Removal and Installation
| WARNING | Always disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury. |
Scheme 30
Scheme 31
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-494597) .
- Remove the nut and position aside the ground wire. To install, tighten to 18 Nm (159 lb-in).
- Remove the starter motor terminal cover.
- Remove the starter motor solenoid battery cable nut. To install, tighten to 12 Nm (106 lb-in).
- Remove the starter motor solenoid wire nut. To install, tighten to 5 Nm (44 lb-in).
- Remove the 2 stud bolts and the starter motor. To install, tighten to 48 Nm (35 lb-ft).
- To install, reverse the removal procedure.
Scheme 32
| Item | Part Number | Description |
|---|---|---|
| 1 | Transmission shift cable adjustment lock (part of 7E395) | |
| 2 | 7H181 | Transmission shift cable rotating slide snap |
| 3 | W711892 | Transmission manual control lever nut |
| 4 | 7A256 | Transmission manual control lever |
Scheme 33
| Item | Part Number | Description |
|---|---|---|
| 1 | 11N087 | Starter motor solenoid battery cable terminal cover |
| 2 | W706414 | Starter motor solenoid battery cable nut |
| 3 | Starter motor solenoid battery cable terminal (part of 14300) | |
| 4 | W705790 | Starter motor solenoid wire nut |
| 5 | Starter motor solenoid wire terminal (part of 14300) | |
| 6 | Wire harness retainer (part of 14300) | |
| 7 | W711515 | Starter motor stud bolt |
| 8 | W503320 | Starter motor bolt |
| 9 | 11002 | Starter motor |
| WARNING | Always disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury. |
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-494597) .
- Remove the Air Cleaner (ACL). For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-494599) .
- Disconnect the transmission shift cable and adjustment lock from the transmission manual control lever.
- Disconnect the transmission shift cable rotating slide snap and position aside the transmission cable.
- Remove the nut and the transmission manual control lever. To install, tighten to 18 Nm (159 lb-in).
- Remove the starter motor terminal cover.
- Remove the starter motor solenoid battery cable nut. To install, tighten to 12 Nm (106 lb-in).
- Remove the starter motor solenoid wire nut. To install, tighten to 5 Nm (44 lb-in).
- Detach the wiring harness retainer from the starter motor stud bolt and position the wiring harness aside.
- Remove the starter motor bolt, stud bolt and the starter. To install, tighten to 48 Nm (35 lb-ft).
- To install, reverse the removal procedure.
