Antenna System: Removal & Installation Ford Escape I рестайлинг

Removal and Installation

1. Remove the antenna mast.
2. Disconnect the antenna cable from the antenna lead-in cable.
3. Release the antenna cable grommet from the vehicle body.
4. Remove the RH front fender splash shield. For additional information, refer to «FRONT END BODY PANELS»(ref-232284) .
5. Remove the antenna base mounting nut (located behind the RH fender) and the antenna base. To install, tighten to 7 Nm (62 lb-in).
6. To install, reverse the removal procedure.

Scheme 46

1. Remove the audio unit. For additional information, refer to «AUDIO UNIT»(ref-232286) .
2. Disconnect the antenna lead-in cable from the antenna cable.
3. Release the antenna lead-in cable pin-type retainers.
4. Remove the antenna lead-in cable.
5. To install, reverse the removal procedure.
