional information, refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .

The remote start feature allows the operator to remotely start the engine from up to 100 meters (328 feet) away and is activated using the IKT. Once started, the engine runs for 10 minutes. The run time can be extended by the operator.

NETWORK INPUT MESSAGES BCM

NETWORK INPUT MESSAGES PCM

Note. This vehicle is equipped with PATS that disables the engine from cranking and starting if an unprogrammed PATS key is used or an invalid PCM ID is received. PATS is controlled by the BCM. If there is a PATS concern that disables the engine, the IPC message center displays "STARTING SYSTEM FAULT". For additional information, refer to PATS, ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS), WITH INTELLIGENT ACCESS (IA) .

The RFA module in conjunction with the BCM controls the ignition modes and in conjunction with the PCM controls the starting system.

During a start event, when the start/stop switch is pressed in combination with the brake pedal, the RFA module, PCM and BCM receive a request to start the engine.

The PCM recognizes the correct inputs from the BCM and TR sensor and provides voltage and ground to energize the starter relay coil and close the starter relay contacts. The starter relay contacts close, providing voltage to the starter solenoid, allowing the starter motor to crank the engine. The PCM disengages the starter motor once an engine RPM threshold is reached, a set crank time is exceeded or the start/stop button is pressed indicating an engine shutdown.

The factory remote start system (if equipped) does not operate if the ignition is in the RUN/START position or the hood is not closed.

The remote start system can be enabled or disabled by the customer. When enabled, the customer can set the engine run time for 5, 10 or 15 minutes. For information on setting the engine run time, refer to the Owner's Literature or INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES .

When equipped with remote start, a remote start event is initiated by pressing a sequence of buttons on the IA key. The factory equipped remote start system does not operate if the ignition is in the RUN/START position or the hood is not closed.

The remote start system allows the operator to start the engine from up to 100 meters (328 feet) away and is activated by pressing the lock button on the IA key once to make sure the doors are locked, followed by 2 presses of the remote start button. The 3 button presses must occur within 3 seconds of each other. The system acknowledges the start request by flashing the exterior lights twice.

Once started, the engine runs for 10 minutes (default run time is 10 minutes; the time can be programmed by the customer to 5, 10 or 15 minutes) and the parking lights remain illuminated until the cycle is complete. The remote start duration can also be extended by initiating remote start while the first timer is still running or by initiating a completely independent start cycle when the first cycle has completed. No more than 2 remote start sequences can occur within a one hour period, unless the ignition is set to the RUN/START position between the remote start requests. During the remote start cycle the power windows are inhibited and the radio will not turn on automatically but may be turned on manually from inside the vehicle. If the remote start system fails to start the horn will chirp twice.

To transition from remote start mode to drive mode, use a programmed IA key to transition to RUN. If a programmed IA key is not used, the engine shuts off.

To deactivate the remote start system, press the remote start button once. When deactivating the remote start system the parking lights turn off to give a visual indication that the engine and climate control features have turned off. It may be necessary to be closer to the vehicle to deactivate the remote start feature than it was to initiate it due to ground deflections and added noise from the engine running.

The remote start system conditions the cabin temperature during remote start based on the outside temperature. For information on cabin temperature conditioning during remote start, refer to CLIMATE CONTROL SYSTEM - ELECTRONIC MANUAL TEMPERATURE CONTROL (EMTC) or CLIMATE CONTROL SYSTEM - DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) .

The BCM is the gateway module, translating HS-CAN messages to the MS-CAN. This allows a message to be distributed throughout both networks.

IA key

The IA key incorporates both the PATS and the RKE transmitter functions in a single device. The IA key must be located inside the vehicle for engine starting. When the IA key is activated it sends out a frequency signal that is received by the RFR module. The IA key also contains a key blade that is used to enter the vehicle as a backup.

Start-Stop Switch

The start/stop switch is a momentary contact switch that is hardwired to the RFA module, BCM, and PCM. When the switch is pressed, it signals the RFA module, BCM and PCM there is a request to either switch the ignition on or start the engine. The start/stop switch is connected to both modules as a backup in case of a failure. If there is a circuit failure to either module from the start/stop switch, the modules communicate the start/stop switch request to each other over the MS-CAN.

RFA Module

The RFA module interprets radio frequency signals from the RFR module and IA key transmitters. The RFA module receives input signals from various modules and other components. Based on this information, the RFA module generates an output signal to control various components such as the door locks and the liftgate.

The PCM receives input signals from sensors and other components (switches, relays). Based on this information, the PCM generates output signals to control various relays, solenoids and actuators including the starter relay.

RFR

The RFR is a receiving antenna that receives high frequency signals. When a remote start request is initiated from the IA key the RFR receives the signal and communicates the remote start request message to the RFA module. The RFA module transmits the message via the MS-CAN to the BCM to initiate a remote start event.

The TR sensor is located inside the transaxle and indicates gearshift position to the PCM. The PCM uses that information to enable the starting system to start the engine in PARK or NEUTRAL. For additional information, refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 6F35 .

Possible Sources

1. Battery
2. Battery cables
3. Fuses
4. Wiring, terminals or connectors
5. Ignition switch
6. Starter motor
7. Starter motor bolts
8. Starter relay
9. BCM
10. PCM
11. TR sensor
12. PATS
13. IKT
14. High current BJB connections

Visual Inspection and Diagnostic Pre-checks

1. High current BJB fuse 2 (150A)
2. BJB fuse 13 (30A)
3. BCM fuse 78 (5A)

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. A1 CHECK THE BATTERY Check the battery condition and state of charge. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) . Is the battery OK? Yes : GO to A2. No : INSTALL a new battery. REFER to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
2. A2 CHECK FOR ANY MESSAGES IN THE MESSAGE CENTER Start the engine. Check the message center while holding the ignition key in the start position Is STARTING SYSTEM FAULT displayed in the message center? Yes : REFER to «ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS), WITHOUT INTELLIGENT ACCESS (IA)»(ref-569623) to diagnose the PATS concern. No : GO to A3.
3. A3 RETRIEVE DTCS Ignition ON. Enter the following diagnostic mode on the scan tool: Self-Test - BCM. Enter the following diagnostic mode on the scan tool: Self-Test - PCM. Were DTCs retrieved on-demand during self-test? Yes : For BCM DTCs, REFER to «BCM DTC Chart»(ref-569607-S05890081462013090600000) . For PCM DTCs, REFER to «PCM DTC Chart»(ref-569607-S40624295432013090600000) . No : GO to A4.
4. A4 CHECK THE STARTER RELAY CONTROL OPERATION NOTE: The following step uses a test light to simulate normal circuit loads. Use only the test light recommended in the «Special Tools»(ref-569607-S07460952992013090600000) table. To avoid connector terminal damage, use the Flex Probe Kit for the test light probe connection to the vehicle. Do not use the test light probe directly on any connector. Ignition OFF. Disconnect: Starter Relay. Connect a test light between: Positive Lead Negative Lead Pin Circuit Pin Circuit Starter Relay Socket-1 CDC12 (BU/WH) Starter Relay Socket-2 CDC12 (YE) Make sure the transmission is in PARK or NEUTRAL. While holding the key in the START position, observe the test light. Does the test light illuminate when the key is in the START position? Yes : GO to A5. No : GO to 12 .
5. A5 CHECK THE VOLTAGE TO THE STARTER RELAY Measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit Starter Relay Socket-3 SBB15 (WH/RD) - Ground Is the voltage greater than 11 volts? Yes : GO to A6. No : VERIFY BJB fuse 13 (30A) is OK. If OK, REPAIR the circuit for an open. If not OK, REFER to the «SYSTEM WIRING DIAGRAMS»(ref-541395) article to identify the possible causes of the circuit short.
6. A6 CHECK THE STARTER MOTOR OPERATION AT THE STARTER RELAY With the gear selector in PARK or NEUTRAL, momentarily connect a fused jumper wire between: Positive Lead Negative Lead Pin Circuit Pin Circuit Starter Relay Socket 3 SBB15 (WH/RD) Starter Relay Socket 5 CDC35 (BU/WH) Did the starter motor engage and the engine crank? Yes : INSTALL a new starter relay. No : GO to A7.
7. A7 CHECK THE BATTERY GROUND CABLE Measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit Battery Positive Post Battery Positive Post - Ground Is the voltage greater than 11 volts? Yes : GO to A8. No : CLEAN or INSTALL new battery cables as necessary. REFER to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
8. A8 CHECK THE STARTER MOTOR GROUND Measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit Battery Positive Post Battery Positive Post Starter Motor Case Starter Motor Case Is the voltage greater than 11 volts? Yes : GO to A9. No : CLEAN the starter motor mounting flange and make sure the starter motor is correctly mounted.
9. A9 CHECK THE VOLTAGE TO THE STARTER MOTOR Measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit C197A-1 ("B" terminal) SBF01 (RD) - Ground Is the voltage greater than 11 volts? Yes : GO to A10. No : CLEAN or INSTALL new battery cables as necessary. REFER to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
10. A10 CHECK THE STARTER MOTOR FOR CORRECT OPERATION With the gear selector in PARK or NEUTRAL, momentarily connect a fused jumper wire between: Positive Lead Negative Lead Pin Circuit Pin Circuit C197A-1 ("B" terminal) SBF01 (RD) C197B-1 ("S" terminal) CDC25 (BN/GN) Did the starter engage and the engine crank? Yes : GO to A11. No : INSTALL a new starter motor. REFER to «STARTER MOTOR - 1.6L GTDI»(ref-569607-S07569985962013072700000) , «STARTER MOTOR - 2.0L GTDI»(ref-569607-S15799749212013072700000) or «STARTER MOTOR - 2.5L»(ref-569607-S24143822182013072700000) .
11. A11 CHECK FOR START INPUT AT THE STARTER Connect: Starter Relay. Disconnect: Starter Solenoid C197B ("S" terminal). With the gear selector in PARK, while holding the key in the START position, measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit C197B-1 ("S" terminal) CDC25 (BN/GN) - Ground Is the voltage greater than 11 volts? Yes : CLEAN the starter solenoid ("S" terminal) and C197B. CHECK the wiring and the starter motor for a loose or intermittent connection. No : REPAIR the circuit for an open.
12. A12 CHECK THE PCM START CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Disconnect: PCM C1551B (1.6L GTDI) or PCM C1381B (2.0L GTDI) or C175B (2.5L). For 1.6L GTDI, measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C1551B-43 CDC12 (YE) - Ground C1551B-62 CDC12 (BU/WH) - Ground For 2.0L GTDI, measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C1381B-43 CDC12 (YE) - Ground C1381B-62 CDC54 (WH/GN) - Ground For 2.5L, measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C175B-7 CDC12 (YE) - Ground C175B-37 CDC54 (WH/GN) - Ground Are the resistances to ground greater than 10, 000 ohms? Yes : GO to A13. No : REPAIR the affected circuit for a short to ground.
13. A13 CHECK THE PCM START CIRCUITS FOR AN OPEN For 1.6L GTDI, measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C1551B-43 CDC12 (YE) Starter Relay Socket-2 CDC12 (YE) C1551B-62 CDC12 (BU/WH) Starter Relay Socket-1 CDC12 (BU/WH) For 2.0L GTDI, measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C1381B-43 CDC12 (YE) Starter Relay Socket-2 CDC12 (YE) C1381B-62 CDC54 (WH/GN) Starter Relay Socket-1 CDC12 (BU/WH) For 2.5L, measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C175B-7 CDC12 (YE) Starter Relay Socket-2 CDC12 (YE) C175B-37 CDC54 (WH/GN) Starter Relay Socket-1 CDC12 (BU/WH) Are the resistances less than 3 ohms? Yes : GO to A14. No : REPAIR the affected circuit for an open.
14. A14 CHECK THE START CIRCUIT FOR VOLTAGE AT THE PCM Ignition OFF. For 1.6L GTDI, while holding the key in the START position, measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit C1551B-47 CDC12 (BU/YE) - Ground For 2.0L GTDI, while holding the key in the START position, measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit C1381B-47 CDC35 (BU/WH) - Ground For 2.5L, while holding the key in the START position, measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit C175B-16 CDC35 (BU/WH) - Ground Is the voltage greater than 11 volts? Yes : GO to A16 . No : GO to A15.
15. A15 CHECK THE IGNITION SWITCH Carry out the IGNITION SWITCH COMPONENT TEST. Refer to the OEM WIRING DIAGRAM COMPONENT TESTING article. Did the ignition switch pass the component test? Yes : REPAIR circuit CDC12 (BU/YE)or CDC35 (BU/WH) for an open. No : INSTALL a new ignition switch. REFER to «STEERING COLUMN SWITCHES»(ref-569588) .
16. A16 CHECK FOR CORRECT PCM OPERATION Ignition OFF. Disconnect and inspect all PCM connectors. Repair: corrosion install new connector or terminals - clean module pins damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the PCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK OASIS for any applicable TSBs. If a TSB exists for this concern, DISCONTINUE this test and FOLLOW the TSB instructions. If no TSB address this concern, INSTALL a new PCM. Refer to «POWERTRAIN CONTROL MODULE (PCM)»(ref-569601-S18764170622013072700000) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

1. Battery
2. Battery cables
3. BCM
4. Fuses
5. High current BJB connections
6. Ignition switch
7. IKT
8. PATS
9. PCM
10. RFA module
11. Starter motor
12. Starter motor bolts
13. Starter relay
14. TR sensor
15. Wiring, terminals or connectors

1. Wiring, terminals or connectors
2. PCM
3. BCM

1. BCM
2. BCM fuse 78 (5A)
3. Ignition Switch (without IA)
4. PCM
5. Start/Stop switch (with IA)
6. Wiring, terminals or connectors

1. Wiring, terminals or connectors
2. Remote start feature not enabled
3. Passive Key
4. External antenna
5. Hood switch input
6. PCM

Component Tests

Always make the Fluke 77-IV Digital Multimeter connections at the component terminal rather than at the wiring end connector. Making a connection at the wiring end connector could result in false readings because the meter will not pick up a high resistance between the wiring connector and the component.
