Multifunction Electronic Modules: Other Ford Escape III

Battery Saver

Note. Time-out is 10 seconds if the vehicle is in factory mode or 0 seconds if the vehicle is in transport mode.

The BCM provides automatic shut-off of the courtesy and demand lamps after a time-out period when the ignition is OFF. A timer in the BCM starts when

1. the ignition transitions to OFF.
2. any door or liftgate/luggage compartment lid becomes ajar.
3. an unlock button of the RKE transmitter is pressed.
4. a door is unlocked using a key.
5. the door lock switch is pressed.

When 10 minutes (30 minutes for demand lamps) have elapsed, the BCM automatically shuts off voltage to the lamps. The timer restarts (voltage is restored if the BCM is in battery saver mode) if

1. the ignition transitions out of OFF.
2. any door or liftgate/luggage compartment lid becomes ajar.
3. the unlock button of the RKE transmitter is pressed.
4. a door is unlocked using a key.
5. the door lock switch is pressed.

Post Crash Alert Function

The post crash alert is a function controlled by the BCM. If the Restraints Control Module (RCM) determines an impact of enough severity (the air bags may or may not be deployed), the post crash alert function activates.

The post crash alert function

1. sounds the horn.
2. turns on the interior lights.
3. unlocks the doors.
4. turns off the wipers, if on.

The post crash alert function can be turned off by

1. pressing the hazard flasher lamp switch (which may need to be pressed twice).
2. pressing the RKE transmitter unlock button.
3. pressing the RKE transmitter panic button.

FET Protection

A FET is a type of transistor that, when used with module software, monitors and controls current flow on module outputs. The FET protection strategy prevents module damage in the event of excessive current flow.

The BCM utilizes a FET protective circuit strategy for many of its outputs (for example, a headlamp output circuit). Output loads (current level) are monitored for excessive current (typically short circuits) and are shut down (turns off the voltage or ground provided by the module) when a fault event is detected. A short circuit DTC is stored at the fault event and a cumulative counter is started.

When the demand for the output is no longer present, the module resets the FET circuit protection to allow the circuit to function. The next time the driver requests a circuit to activate that has been shut down by a previous short (FET protection) and the circuit is still shorted, the FET protection shuts off the circuit again and the cumulative counter advances.

When the excessive circuit load occurs often enough, the module shuts down the output until a repair procedure is carried out. Each FET protected circuit has 3 predefined levels of short circuit tolerance based on the harmful effect of each circuit fault on the FET and the ability of the FET to withstand it. A module lifetime level of fault events is established based upon the durability of the FET. If the total tolerance level is determined to be 600 fault events, the 3 predefined levels would be 200, 400 and 600 fault events.

When each tolerance level is reached, DTC U1000:00 should set along with the short circuit DTC that was stored on the first failure. These DTCs cannot be cleared until the vehicle is repaired.

After the repair, it is necessary to clear the DTCs using the Clear DTC operation on the scan tool, cycling the ignition, and run the BCM on-demand self-test.

The module never resets the fault event counter to zero and continues to advance the fault event counter as short circuit fault events occur. If the number of short circuit fault events reach the third level, DTC U3000:49 sets along with the associated short circuit DTC. DTC U3000:49 cannot be cleared and the module must be replaced after the initial fault is repaired.

Gateway Function

The BCM acts as a gateway module by receiving information in one format and transmitting it to other modules using another format. For example, the BCM receives the vehicle speed data from the ABS module over the HS-CAN, converts the data into a MS-CAN message and sends (gateways) the message to other network modules, such as the IPC. This enables network communication between modules that do not communicate using the same network (HS-CAN or MS-CAN).

Transport Mode

During vehicle build, some modules (such as the IPC and the BCM) are set to factory mode. When the vehicle build is complete, the vehicle is set to transport mode.

Transport mode is used to reduce the drain on the battery during longer periods when the vehicle is not used. Various system functions can be altered or disabled when in the transport mode. While in transport mode, the IPC displays TRANSPORT MODE in the message center. Transport mode can be disabled and placed into normal operation mode. Refer to DISABLING TRANSPORT OR FACTORY MODE .

Body Control Module (BCM)

The BCM is a multifunction module that requires PMI when replaced. Refer to MODULE CONFIGURATION .

Remote Function Actuator (RFA) Module

The RFA module is a multifunction module that requires PMI when replaced. Refer to MODULE CONFIGURATION .

Possible Sources

1. BCM
2. PCM

1. ABS module
2. BCM

1. BCM
2. PSCM

1. BCM
2. RCM

1. BCM
2. IPC

1. BCM
2. HVAC module

1. BCM
2. DDM

1. BCM
2. PDM

1. BCM
2. RFA module

1. BCM

1. Wiring, terminals or connectors
2. BCM

Scheme 8

1. K1 CHECK THE BCM VOLTAGE SUPPLY Ignition OFF. Disconnect: BCM C2280G. Measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit C2280G-1 SBB18 (YE) - Ground C2280G-2 SBB17 (RD) - Ground Are the voltages greater than 11 volts? Yes : GO to K2. No : REPAIR the circuit.
2. K2 CHECK FOR CORRECT BCM OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK OASIS for any applicable TSBs. If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new BCM. REFER to «BODY CONTROL MODULE (BCM)»(ref-569586-S23098700392013072700000) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

1. Wiring, terminals or connectors
2. BCM

Scheme 9

Scheme 10

1. L1 CHECK THE BCM POWER GROUND Ignition OFF. Disconnect: BCM C2280E. Measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C2280E-2 GD140 (BK/GY) - Ground Is the resistance less than 3 ohms? Yes : GO to L2. No : REPAIR the circuit.
2. L2 CHECK THE BCM PROCESSOR GROUND Disconnect: BCM C2280A. Measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C2280A-3 GD123 (BK/GY) - Ground Is the resistance less than 3 ohms? Yes : GO to L3. No : REPAIR the circuit.
3. L3 CHECK FOR CORRECT BCM OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK OASIS for any applicable TSBs. If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new BCM. REFER to «BODY CONTROL MODULE (BCM)»(ref-569586-S23098700392013072700000) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

1. Wiring, terminals or connectors
2. Charging system
3. Battery
4. BCM

Scheme 11

Scheme 12

1. M1 CARRY OUT THE BCM SELF-TEST NOTE: DTC U3003:16 will not clear unless the battery voltage is greater than 13V for 2 minutes. Ignition ON. Using a scan tool, clear the DTCs. Wait 10 seconds. Ignition OFF. Ignition ON. Using a scan tool, perform the BCM self-test. Is DTC U3003:16 still present? Yes : GO to M2. No : The system is operating correctly at this time. The DTC may have been set due to a previous low battery voltage condition.
2. M2 CHECK FOR CHARGING SYSTEM DTCs IN THE BCM Using a scan tool, retrieve all continuous memory DTCs. Are any charging system DTCs recorded? Yes : REFER to «CHARGING SYSTEM»(ref-569572) . No : GO to M3.
3. M3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) . Is the battery OK and fully charged? Yes : GO to M4. No : REFER to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
4. M4 CHECK THE BCM VOLTAGE SUPPLY Ignition OFF. Disconnect: BCM C2280G. Ignition ON. Measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit C2280G-1 SBB18 (YE) - Ground C2280G-2 SBB17 (RD) - Ground Are the voltages greater than 11 volts? Yes : GO to M5. No : VERIFY the high current BJB fuse 9 (50A) is OK. If OK, REPAIR the circuit. If not OK, REFER to the appropriate «SYSTEM WIRING DIAGRAMS»(ref-541395) to identify the possible causes for the short circuit.
5. M5 CHECK THE BCM PROCESSOR GROUND Disconnect: BCM C2280A. Measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C2280A-3 GD123 (BK/GY) - Ground Is the resistance less than 3 ohms? Yes : GO to M6. No : REPAIR the circuit.
6. M6 CHECK FOR CORRECT BCM OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK OASIS for any applicable TSBs. If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new BCM. REFER to «BODY CONTROL MODULE (BCM)»(ref-569586-S23098700392013072700000) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

1. Charging system
2. BCM

1. Wiring, terminals or connectors
2. BCM
3. PCM

Scheme 13

1. O1 CHECK THE PCM FOR A SHORT TO GROUND Ignition OFF. Disconnect: PCM C1551B. Ignition ON. Using a scan tool, clear the DTCs. Wait 10 seconds. Using a scan tool, perform the BCM self-test. NOTE: Disregard DTC B1206:15 during this step. DTC B1206:15 sets with the PCM disconnected. Is DTC B1206:11 still present? Yes : GO to O2. No : INSTALL a new PCM. REFER to «ELECTRONIC ENGINE CONTROLS»(ref-569601) .
2. O2 CHECK THE CRASH EVENT SIGNAL CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect: BCM C2280A. Measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C2280A-5 VE518 (BN/WH) - Ground Is the resistance greater than 10, 000 ohms? Yes : GO to O3. No : REPAIR the circuit.
3. O3 CHECK FOR CORRECT BCM OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK OASIS for any applicable TSBs. If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new BCM. REFER to «BODY CONTROL MODULE (BCM)»(ref-569586-S23098700392013072700000) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

1. Wiring, terminals or connectors
2. BCM
3. PCM

Scheme 14

Scheme 15

Scheme 16

1. P1 CHECK THE PCM FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: PCM C1551B. Connect a fused jumper wire between: Lead 1 Lead 2 Pin Circuit Pin Circuit C1551B-29 VE518 (BN/WH) - Ground Ignition ON. Using a scan tool, clear the DTCs. Wait 10 seconds. Using a scan tool, perform the BCM self-test. NOTE: Disregard DTC B1206:11 during this step. DTC B1206:11 sets with the PCM disconnected. Is DTC B1206:15 still present? Yes : REMOVE the jumper wire. GO to P2. No : REMOVE the jumper wire. INSTALL a new PCM. REFER to «ELECTRONIC ENGINE CONTROLS»(ref-569601)
2. P2 CHECK THE CRASH EVENT SIGNAL FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: BCM C2280A. Ignition ON. Measure the voltage between: Lead 1 Lead 2 Pin Circuit Pin Circuit C2280A-5 VE518 (BN/WH) - Ground Is any voltage present? Yes : REPAIR the circuit. No : GO to P3.
3. P3 CHECK THE CRASH EVENT SIGNAL FOR AN OPEN Ignition OFF. Measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C2280A-5 VE518 (BN/WH) C1551B-29 VE518 (BN/WH) Is the resistance less than 3 ohms? Yes : GO to P4. No : REPAIR the circuit.
4. P4 CHECK FOR CORRECT BCM OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK OASIS for any applicable TSBs. If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new BCM. REFER to «BODY CONTROL MODULE (BCM)»(ref-569586-S23098700392013072700000) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

1. BCM
2. LTM

1. Wiring, terminals or connectors
2. BCM
3. RCM

Scheme 17

Scheme 18

1. R1 CONFIRM THAT THE DTC RESETS Ignition ON. Using a scan tool, clear the BCM DTCs. Wait 10 seconds. Road test the vehicle. Using a scan tool, perform BCM self-test. Is BCM DTC B10A2:02 retrieved? Yes : If only BCM DTC B10A2:02 is retrieved, GO to R2. If BCM DTC U0151:00 is retrieved, REPAIR the DTC. GO to «PINPOINT TEST D»(ref-569586-S05010195722013072700000) . No : The system is operating correctly at this time. The DTC may have been falsely set by a RCM self-test, causing the signal to momentarily stop and set the DTC.
2. R2 CHECK FOR RCM DTCs Using a scan tool, perform the RCM self-test. Are any RCM DTCs retrieved? Yes : REPAIR all RCM DTCs. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-569600) . No : GO to R3.
3. R3 CHECK FOR VOLTAGE FROM THE RCM Ignition OFF. Disconnect: BCM C2280C. Ignition ON. Measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit C2280C-51 CR115 (BN) - Ground Is the voltage greater than 5 volts? Yes : GO to R6 . No : GO to R4.
4. R4 CHECK THE EVENT NOTIFICATION SIGNAL CIRCUIT FOR AN OPEN Ignition OFF. Depower the SRS. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-569600) . Disconnect: RCM C310B. Measure the resistance between: Positive Lead Negative Lead Pin Circuit Pin Circuit C310B-42 CR115 (BN) C2280C-51 CR115 (BN) Is the resistance less than 3 ohms? Yes : GO to R5. No : REPAIR the circuit. Refer to the OEM Connector Repair Procedures article for additional information.
5. R5 CONFIRM THE RCM FAULT NOTE: Make sure all SRS components and the RCM electrical connectors are connected before carrying out the self-test. If not, DTCs will be recorded. Ignition OFF. Prior to reconnecting any previously disconnected SRS component: inspect connector(s) (including any inline connectors) for pushed-out, loose or spread terminals and loose or frayed wire connections at terminals. inspect wire harness for any damaged, pinched, cut or pierced wires. inspect RCM C310A and C310B CPA lever/lock for correct operation. REFER to RCM removal and installation instructions in «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-569600) . repair any concerns found. Refer to Refer to the OEM Connector Repair Procedures article for additional information. Connect: BCM C2280C. Connect: RCM C310A and C310B. Repower the SRS. Do not prove out the SRS at this time. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-569600) . Ignition ON. Using a scan tool, perform the BCM self-test. Was the original DTC retrieved on-demand during self-test? Yes : CHECK OASIS for any applicable TSBs. If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new RCM. REFER to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-569600) . No : The fault is not present at this time. The fault may have been caused by a loose or corroded connector. REPAIR the root cause of any connector or terminal issues.
6. R6 CHECK FOR CORRECT BCM OPERATION Disconnect and inspect all BCM connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the BCM connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK OASIS for any applicable TSBs. If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new BCM. REFER to «BODY CONTROL MODULE (BCM)»(ref-569586-S23098700392013072700000) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

1. Battery
2. PCM

1. BCM
2. RFA module

1. Wiring, terminals or connectors
2. Battery
3. Generator
4. PCM
5. RFA module

Scheme 19

Scheme 20

1. U1 CHECK THE RFA MODULE VOLTAGE SUPPLY Ignition ON. Measure and record the battery voltage. Ignition OFF. Disconnect: RFA Module C4392C. Ignition ON. Measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit C4392C-5 SBR08 (VT/RD) - Ground Is the voltage measured at the RFA module within 2 volts of the voltage measured at the battery? Yes : GO to U2. No : REPAIR the circuit.
2. U2 CHECK THE RFA MODULE GROUND Measure the voltage between: Positive Lead Negative Lead Pin Circuit Pin Circuit C4392C-5 SBR08 (VT/RD) C4392C-4 GD143 (BK/VT) Is the voltage greater than 11 volts? Yes : GO to U3. No : REPAIR the circuit.
3. U3 CHECK FOR CORRECT RFA MODULE OPERATION Disconnect and inspect all the RFA module connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the RFA module connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK OASIS for any applicable TSBs. If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new RFA module. REFER to «REMOTE FUNCTION ACTUATOR (RFA) MODULE»(ref-569586-S01476175832013072700000) . No : The system is operating correctly at this time. The concern may have been caused by module connections. ADDRESS the root cause of any connector or pin issues.

Disabling Transport or Factory Mode

1. Place the ignition in the OFF position.
2. Verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-569582) .
3. NOTE: ON vehicles with intelligent access (IA), place a programmed IA key in the passive anti-theft system (PATS) transceiver slot. Place the ignition in the ON position. NOTE: Steps 4 and 5 must be carried out within 10 seconds.
4. Press and release the brake pedal 5 times.
5. Press and release the hazard switch 2 times (on, off).
6. NOTE: When exiting Factory mode, the instrument panel cluster (IPC) message center will indicate NORMAL MODE when the procedure has been successfully completed. Place the ignition in the OFF position.
