Engine Mechanical - 2.5L: Overhaul Ford Escape III

Disassembly

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including material created while cleaning gasket surfaces, that enters the oil passages, coolant passages or the oil pan can cause engine failure.

Note. Aluminum surfaces are soft and can be scratched easily. Never place the cylinder head gasket surface, unprotected, on a bench surface.

Note. If the components are to be reinstalled, they must be installed in the same positions. Mark the components removed for locations.

Scheme 659

Scheme 660

Scheme 661

Scheme 662

Scheme 663

1. NOTE: Rear shown in illustration, front similar.
2. Discard the specified component. Follow local disposal regulations.
3. Discard the specified component. Follow local disposal regulations.
4. NOTE: Only use hand tools when removing or installing the spark plugs or damage can occur to the cylinder head or spark plug.
5. NOTE: Use a small screwdriver and multi-purpose grease to remove the valve collets. Remove the valve collets, valve spring retainers and the valve springs. Special Tool(s): Compressor, Valve Spring 303-300, Compressor, Valve Spring 303-350 and Compressor, Valve Spring 303-472. Material: Multi-Purpose Grease XG-4 and/or XL-5.
6. Visual check Install new parts, as necessary.
7. Discard the specified component. Follow local disposal regulations. Special Tool(s): Remover, Valve Stem Oil Seal 303-468, Slide Hammer 307-005.
8. NOTE: Note the location of the valves if they are to be reused.
9. Visual check Inspect the following valve areas: The end of the stem for grooves or scoring. The valve face and the edge for pits, grooves or scores. The valve head for signs of burning, erosion, warpage and cracking. The valve margin for wear. Install new parts, as necessary.

Scheme 664

Scheme 665

Scheme 666

1. NOTE: If installing the original valves, make sure the valves are installed in the same position from which they were removed. Coat the valve stems with clean engine oil. Apply the specified lubricant to the specified component. Material: Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil.
2. NOTE: Use the protector provided with the replacement kit to prevent damage to the valve seals. Apply the specified lubricant to the specified component. Special Tool(s): Installer, Valve Stem Oil Seal 303-470. Material: Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil.
3. NOTE: Check the seating of the valve collets. Install the valve springs, valve spring retainers and the valve collets. Special Tool(s): Compressor, Valve Spring 303-300, Compressor, Valve Spring 303-350 and Compressor, Valve Spring 303-472. Material: Multi-Purpose Grease XG-4 and/or XL-5. Compress the valve spring and install the valve collets, using multi-purpose grease and a small screwdriver. Check the seating of the valve collets.
4. NOTE: Only use hand tools when removing or installing the spark plugs or damage can occur to the cylinder head or spark plug. Tighten to 12 Nm (106 lb-in).
5. Tighten to 12 Nm (106 lb-in).
6. Tighten to 20 Nm (177 lb-in).
7. NOTE: Replace gasket if damaged. Visual check
8. Tighten to 10 Nm (89 lb-in).
9. NOTE: Rear shown in illustration, front similar. Tighten to 47 Nm (35 lb-in).

1. Discard the specified components. Follow local disposal regulations.
2. Discard the specified components. Follow local disposal regulations.
3. NOTE: If the piston and connecting rod are to be reinstalled, they must be assembled in the same orientation. Mark the piston orientation to the connecting rod for reassembly. Separate the piston from the connecting rod. Clean and inspect the piston. Refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-569567) .

Assembly

1. Indicates front of engine.
2. Apply the specified lubricant to the specified component. Material: Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil.
3. Material: Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil.
4. NOTE: The piston compression upper and lower ring should be installed with the paint mark on the outside diameter circumference of the ring to be positioned on the right side of the ring gap. The lower compression ring needs to be installed with the undercut side downward. NOTE: The upper and lower compression ring gaps are not controlled for installation. Align the piston rings onto the piston. Center line of the piston parallel to the wrist pin bore. Upper compression ring gap location. Upper oil control ring gap location. Lower oil control ring gap location. Expander ring and lower compression ring end gap location.

SPECIAL TOOLS Handle 205-153 (T80T-4000-W) Aligner, Crankshaft Sensor 303-1417 Alignment Plate, Camshaft 303-465 (T94P-6256-CH) Dial Indicator Gauge with Holding Fixture 100-002 (TOOL-4201-C) 2, 200# Floor Crane, Fold Away 300-OTC1819E or equivalent Holding Tool, Crankshaft Damper 303-1416 Holding Tool, Flywheel 303-103 (T74P-8375-A) Installer, Camshaft Front Oil Seal 303-096 (T74P-6150-A) Installer, Crankshaft Rear Main Oil Seal 303-328 (T88P-6701-B1) Installer, VCT Spark Plug Tube Seal 303-1247/2 Timing Peg, Crankshaft TDC 303-507

Scheme 667

Scheme 668

Scheme 669

GENERAL EQUIPMENT

MATERIAL SPECIFICATIONS
