Power Transfer Unit (Ptu): Removal & Installation Ford Escape I рестайлинг

Removal

1. Remove the transfer case. For additional information, refer to «POWER TRANSFER UNIT (PTU) - AUTOMATIC TRANSAXLE»(ref-232190-S21390762642006051600000) or «POWER TRANSFER UNIT (PTU) - MANUAL TRANSAXLE»(ref-232190-S24445789582006051600000) .
2. Using the special tool to hold the flange, remove the pinion nut.
3. Using the special tool, remove the transfer case rear output shaft flange.

Installation

1. Install the transfer case rear output shaft flange.
2. Using the special tool, install the pinion nut.
3. Install the transfer case. For additional information, refer to «POWER TRANSFER UNIT (PTU) - AUTOMATIC TRANSAXLE»(ref-232190-S21390762642006051600000) or «POWER TRANSFER UNIT (PTU) - MANUAL TRANSAXLE»(ref-232190-S24445789582006051600000) .

1. Remove the transfer case. For additional information, refer to «POWER TRANSFER UNIT (PTU) - AUTOMATIC TRANSAXLE»(ref-232190-S21390762642006051600000) or «POWER TRANSFER UNIT (PTU) - MANUAL TRANSAXLE»(ref-232190-S24445789582006051600000) .
2. Using the slide hammer with a 3-jaw puller attachment, remove the transfer case tube.

Scheme 1

Scheme 2

1. Inspect the condition of the transfer case vent hole. By hand, insert the new transfer case vent into the transfer case cover and measure the distance between the transfer case cover and the vent as indicated. If the measurement is less than specification, install a new transfer case.
2. Apply a bead of silicone gasket and sealant to the transfer case vent where indicated.
3. Using the special tool, install the transfer case vent.
4. Measure the depth of the transfer case vent. If the vent is too high, repeat Step 3 .
5. Install the transfer case vent boot.
6. Install the transfer case. For additional information, refer to «POWER TRANSFER UNIT (PTU) - AUTOMATIC TRANSAXLE»(ref-232190-S21390762642006051600000) or «POWER TRANSFER UNIT (PTU) - MANUAL TRANSAXLE»(ref-232190-S24445789582006051600000) .
