Removal and Installation
- Upload the PAM configuration to the scan tool. For additional information, refer to Programmable Module Installation (PMI) in «MODULE CONFIGURATION»(ref-494552) .
- Remove the LH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-494578) .
- Remove the 2 nuts and the PAM. Disconnect the electrical connector.
- To install, reverse the removal procedure. Download the configuration information to the PAM. For additional information, refer to «MODULE CONFIGURATION»(ref-494552) to carry out PMI.
Scheme 27
| Item | Part Number | Description |
|---|---|---|
| 1 | Parking aid sensor electrical connectors (part of 14N139) | |
| 2 | 15K859 | Parking aid sensors |
- Remove the rear bumper cover. For additional information, refer to «BUMPERS»(ref-494621) .
- Disconnect the parking aid sensor(s) electrical connector(s).
- Press the retaining tabs and remove the parking aid sensor(s).
- To install, reverse the removal procedure.
Scheme 28
| Item | Part Number | Description |
|---|---|---|
| 1 | 15K864 | Parking aid speaker |
| 2 | W705635 | Parking aid speaker push pins (2 required) |
| 3 | Parking aid speaker electrical connector (part of 14A005) |
- Remove the LH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-494578) .
- Remove the 2 push pins and the parking aid speaker. Disconnect the electrical connector.
- To install, reverse the removal procedure.
Scheme 29
| Item | Part Number | Description |
|---|---|---|
| 1 | 7842528 | Name plate |
| 2 | Rear video camera bracket screw | |
| 3 | Rear video camera bracket | |
| 4 | 19G940 | Rear video camera |
| 5 | Rear video camera electrical connector (part of 14A583) |
Scheme 30
| Item | Part Number | Description |
|---|---|---|
| 1 | Rear video camera electrical connector (part of 14A583) | |
| 2 | Rear video camera bracket | |
| 3 | 19G940 | Rear video camera |
Removal
Edge
Pinpoint Test I
I5
MKX
- MKX
Installation
Edge
Pinpoint Test I
I6
MKX
- MKX
