Overview
The power mirrors allow the LH or RH exterior mirror glass to be positioned electronically. The position of the power mirror glass is controlled by the exterior mirror control switch. The LH or RH selection switch determines which exterior mirror glass is controlled.
Scheme 22
The exterior power mirrors are equipped with heated mirror glass. This feature heats the mirror glass to remove frost, snow, ice and condensation.
Scheme 23
The memory mirror feature allows the driver to recall or save the preferred positioning of the LH and RH exterior mirror glass.
Scheme 24
The interior rear view mirror has pivot points which allow the adjustment of the mirror up, down, left and right. The interior mirror may be equipped with either a manual dimming or auto-dimming feature to control the reflectance of the interior rear view mirror glass. The manual dimming feature is completely controlled by the driver. The auto-dimming mirror electronically changes the mirror glass to a lower reflectance state when bright lights (glare) reach the mirror from behind the vehicle during nighttime conditions.
Diagnostic Overview
Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to Diagnostic Methods in SERVICE INFORMATION for more information about these practices.
Normal Operation and Fault Conditions
Refer to REAR VIEW MIRRORS .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1302:11 | Mirror Motor Common: Circuit Short to Ground | This continuous and on-demand DTC sets if the DDM detects excessive current draw when voltage is applied to the common circuit. |
| B1302:15 | Mirror Motor Common: Circuit Short to Battery or Open | This continuous and on-demand DTC sets if the DDM detects a short to battery or open when voltage is applied to the common circuit. |
| B1C09:11 | Driver Left/Right Mirror Motor: Circuit Short to Ground | This continuous and on-demand DTC sets if the DDM detects a short to ground when voltage is applied to the horizontal mirror motor circuit. |
| B1C09:15 | Driver Left/Right Mirror Motor: Circuit Short to Battery or Open | This continuous and on-demand DTC sets if the DDM detects a short to battery or open when voltage is applied to the horizontal mirror motor circuit. |
| B1C10:11 | Driver Up/Down Mirror Motor: Circuit Short to Ground | This continuous and on-demand DTC sets if the DDM detects a short to ground when voltage is applied to the vertical motor circuit. |
| B1C10:15 | Driver Up/Down Mirror Motor: Circuit Short to Battery or Open. | This continuous and on-demand DTC sets if the DDM detects a short to battery or open when voltage is applied to the vertical motor circuit. |
DTC FAULT TRIGGER CONDITIONS
Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to Diagnostic Methods in SERVICE INFORMATION for more information about these practices.
Refer to REAR VIEW MIRRORS .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B1302:11 | Mirror Motor Common: Circuit Short to Ground | This continuous and on-demand DTC sets if the PDM detects excessive current draw when voltage is applied to the common circuit. |
| B1302:15 | Mirror Motor Common: Circuit Short to Battery or Open | This continuous and on-demand DTC sets if the PDM detects a short to battery or open when voltage is applied to the common circuit. |
| B1C11:11 | Passenger Left/Right Mirror Motor: Circuit Short to Ground | This continuous and on-demand DTC sets if the PDM detects a short to ground when voltage is applied to the horizontal mirror motor circuit. |
| B1C11:15 | Passenger Left/Right Mirror Motor: Circuit Short to Battery or Open | This continuous and on-demand DTC sets if the PDM detects a short to battery or open when voltage is applied to the horizontal mirror motor circuit. |
| B1C12:11 | Passenger Up/Down Mirror Motor: Circuit Short to Ground | This continuous and on-demand DTC sets if the PDM detects a short to ground when voltage is applied to the vertical motor circuit. |
| B1C12:15 | Passenger Up/Down Mirror Motor: Circuit Short to Battery or Open. | This continuous and on-demand DTC sets if the PDM detects a short to battery or open when voltage is applied to the vertical motor circuit. |
DTC FAULT TRIGGER CONDITIONS
Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to Diagnostic Methods in SERVICE INFORMATION for more information about these practices.
Refer to REAR VIEW MIRRORS .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B12BC:11 | Mirror Position Sensor Supply: Circuit Short to Ground | This continuous and on-demand DTC sets if the DDM detects excessive current draw on the mirror position sensor supply circuit. |
| B1302:11 | Mirror Motor Common: Circuit Short to Ground | This continuous and on-demand DTC sets if the DDM detects excessive current draw when voltage is applied to the common circuit. |
| B1302:15 | Mirror Motor Common: Circuit Short to Battery or Open | This continuous and on-demand DTC sets if the DDM detects a short to battery or open when voltage is applied to the common circuit. |
| B1378:11 | Mirror Horizontal Position Sensor: Circuit Short to Ground | This continuous and on-demand DTC sets if the DDM detects a short to ground on the vertical position circuit. |
| B137C:11 | Mirror Vertical Position Sensor: Circuit Short to Ground | This continuous and on-demand DTC sets if the DDM detects a short to ground on the vertical position circuit. |
| B1C09:11 | Driver Left/Right Mirror Motor: Circuit Short to Ground | This continuous and on-demand DTC sets if the DDM detects a short to ground when voltage is applied to the horizontal mirror motor circuit. |
| B1C09:15 | Driver Left/Right Mirror Motor: Circuit Short to Battery or Open | This continuous and on-demand DTC sets if the DDM detects a short to battery or open when voltage is applied to the horizontal mirror motor circuit. |
| B1C10:11 | Driver Up/Down Mirror Motor: Circuit Short to Ground | This continuous and on-demand DTC sets if the DDM detects a short to ground when voltage is applied to the vertical motor circuit. |
| B1C10:15 | Driver Up/Down Mirror Motor: Circuit Short to Battery or Open. | This continuous and on-demand DTC sets if the DDM detects a short to battery or open when voltage is applied to the vertical motor circuit. |
DTC FAULT TRIGGER CONDITIONS
Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to Diagnostic Methods in SERVICE INFORMATION for more information about these practices.
Refer to REAR VIEW MIRRORS .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B12BC:11 | Mirror Position Sensor Supply: Circuit Short to Ground | This continuous and on-demand DTC sets if the PDM detects excessive current draw on the mirror position sensor supply circuit. |
| B1302:11 | Mirror Motor Common: Circuit Short to Ground | This continuous and on-demand DTC sets if the PDM detects excessive current draw when voltage is applied to the common circuit. |
| B1302:15 | Mirror Motor Common: Circuit Short to Battery or Open | This continuous and on-demand DTC sets if the PDM detects a short to battery or open when voltage is applied to the common circuit. |
| B1378:11 | Mirror Horizontal Position Sensor: Circuit Short to Ground | This continuous and on-demand DTC sets if the PDM detects a short to ground on the vertical position circuit. |
| B137C:11 | Mirror Vertical Position Sensor: Circuit Short to Ground | This continuous and on-demand DTC sets if the PDM detects a short to ground on the vertical position circuit. |
| B1C11:11 | Passenger Left/Right Mirror Motor: Circuit Short to Ground | This continuous and on-demand DTC sets if the PDM detects a short to ground when voltage is applied to the horizontal motor circuit. |
| B1C11:15 | Passenger Left/Right Mirror Motor: Circuit Short to Battery or Open | This continuous and on-demand DTC sets if the PDM detects a short to battery or open when voltage is applied to the horizontal motor circuit. |
| B1C12:11 | Passenger Up/Down Mirror Motor: Circuit Short to Ground | This continuous and on-demand DTC sets if the PDM detects a short to ground when voltage is applied to the vertical motor circuit. |
| B1C12:15 | Passenger Up/Down Mirror Motor: Circuit Short to Battery or Open | This continuous and on-demand DTC sets if the PDM detects a short to battery or open when voltage is applied to the vertical motor circuit. |
DTC FAULT TRIGGER CONDITIONS
Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to Diagnostic Methods in SERVICE INFORMATION for more information about these practices.
Refer to REAR VIEW MIRRORS .
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| B12D8:11 | Mirror Heater Output: Circuit Short to Ground | This continuous and on-demand DTC sets if the DDM or the PDM detects excessive current draw on the mirror heater output circuit. |
| B12D8:15 | Mirror Heater Output: Circuit Short to Battery or Open | This continuous and on-demand DTC sets if the DDM or the PDM detects lower than expected current draw on the mirror heater output circuit. |
DTC FAULT TRIGGER CONDITIONS
Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to Diagnostic Methods in SERVICE INFORMATION for information about these practices.
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| U0208:00 | Lost Communication With "Seat Control Module A": No Sub Type Information | This continuous DTC sets in the DDM or PDM if data messages received from the DSM over the MS-CAN are missing for.35 seconds or more. |
DTC FAULT TRIGGER CONDITIONS
Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to Diagnostic Methods in SERVICE INFORMATION for information about these practices.
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| U0199:00 | Lost Communication With "Door Control Module A": No Sub Type Information | This continuous DTC sets in the DSM if data messages received from the DDM over the MS-CAN are missing for 10 seconds or more. |
DTC FAULT TRIGGER CONDITIONS
Diagnostics in this information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to Diagnostic Methods in SERVICE INFORMATION for more information about these practices.
Refer to SYSTEM WIRING DIAGRAMS - Power Mirrors for additional information.
Normal Operation
Refer to REAR VIEW MIRRORS .
Mirror Identification
| Item | Part Number | Description |
|---|---|---|
| 1 | Mirror type 1 | |
| 2 | Mirror type 2 | |
| 3 | Mirror type 3 | |
| 4 | Mirror type 4 |
