Scheme 447

Scheme 448

Scheme 449

Valve Train

The valve train uses DAMB. The camshaft lobes are positioned directly above mechanical buckets which are positioned on top of the valves.

Ti-VCT

The Ti-VCT system allows variable control of intake valve closing which optimizes combustion at full load providing improved power and low speed torque (broadening the torque curve) which enables variable valve overlap which provides better fuel economy and emissions and provides optimized cold start operation with improved exhaust emissions.

Refer to ENGINE SYSTEM - GENERAL INFORMATION for basic mechanical concerns or refer to the INTRODUCTION - GAS for driveability concerns.

Valve Clearance Check

GENERAL EQUIPMENT

1. Remove the valve cover. Refer to «VALVE COVER»(ref-569556-S36973038392013072700000) .
2. Remove the RH fender splash shield. Refer to «FRONT END BODY PANELS»(ref-569581) .
3. NOTE: Turn the engine clockwise only, and only use the crankshaft bolt. NOTE: Measure the clearance of each valve at base circle, with the lobe pointed away from the tappet. General Equipment: Feeler Gauge. Use a feeler gauge to measure the clearance of each valve and record its location.
4. NOTE: The number on the valve tappet only reflects the digits that follow the decimal. For example, a tappet with the number 0.650 has the thickness of 3.650 mm. NOTE: The nominal clearance is: intake: 0.25 mm (0.0095 in). exhaust: 0.36 mm (0.0142 in). NOTE: The acceptable clearances after being fully installed are: intake: 0.19-0.31 mm (0.007-0.012 in). exhaust: 0.30-0.42 mm (0.012-0.017 in). Select tappets using this formula: ideal tappet thickness = measured clearance + the existing tappet thickness - nominal clearance. Select the closest tappet size to the ideal tappet thickness available and mark the installation location.
5. If any tappets do not measure within specifications, install new tappets in these locations. Refer to «VALVE TAPPETS»(ref-569556-S32985000992013072700000) .

Balance Shaft Backlash

SPECIAL TOOLS Dial Indicator Gauge with Holding Fixture 100-002 (TOOL-4201-C) Timing Peg, Crankshaft TDC 303-507

Scheme 450

GENERAL EQUIPMENT

Scheme 451

Scheme 452

Scheme 453

Scheme 454

1. Install the Special Tool(s): Timing Peg, Crankshaft TDC 303-507. Rotate the crankshaft slowly clockwise until the crankshaft balance weight is up against the Crankshaft TDC Timing Peg. The engine is now at TDC.
2. NOTE: Mark the balance shaft assembly front shafts on the top for reference that the balance shaft assembly is at TDC. Marker. General Equipment: Marker.
3. NOTE: Due to the precision interior construction of the balancer unit, it should not be disassembled. Remove the 4 bolts and the balancer unit.
4. Remove the adjustment shims from the seat faces of the balancer unit.
5. NOTE: Visually inspect the balancer unit gear for damage and verify that the shaft turns smoothly. If there is any damage or malfunction, replace the balancer unit. Install the master adjustment shims (No. 50) on the seat faces of the balancer unit.
6. With the balancer unit shaft marks at the TDC position, slowly install the balancer unit to the cylinder block to avoid interference between the crankshaft drive gear and the balancer unit driven gear.
7. Install the balancer unit bolts. Tighten in the sequence shown in illustration in 2 stages. Stage 1: Tighten to 25 Nm (18 lb-ft). Stage 2: Tighten to 42 Nm (31 lb-ft).
8. Remove the Special Tool(s): Timing Peg, Crankshaft TDC 303-507. Rotate the crankshaft to confirm that there are no meshing problems between the balancer unit gear and the crankshaft gear.
9. Install the Special Tool(s): Timing Peg, Crankshaft TDC 303-507. Rotate the crankshaft slowly clockwise until the crankshaft balance weight is up against the Crankshaft TDC Timing Peg. Remove the Crankshaft TDC Timing Peg.
10. NOTE: Measure the backlash and verify that it is within specified range at all of the following 6 positions: 10 degrees, 30 degrees, 100 degrees, 190 degrees, 210 degrees and 280 degrees. It will be necessary to reset the measuring equipment between measurements. NOTE: The measurement must be taken with the Dial Indicator Gauge with Holding Fixture, a 5-mm Allen wrench and worm clamp set up as shown in illustration. Mark the Allen wrench with a file 80 mm (3.149 in) above the driven gear shaft center. Make sure the worm clamp and Allen wrench are not touching the balance shaft housing. NOTE: For an accurate measurement while measuring the gear backlash, insert a screwdriver as shown in illustration into the crankshaft No. 1 crankweight area and set both the rotation and the thrust direction with the screwdriver, using a prying action as shown in illustration. Install the Special Tool(s): Dial Indicator Gauge with Holding Fixture 100-002 Measure the gear backlash. Position the Dial Indicator Gauge with Holding Fixture (1) on the Allen wrench 80 mm (3.149 in) above the driven gear shaft center (2) on the balancer unit. Rotate the crankshaft clockwise and measure the backlash at all of the following 6 positions: 10 degrees, 30 degrees, 100 degrees, 190 degrees, 210 degrees and 280 degrees.
11. NOTE: If maximum backlash exceeds 0.101 mm (0.003 in), install a new balancer unit. Using the backlash measurement, select the proper shims from the Adjustment Shim Selection Table. Remove the balancer unit from the cylinder block. Install the selected adjustment shims on the seat faces of the balancer unit.
12. Install the Special Tool(s): Timing Peg, Crankshaft TDC 303-507. Rotate the crankshaft slowly clockwise until the crankshaft balance weight is up against the Crankshaft TDC Timing Peg. The engine is now at TDC.
13. With the balancer unit shaft marks in the TDC position, slowly install the balancer unit to the cylinder block to avoid interference between the crankshaft drive gear and the balancer unit driven gear.
14. Install the balancer unit bolts. Tighten in the sequence shown in illustration in 2 stages. Stage 1: Tighten to 25 Nm (18 lb-ft). Stage 2: Tighten to 42 Nm (31 lb-ft).
15. Remove the Special Tool(s): Timing Peg, Crankshaft TDC 303-507.
16. NOTE: Remeasure the backlash and verify that it is within specified range at all of the following 6 positions: 10 degrees, 30 degrees, 100 degrees, 190 degrees, 210 degrees and 280 degrees. It will be necessary to reset the measuring equipment between measurements. NOTE: The measurement must be taken with the Dial Indicator Gauge with Holding Fixture, a 5-mm Allen wrench and worm clamp set up as shown in illustration. Mark the Allen wrench with a file 80 mm (3.149 in) above the driven gear shaft center. Make sure the worm clamp and Allen wrench are not touching the balance shaft housing. NOTE: For an accurate measurement while measuring the gear backlash, insert a screwdriver as shown in illustration into the crankshaft No. 1 crankweight area and set both the rotation and the thrust direction with the screwdriver, using a prying action as shown in illustration. Install the Special Tool(s): Dial Indicator Gauge with Holding Fixture 100-002. Measure the gear backlash. Position the Dial Indicator Gauge with Holding Fixture (1) on the Allen wrench 80 mm (3.149 in) above the driven gear shaft center (2) on the balancer unit. Rotate the crankshaft clockwise and measure the backlash at all of the following 6 positions: 10 degrees, 30 degrees, 100 degrees, 190 degrees, 210 degrees and 280 degrees. If the backlash exceeds the specified range of 0.005 to 0.101 mm (0.00019 to 0.0039 in), install a new balancer unit and repeat the procedure.

Scheme 455

Scheme 456

Scheme 457

Scheme 458

1. With vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Disconnect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
3. Remove the TB. Refer to «FUEL CHARGING AND CONTROLS - 2.0L GTDI»(ref-569617) .
4. Refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-569597) .
5. NOTE: Vehicles built on or before 9/28/2012 have a vacuum port on the side of the intake manifold. These engines are equipped with either a brake aspiration hose or intake manifold plug in the vacuum port.
6. Refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-569597) .

Valve Cover

SPECIAL TOOLS Handle 205-153 (T80T-4000-W) Installer, VCT Spark Plug Tube Seal 303-1247/2 Remover, VCT Spark Plug Tube Seal 303-1247/1

Scheme 459

Scheme 460

Scheme 461

MATERIAL SPECIFICATIONS

Crankshaft Pulley

SPECIAL TOOLS Camshaft Alignment Tool 303-1565 Crank Sensor Alignment Tool 303-1521 Timing Peg, Crankshaft TDC 303-507

Scheme 462

GENERAL EQUIPMENT

MATERIAL SPECIFICATIONS

Crankshaft Front Seal

SPECIAL TOOLS Installer, Camshaft Front Oil Seal 303-096 (T74P-6150-A) Remover, Oil Seal 303-409 (T92C-6700-CH)

Scheme 463

Scheme 464

MATERIAL SPECIFICATIONS

Engine Front Cover

GENERAL EQUIPMENT

MATERIAL SPECIFICATIONS

Timing Drive Components

SPECIAL TOOLS Camshaft Alignment Tool 303-1565

GENERAL EQUIPMENT

Camshafts

SPECIAL TOOLS Camshaft Alignment Tool 303-1565 Timing Peg, Crankshaft TDC 303-507

MATERIAL SPECIFICATIONS

Valve Tappets

MATERIAL SPECIFICATIONS

Valve Springs

SPECIAL TOOLS Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-472 (T94P-6565-AH) Compressor, Valve Spring 303-1249

Scheme 465

Scheme 466

GENERAL EQUIPMENT

MATERIAL SPECIFICATIONS

Valve Seals

SPECIAL TOOLS Installer, Valve Stem Oil Seal 303-470 (T94P-6510-CH) Remover, Valve Stem Oil Seal 303-468 (T94P-6510-AH) Slide Hammer 307-005 (T59L-100-B)

Scheme 467

MATERIAL SPECIFICATIONS

Cylinder Head

MATERIAL SPECIFICATIONS

Oil Pan

GENERAL EQUIPMENT

MATERIAL SPECIFICATIONS

Oil Pump

SPECIAL TOOLS Adapter 303-290-05A Adapter 303-290B-19 303-F072

Scheme 468

Scheme 469

GENERAL EQUIPMENT

MATERIAL SPECIFICATIONS

Scheme 470

Scheme 471

1. With the engine in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Disconnect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
3. Remove the engine front cover. Refer to «ENGINE FRONT COVER»(ref-569556-S10199030572013072700000) .
4. Special Tool(s): Engine Support Bar 303-F072, Adapter 303-290-05A and Adapter 303-290B-19.
5. Remove the General Equipment: Wooden Block and Floor Jack.
6. Remove the A/C drive belt. Refer to «ACCESSORY DRIVE»(ref-569614) .
7. Relocate and support the component.
8. Tighten to 27 Nm (20 lb-ft).
9. Discard the specified component. Follow local disposal regulations.

Scheme 472

Scheme 473

1. Clean the specified component with the specified material. Material: Motorcraft® Metal Surface Prep ZC-31-A.
2. Tighten in the sequence shown in illustration in 2 stages: Stage 1: Tighten to 10 Nm (89 lb-in). Stage 2: Tighten to 20 Nm (177 lb-in).
3. Tighten to 25 Nm (18 lb-ft).
4. Tighten to 10 Nm (89 lb-in).
5. Tighten to 10 Nm (89 lb-in).
6. NOTE: Do not use metal scrapers, wire brushes, power abrasive discs or other abrasive means to clean the sealing surfaces. These tools cause scratches and gouges, which make leak paths. Use a plastic scraping tool to remove traces of sealant. Plastic scraper.
7. NOTE: If the oil pan is not secured within 10 minutes of sealant application, the sealant must be removed and the sealing area cleaned with metal surface prep. Allow to dry until there is no sign of wetness, or 10 minutes, whichever is longer. Failure to follow this procedure can cause future oil leakage. Apply a continuous bead of the specified diameter from the specified tube. Material: Silicone Gasket and Sealant TA-30.
8. NOTE: Do not tighten the oil pan bolts at this time. Finger tight.
9. Align the front surface of the oil pan flush with the front surface of the engine block. General Equipment: Straight Edge.
10. Tighten in the sequence shown in illustration to 20 Nm (177 lb-in).
11. Tighten to 48 Nm (35 lb-ft).
12. Tighten to 48 Nm (35 lb-ft).
13. Tighten to 25 Nm (18 lb-ft). Tighten to 9 Nm (80 lb-in). Tighten to 25 Nm (18 lb-ft).
14. Tighten to 5 Nm (44 lb-in). Tighten to 11 Nm (97 lb-in).
15. General Equipment: Wooden Block and Floor Jack.
16. Remove the Special Tool(s): Engine Support Bar 303-F072, Adapter 303-290-05A and Adapter 303-290B-19.
17. Install the engine front cover. Refer to «ENGINE FRONT COVER»(ref-569556-S10199030572013072700000) .
18. Connect the battery ground cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
19. Fill the engine with clean engine oil. Material: Motorcraft® SAE 5W-30 Premium Synthetic Blend Motor Oil.

Oil Filter Adapter

MATERIAL SPECIFICATIONS

Engine Oil Pressure (EOP) Switch

MATERIAL SPECIFICATIONS

Flexplate

SPECIAL TOOLS Holding Tool, Flywheel 303-103 (T74P-8375-A)

Crankshaft Rear Seal with Retainer Plate

SPECIAL TOOLS Installer, Crankshaft Rear Main Oil Seal 303-328 (T88P-6701-B1)

Scheme 474

GENERAL EQUIPMENT

MATERIAL SPECIFICATIONS

Scheme 475

Scheme 476

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Remove the A/C drive belt. Refer to «ACCESSORY DRIVE»(ref-569614) .
3. Remove the flexplate. Refer to «FLEXPLATE»(ref-569556-S07144109982013072700000) .
4. Relocate and support the component.
5. Tighten to 27 Nm (20 lb-ft).
6. Discard the specified component. Follow local disposal regulations.

Scheme 477

1. NOTE: Do not use metal scrapers, wire brushes, power abrasive discs or other abrasive means to clean the sealing surfaces. These tools cause scratches and gouges, which make leak paths. Use a plastic scraping tool to remove traces of sealant. Plastic scraper. General Equipment: Plastic Scraper.
2. Special Tool(s): Installer, Crankshaft Rear Main Oil Seal 303-328. Tighten in the sequence shown in illustration to 10 Nm (89 lb-in).
3. NOTE: If the oil pan is not secured within 10 minutes of sealant application, the sealant must be removed and the sealing area cleaned with metal surface prep. Allow to dry until there is no sign of wetness, or 10 minutes, whichever is longer. Failure to follow this procedure can cause future oil leakage. Apply a continuous bead of the specified diameter from the specified tube. Material: Silicone Gasket and Sealant TA-30.
4. Finger tight.
5. NOTE: The engine front cover-to-oil pan fasteners must be tightened first to align the front surface of the oil pan flush with the front surface of the engine block. Tighten to 10 Nm (89 lb-in).
6. Tighten in the sequence shown in illustration to 20 Nm (177 lb-in).
7. Tighten to 25 Nm (18 lb-ft). Tighten to 9 Nm (80 lb-in). Tighten to 25 Nm (18 lb-ft).
8. Install the flexplate. Refer to «FLEXPLATE»(ref-569556-S07144109982013072700000) .
9. Install the A/C drive belt. Refer to «ACCESSORY DRIVE»(ref-569614) .
10. Fill the engine with clean engine oil. Material: Motorcraft® SAE 5W-30 Premium Synthetic Blend Motor Oil.

Engine Mount

GENERAL EQUIPMENT

SPECIAL TOOLS Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-472 (T94P-6565-AH) Compressor, Valve Spring 303-1249 Installer, Valve Stem Oil Seal 303-470 (T94P-6510-CH) Remover, Valve Stem Oil Seal 303-468 (T94P-6510-AH) Slide Hammer 307-005 (T59L-100-B)

Scheme 478

Scheme 479

MATERIAL SPECIFICATIONS

Piston

MATERIAL SPECIFICATIONS

Scheme 480
