Engine Ignition Components - Exploded View
Note. LH side shown in illustration, RH side similar.
Scheme 6
| Item | Part Number | Description |
|---|---|---|
| 1 | Ignition coil-on-plug electrical connector (3 required) (part of 12C508) | |
| 2 | W714507 | Ignition coil-on-plug bolt (3 required) |
| 3 | 12029 | Ignition coil-on-plug (3 required) |
| 4 | 12025 | Coil seal (3 required) |
| 5 | 12405 | Spark plug (3 required) |
- Refer to the appropriate procedures and/or exploded views in this service information for any Warnings, Notices, Notes, Materials, Specifications, and Special Tools. Items in the exploded views may not be listed in order of removal.
Ignition Coil-On-Plug
| Item | Specification |
|---|---|
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
MATERIAL SPECIFICATIONS
