Removal and Installation
| CAUTION | On vehicles equipped with a CD6 audio unit, interrupting battery power within 30 seconds of repowering will damage the audio unit. To prevent audio unit damage, do not disconnect the battery (or audio unit), reconnect the battery (or audio unit), and then disconnect it again within 30 seconds. |
Scheme 1
- Using the special tool, remove the audio unit. Disconnect the electrical connectors and the antenna lead-in cable.
- To install, reverse the removal procedure.
Scheme 2
- Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-232248) .
- Remove the RH rear quarter trim panel.
- Disconnect the subwoofer amplifier electrical connector.
- Remove the 4 screws and the subwoofer amplifier.
- To install, reverse the removal procedure.
