Engine Cooling System: Removal & Installation Ford Escape III

Removal

Note. Removal steps in this procedure may contain installation details.

All engines

Installation

1. To install, reverse the removal procedure.
2. Fill and bleed the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 12

1. Remove the heater shut-off valve. Refer to ' «HEATER SHUT-OFF VALVE»(ref-569571-S41241902422013072700000) .
2. General Equipment: Hose Clamp Remover/Installer.
3. Discard the specified component. Follow local disposal regulations. To install, tighten to 10 Nm (89 lb-in).

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 13

Scheme 14

1. Drain the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .
2. NOTE: Cover the generator to prevent coolant contamination of the generator. Completely cover the generator with waterproof plastic.
3. General Equipment: Hose Clamp Remover/Installer.
4. General Equipment: Hose Clamp Remover/Installer.
5. Visual check. To install, tighten to 10 Nm (89 lb-in).

1. To install, reverse the removal procedure.
2. Fill and bleed the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .

Note. Removal steps in this procedure may contain installation details.

1. Drain the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .
2. NOTE: Cover the generator to prevent coolant contamination of the generator. Completely cover the generator with waterproof plastic.
3. General Equipment: Hose Clamp Remover/Installer.
4. Discard the specified component. Follow local disposal regulations. To install, tighten to 10 Nm (89 lb-in).

1. To install, reverse the removal procedure.
2. Fill and bleed the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 15

1. Drain the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .
2. Remove the intake manifold. Refer to «ENGINE - 2.5L»(ref-569568) .
3. General Equipment: Hose Clamp Remover Installer.

1. To install, reverse the removal procedure.
2. Fill the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .

Note. Do not loosen or remove the crankshaft pulley bolt without first installing the special tools. The crankshaft pulley and the crankshaft timing sprocket are not keyed to the crankshaft. Before any repair requiring loosening or removal of the crankshaft pulley bolt, the crankshaft and camshafts must be locked in place by the special service tools, otherwise severe engine damage can occur.

Note. During engine repair procedures, cleanliness is extremely important. Any foreign material, including any material created while cleaning gasket surfaces, that enters the oil passages, coolant passages or the oil pan can cause engine failure.

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. With the vehicle in NEUTRAL, position it on a hoist. Refer to «JACKING & LIFTING»(ref-569550) .
2. Remove the cowl panel. Refer to «FRONT END BODY PANELS»(ref-569581) .
3. Remove the RH front wheel and tire. Refer to «WHEELS AND TIRES»(ref-569561) .
4. Drain the cooling system. refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .
5. Remove the RH front fender splash shield. Refer to «FRONT END BODY PANELS»(ref-569581) .
6. Discard the specified component. Follow local disposal regulations.
7. NOTE: It may be necessary to rotate the halfshaft to remove the front lower bolt.
8. NOTE: The Crankshaft TDC Timing Pin will contact the crankshaft and prevent it from turning past TDC. However, the crankshaft can still be rotated in the counterclockwise direction. The crankshaft must remain at the TDC position during the crankshaft pulley removal and installation. Install the Special Tool(s): Pin, Crankshaft TDC 303-748.
9. NOTE: Only rotate the crankshaft clockwise direction. Special Tool(s): Timing Peg, Crankshaft TDC 303-507. Rotate the crankshaft slowly clockwise until the crankshaft balance weight is up against the TDC Timing Peg. The engine is now at TDC.
10. Turn the component CCW through 1 complete turn.
11. Remove the generator. Refer to «CHARGING SYSTEM»(ref-569572) .
12. Special tool(s): Tool, Timing Belt Holding 303-1556. Marker.
13. NOTE: The crankshaft or camshafts must not be rotated while the timing belt is removed. General Equipment: Holding Pin.

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. Tighten to 10 Nm (89 lb-in).
2. Visual check.
3. Tighten to 25 Nm (18 lb-ft). Remove the General Equipment: Holding Pin.
4. Visual check Remove the Special Tool(s): Tool, Timing Belt Holding 303-1556.
5. Tighten to 10 Nm (89 lb-in). Finger tight. Finger tight.
6. Tighten to 10 Nm (89 lb-in).
7. Tighten to 48 Nm (35 lb-ft).
8. Tighten to 8 Nm (71 lb-in).
9. Tighten to 80 Nm (59 lb-ft).
10. Install the generator. Refer to «CHARGING SYSTEM»(ref-569572) .
11. Remove the Special Tool(s): Pin, Crankshaft TDC 303-748.
12. Tighten to 20 Nm (177 lb-in).
13. Tighten to 48 Nm (35 lb-ft).
14. Tighten to 5 Nm (44 lb-in). Tighten to 25 Nm (18 lb-ft). Tighten to 25 Nm (18 lb-ft).
15. Tighten to 20 Nm (177 lb-in).
16. Install the RH front fender splash shield. Refer to «FRONT END BODY PANELS»(ref-569581) .
17. Install the RH front wheel and tire. Refer to «WHEELS AND TIRES»(ref-569561) .
18. Tighten to 5 Nm (44 lb-in).
19. Tighten to 5 Nm (44 lb-in).
20. Install the cowl panel. Refer to «FRONT END BODY PANELS»(ref-569581) .
21. Fill the cooling system. refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .

1. Drain the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .
2. Turn the component CCW through 1 complete turn.
3. Discard the specified component. Follow local disposal regulations.

1. Apply the specified lubricant to the specified component. Material: Motorcraft Orange Antifreeze/Coolant. Tighten to 10 Nm (89 lb-in).
2. Visual check.
3. Tighten to 20 Nm (177 lb-in).
4. Fill and bleed the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 28

Scheme 29

1. Remove the cooling module. Refer to «COOLING MODULE»(ref-569571-S19754305672013072700000) .
2. General Equipment: Hose Clamp Remover/Installer.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

All engines

1. To install, reverse the removal procedure.
2. Fill and bleed the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .
3. Evacuate, leak test and charge the A/C system: For EATC system, refer to «CLIMATE CONTROL SYSTEM - ELECTRONIC MANUAL TEMPERATURE CONTROL (EMTC)»(ref-569573) . For DATC system, refer to «CLIMATE CONTROL SYSTEM - DUAL AUTOMATIC TEMPERATURE CONTROL (DATC)»(ref-569574) .

Note. Removal steps in this procedure may contain installation details.

Scheme 30

Scheme 31

Scheme 32

1. Remove the cooling module. Refer to «COOLING MODULE»(ref-569571-S19754305672013072700000) .
2. To install, tighten to 5 Nm (44 lb-in).

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. WARNING: Always allow the engine to cool before opening the cooling system. Do not unscrew the coolant pressure relief cap when the engine is operating or the cooling system is hot. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. Failure to follow these instructions may result in serious personal injury.
2. Hose pinch pliers. Extract the fluid with a syringe.
3. General Equipment: Hose Clamp Remover/Installer.

1. To install, reverse the removal procedure.
2. Fill the degas bottle. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) for the recommended coolant mixture and fill level.

Note. Removal steps in this procedure may contain installation details.

1. Drain the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .
2. Remove the generator. Refer to «CHARGING SYSTEM»(ref-569572) .
3. Discard the specified component. Follow local disposal regulations. To install, tighten to 10 Nm (89 lb-in).

1. To install, reverse the removal procedure.
2. Fill and bleed the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 37

1. Drain the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .
2. General Equipment: Hose Clamp Remover/Installer.
3. Discard the specified component. Follow local disposal regulations. To install, tighten to 10 Nm (89 lb-in).

1. To install, reverse the removal procedure.
2. Fill and bleed the cooling system. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .

Note. Removal steps in this procedure may contain installation details.

1. Remove the cooling fan motor and shroud. Refer to «COOLING FAN MOTOR AND SHROUD»(ref-569571-S16041825642013072700000) .

1. To install, reverse the removal procedure.

1. To install, reverse the removal procedure.
2. Fill the degas bottle. Refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) for the recommended coolant mixture and fill level.
