Without Intelligent Access
- Fuse(s)
- Battery
- Battery cables
- Ignition switch
- Starter motor
- Starter relay (located in the Battery Junction Box (BJB))
- PCM (located on the RH side of cowl)
- Body Control Module (BCM)
- Transmission Range (TR) sensor (located inside the transmission)
- Integrated Keyhead Transmitter (IKT)
- Remote start feature, initiated by pressing a sequence of buttons on the IKT
With Intelligent Access
- Fuse(s)
- Battery
- Battery cables
- Start/stop switch
- Brake switch
- Starter motor
- Starter relay (located in the BJB)
- PCM (located on the RH side of cowl)
- BCM
- TR sensor (located inside the transmission)
- Intelligent Access (IA) key
- Remote Function Actuator (RFA) module
- Remote start feature, initiated by pressing a sequence of buttons on the IA key
SPECIAL TOOLS DESCRIPTION CHART Flex Probe Kit NUD105-R025D or equivalent Circuit Tester / Test Light SGT27000 Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 34
Scheme 35
Scheme 36
Scheme 37
Component Tests
| WARNING | Always disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury. |
Always make the Fluke 77-IV Digital Multimeter connections at the component terminal rather than at the wiring end connector. Making a connection at the wiring end connector could result in false readings because the meter will not pick up a high resistance between the wiring connector and the component.
Scheme 38
- Make sure the battery is fully charged. Carry out a battery load test. Refer to «BATTERY, MOUNTING AND CABLES»(ref-494597) .
- Connect a remote starter switch between the starter solenoid "S" terminal and the battery positive (+) terminal.
- Connect the Fluke 77-IV Digital Multimeter positive lead to the battery positive (+) post. Connect the negative lead to the starter solenoid "M" terminal.
- Engage the remote starter switch. Read and record the voltage. The voltage reading should be 0.5 volt or less.
- If the voltage reading is 0.5 volt or less, go to the «STARTER MOTOR - Ground Circuit Test»(ref-494580-S08888366012012081400000) .
- If the voltage reading is greater than 0.5 volt, this is an indication of excessive resistance in the connections, the positive battery cable or in the starter solenoid. Move the Fluke 77-IV Digital Multimeter negative lead to the starter solenoid "B" terminal and repeat the test. If the voltage reading at the "B" terminal is lower than 0.5 volt, the concern is either in the connections at the starter solenoid or in the solenoid contacts.
- Remove the cables from solenoid "B" "S" and "M" terminals. Clean the cables and connections and reinstall the cables to the correct terminals. Repeat Steps 3 through 6. If the voltage drop reading is still greater than 0.5 volt when checked at the "M" terminal or less than 0.5 volt when checked at the "B" terminal, the concern is in the solenoid contacts. Install a new starter motor.
- If the voltage reading taken at the solenoid "B" terminal is still greater than 0.5 volt after cleaning the cables and connections at the solenoid, the concern is either in the positive (+) battery cable connection or in the positive battery cable itself.
- Clean the positive (+) battery cable connection. If this does not solve the problem, install a new positive battery cable.
