Power Transfer Unit (Ptu): Component Locations Ford Escape I рестайлинг

Special Tool(s)

SPECIAL TOOL(S) CHART Installer, PTO Drive Gear Outer Oil Seal 308 - 430 or equivalent

Scheme 3

Scheme 4

1. Remove the transfer case rear output shaft flange. For additional information, refer to «OUTPUT FLANGE»(ref-232190-S10129327142006051600000) .
2. Remove the transfer case rear output shaft oil (pinion) seal.

Scheme 5

1. Using the special tool, install the transfer case rear output shaft oil (pinion) seal.
2. Install the transfer case rear output shaft flange. For additional information, refer to «OUTPUT FLANGE»(ref-232190-S10129327142006051600000) .

SPECIAL TOOL(S) CHART Holding Fixture, Drive Pinion Flange 205-126 (T78P-4851-A) Remover, Steering Wheel 211-014 (T67L-3600-A)

Scheme 6

SPECIAL TOOL(S) CHART Installer, Vent Tube 308-584 or equivalent

Scheme 7

SPECIAL TOOL(S) CHART Slide Hammer 100-001 (T50T-100-A) Remover, Halfshaft Oil Seal 308-428 (1 Of 2)

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Remove the PTU from the vehicle. For additional information, refer to «POWER TRANSFER UNIT (PTU) - AUTOMATIC TRANSAXLE»(ref-232190-S21390762642006051600000) or «POWER TRANSFER UNIT (PTU) - MANUAL TRANSAXLE»(ref-232190-S24445789582006051600000) .
2. Using the special tools, remove the outer input seal.
3. Remove the dust cover and the halfshaft seal.
4. Remove the dust cover and the output seal.
5. Remove the PTU vent tube.
6. Remove the PTU cover bolts and the PTU cover, then remove the gears.
7. Remove the inner input seal.
8. Clean the PTU sealing surface.

SPECIAL TOOL(S) CHART Adapter for 303-224 (Handle) 205-153 (T80T-4000-W) Installer, Halfshaft Oil Seal 308-429 Installer, Rear Axle Oil Seal 205-155 (T80T-4000-Y) Installer, Halfshaft Oil Seal 308-431 Installer, PTO Dust Flange 308 - 432 Installer, Driven Gear Oil Seal 308-427 Installer, PTO Drive Gear Outer Oil Seal 308-430

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17
