Speaker System: Removal & Installation Ford Escape I рестайлинг

Removal and Installation

1. Remove the door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-232240) . Front Door Tweeter Speaker
2. Release the pin-type retainer and remove the front door tweeter speaker.
3. Remove the 4 speaker screws and the speaker. Disconnect the electrical connector.
4. To install, reverse the removal procedure.

Scheme 47

1. Remove the RH quarter trim panel.
2. Disconnect the subwoofer amplifier electrical connector.
3. Remove the 3 bolts and the speaker enclosure. To install, tighten to 8 Nm (71 lb-in).
4. To install, reverse the removal procedure.
