Engine Cooling System: Maintenance Ford Escape III

Cooling System (Mechanical) 5 illustrations ~628 words

Cooling System Draining, Filling and Bleeding

SPECIAL TOOLS Airlift Cooling System Tester UVU550000 or equivalent

Scheme 38

Scheme 38: Cooling System Draining, Filling and Bleeding
ItemSpecification
Motorcraft® Orange Antifreeze/Coolant Concentrated VC-3-B (US); CVC-3-B2 (Canada)WSS-M97B44-D
Motorcraft® Orange Antifreeze/Coolant Prediluted VC-3DIL-B (US); CVC-3DIL-B (Canada)WSS-M97B44-D2

MATERIAL SPECIFICATIONS

Draining

WARNINGAlways allow the engine to cool before opening the cooling system. Do not unscrew the coolant pressure relief cap when the engine is operating or the cooling system is hot. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. Failure to follow these instructions may result in serious personal injury.

Note. The coolant must be recovered in a suitable, clean container for reuse. If the coolant is contaminated, it must be recycled or disposed of correctly. Using contaminated coolant may result in damage to the engine or cooling system components.

Note. The vehicle cooling system is filled with Motorcraft® Orange Antifreeze/Coolant. Do not mix coolant types. Mixing coolant types degrades the corrosion protection of the coolant. Failure to follow these instructions may damage the engine or cooling system.

Note. Always fill the cooling system with the manufacturer's specified coolant. Chemically flush the cooling system if a non-specified coolant has been used. Refer to COOLING SYSTEM FLUSHING . Failure to follow these instructions may damage the engine or cooling system.

Note. During normal vehicle operation, Motorcraft® Orange Antifreeze/Coolant may change color from orange to pink or light red. As long as the engine coolant is clear and uncontaminated, this color change does not indicate the engine coolant has degraded nor does it require the engine coolant to be drained, the system to be flushed, or the engine coolant to be replaced.

Note. Less than 80% of coolant capacity can be recovered with the engine in the vehicle. Dirty, rusty or contaminated coolant requires replacement.

Scheme 39

Scheme 39
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-569550) .
  2. Release the pressure in the cooling system by slowly turning the pressure relief cap one-half turn counterclockwise. When the pressure is released, remove the pressure relief cap.
  3. Install a drain hose on the radiator draincock.
  4. Place a suitable container below the radiator draincock. Open the draincock and allow to drain. Close the draincock after draining.

Cooling System Flushing

ItemSpecification
Motorcraft® Premium Cooling System Flush VC-1ESR-M14P7-A

MATERIAL SPECIFICATIONS

WARNINGAlways allow the engine to cool before opening the cooling system. Do not unscrew the coolant pressure relief cap when the engine is operating or the cooling system is hot. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. Failure to follow these instructions may result in serious personal injury.

Note. To remove rust, sludge and other foreign material from the cooling system, use cooling system flush that is safe for use with aluminum radiators. This cleaning restores cooling system efficiency and helps prevent overheating. A pulsating or reversed direction of flushing water will loosen sediment more quickly than a steady flow in the normal coolant flow direction. In severe cases where cleaning solvents will not clean the cooling system efficiently, it will be necessary to use the pressure flushing method using cooling system flusher. Dispose of old coolant and flushing water contaminated with antifreeze and cleaning chemicals in accordance with local, state or federal laws.

  1. Add Premium Cooling System Flush to the cooling system and follow the directions on the package.
  2. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .
  3. Remove the radiator. Refer to «RADIATOR»(ref-569571-S05911474452013072700000) .
  4. NOTE: Radiator internal pressure must not exceed 138 kPa (20 psi). Damage to the radiator can result. Backflush the radiator with radiator turned so the upper radiator hose is at the top and with a high-pressure hose in the upper hose location.
  5. NOTE: The thermostat and housing are serviced as an assembly. Remove the thermostat housing. Refer to «THERMOSTAT HOUSING - 1.6L GTDI»(ref-569571-S34184907782013072700000) , «THERMOSTAT HOUSING - 2.0L GTDI»(ref-569571-S33582063442013072700000) , or «THERMOSTAT HOUSING - 2.5L»(ref-569571-S02870471332013072700000) .
  6. Backflush the engine. Position the high-pressure water hose into the engine through the lower radiator hose and backflush the engine.
  7. NOTE: The thermostat and housing are serviced as an assembly. Install the thermostat housing. Refer to «THERMOSTAT HOUSING - 1.6L GTDI»(ref-569571-S34184907782013072700000) , «THERMOSTAT HOUSING - 2.0L GTDI»(ref-569571-S33582063442013072700000) , or «THERMOSTAT HOUSING - 2.5L»(ref-569571-S02870471332013072700000) .
  8. Install the radiator. Refer to «RADIATOR»(ref-569571-S05911474452013072700000) .
  9. Fill and bleed the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING AND BLEEDING»(ref-569571-S38562264622013072700000) .

Transmission Fluid Heater Coolant Control Valve

General Equipment
Hose Clamp Remover/Installer

Scheme 40

Scheme 40: Removal

Scheme 41

Scheme 41

Scheme 42

Scheme 42
  1. Hose pinch pliers.
  2. General Equipment: Hose Clamp Remover/Installer.
