Special Tool(s)
SPECIAL TOOLS Worldwide Diagnostic System (WDS), Vehicle Communication Module (VCM) with appropriate adapters, or equivalent diagnostic tool 73III Automotive Meter 105-R0057 or equivalent Flex Probe Kit 105-R025B
Scheme 11
Scheme 12
Scheme 13
Refer to SYSTEM WIRING DIAGRAMS (Escape) or SYSTEM WIRING DIAGRAMS (Marine) for connector identification and wiring diagrams.
The steering column switches include the ignition switch and the multifunction switch (high beam/low beam, flash-to-pass, turn signal, and windshield wiper). The ignition switch is controlled by the ignition lock cylinder with a key. When the ignition lock cylinder is turned using the key, a mechanical connection positions the ignition switch to the selected position and allows the ignition switch to send voltage to specific components. The multifunction switch controls the various components electrically. The headlamp switch sends constant voltage to the headlamps when placed in the ON position, while the flash-to-pass is a momentary switch used to send voltage to the headlamp high beams only. The headlamp high beam/low beam switch sends voltage to the low or high beam headlamps while the headlamps are on. The turn signal switch portion of the multifunction switch operates the left and right turn signals. The windshield wiper switch function uses a ground signal to activate the various wiper modes and the wiper/washer.
