Rear View Mirror (Without One-Touch Up): Removal & Installation Ford Escape III

Removal and Installation

Note. Removal steps in this procedure may contain installation details.

Scheme 1

Scheme 2

1. To install, tighten to 8 Nm (71 lb-in).
2. To install, reverse the removal procedure.

Scheme 3

1. Remove the exterior mirror glass. Refer to «EXTERIOR MIRROR»(ref-569645-S40119061802013072700000) .
2. NOTE: Use a flat-blade screwdriver and remove the exterior mirror motor from the 3 mounting clips. To install, tighten to 1.45 Nm (12.8 lb.in).
3. To install, reverse the removal procedure.

Scheme 4

Scheme 5

Scheme 6

1. WARNING: Place a shop towel between the hands and the exterior mirror glass for protection in case of glass breakage during mirror service. Failure to follow this instruction may result in serious personal injury.
2. If equipped.
3. If required.
4. To install, reverse the removal procedure. Rotate the exterior mirror glass in all directions after installation to make sure that all of the exterior mirror glass retaining clips are completely fastened.

Removal

Mirror Type 1

Note. The windshield must be at room temperature. Otherwise, damage to the windshield glass may occur.

Note. A video version of this procedure is available on-line.

Installation

Mirror Type 1

Note. A video version of this procedure is available on-line.
