Parking Aid System: Other Ford Edge I рестайлинг

Video

The rear video camera system consists of the following

1. Video camera (located in the liftgate)
2. Accessory Protocol Interface Module (APIM)
3. Front Display Interface Module (FDIM)
4. Instrument Panel Cluster (IPC)
5. Body Control Module (BCM)

The video camera system visually aids the driver while reversing or reverse parking the vehicle. The video camera system features are as follows

1. Fixed guidelines - this feature assists the driver with backing into a parking space or aligning the vehicle with an object.
2. Visual park aid alert - this feature assists the driver to visually see the object causing the parking aid system to sound.
3. Manual zoom - this feature assists the driver with connecting or towing a trailer allowing the driver to manually zoom closer to an object behind the vehicle.
4. Video camera delay - this feature allows the driver to see the image behind the vehicle after the vehicle is shifted out of reverse. The image will not be displayed if the vehicle is shifted into park.

The features are controlled though the FDIM. Refer to the Owner's Literature for information on how to operate the video camera system features.

SPECIAL TOOLS CHART Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit NUD105-R025D or equivalent

Scheme 31

Scheme 32

Scheme 33

Parking Aid - Video

SPECIAL TOOLS CHART Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit NUD105-R025D or equivalent

Scheme 34

Elevation System Check

1. Turn the ignition to the ON position, engine off.
2. Set the parking brake.
3. Place the gear shift in REVERSE (R).
4. Verify that no audible alerts are heard. If audible alerts are heard, check to make sure the bumper is correctly installed and is not tilted downward so that the sensor is pointing at the ground. If the audible warning tone is heard, refer to «PARKING AID»(ref-494633-S39724657982012081400000) in the Diagnosis and Testing portion of this article.

Scheme 35
