Power Steering System: Removal & Installation Ford Econoline E150

Manual & Power Steering 22 illustrations ~611 words

Removal

CAUTIONWhile repairing the power steering system, care should be taken to prevent the entry of contaminants or premature failure of the power steering components can occur.

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29
  1. Raise the vehicle. For additional information, refer to «JACKING & LIFTING»(ref-210109) .
  2. Remove the return hose from the power steering pump and drain the power steering oil reservoir.
  3. Lower the vehicle.
  4. Lift the reservoir out of the reservoir bracket.
  5. Remove the reservoir bolts from the bracket.
  6. Remove the bolts and remove the bracket.
  7. Compress the clamps and disconnect the power steering return hose and the power steering reservoir pump hose from the reservoir.
  8. Remove the power steering oil reservoir.

Installation

  1. To install, reverse the removal procedure.
  2. Fill and leak check the system. For additional information, refer to «STEERING SYSTEM-GENERAL INFORMATION»(ref-210123) .

Scheme 30

Scheme 30: Power Steering Pump

Removal and Installation

CAUTIONWhile repairing the power steering system, care should be taken to prevent the entry of contaminants or premature failure of the power steering components can occur.

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33
  1. Remove the power steering pump pulley. For additional information, refer to «POWER STEERING PUMP PULLEY»(ref-210125-S01265600142005121300000) .
  2. Disconnect the power steering reservoir pump hose and pressure line from the power steering pump. Drain the power steering oil reservoir.
  3. Remove the bolts and the pump.
  4. Remove the bolts and the pump.
  5. To install, reverse the removal procedure. Install a new power steering seal on the power steering pressure fitting by stretching the seal over the seal replacer until it is large enough to slip over the threads of the fitting.
  6. Install the power steering pump pulley. For additional information, refer to «POWER STEERING PUMP PULLEY»(ref-210125-S01265600142005121300000) .
  7. Fill and leak check the system. For additional information, refer to «STEERING SYSTEM-GENERAL INFORMATION»(ref-210123) .

Scheme 34

Scheme 34: Power Steering Pump Pulley

Scheme 35

Scheme 35: Removal and Installation
  1. Remove the engine cooling fan. For additional information, refer to «ENGINE SYSTEM-GENERAL INFORMATION»(ref-210133) .
  2. Rotate the tensioner clockwise and remove the belt from the power steering pump pulley.
  3. With the vehicle in NEUTRAL, position on a hoist.
  4. If equipped, remove the deflector shield.
  5. Using the special tool, remove the pulley. Inspect the pulley for paint marks in the web area near the hub. If there are 2 paint marks, install a new pulley. If there is no paint mark, use a paint pencil to mark the web area of the pulley near the hub.
  6. To install, reverse the removal procedure.
  7. Using the special tool, install the pulley.
CAUTIONWhile repairing the power steering system, care should be taken to prevent the entry of contaminants or premature failure of the power steering components can occur.

Scheme 36

Scheme 36

Scheme 37

Scheme 37
  1. Remove the transmission fluid cooler. For additional information, refer to «TRANSAXLE/TRANSMISSION COOLING»(ref-210157) .
  2. Disconnect the power steering hoses at the fluid cooler.
  3. Remove the 2 power steering cooler bolts and remove the power steering cooler.

Scheme 38

Scheme 38: Installation
  1. To install, reverse the removal procedure. Install the transmission cooler. For additional information, refer to «TRANSAXLE/TRANSMISSION COOLING»(ref-210157) . Fill and leak check the system. For additional information, refer to «STEERING SYSTEM-GENERAL INFORMATION»(ref-210123) .

Scheme 39

Scheme 39: Steering Gear

Note. New O-ring seals must be installed any time the lines are disconnected from the steering gear.

Scheme 40

Scheme 40: Removal and Installation

Scheme 41

Scheme 41

Scheme 42

Scheme 42

Scheme 43

Scheme 43

Scheme 44

Scheme 44

Scheme 45

Scheme 45

Scheme 46

Scheme 46
  1. Place the front wheels in the straight-ahead position and the ignition switch in the OFF position.
  2. Remove the bolt and detach the intermediate shaft from the gear.
  3. Disconnect the lines. Discard the O-ring seals.
  4. With vehicle in NEUTRAL, place on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-210109) .
  5. Remove and discard the cotter pin and nut.
  6. Using the special tool, separate the drag link.
  7. Remove the bolts and the steering gear.
  8. Remove the bolts and the steering gear.
  9. Secure the steering gear in a vise and remove the nut and lock washer.
  10. Using the special tool, remove the steering gear sector shaft arm.
  11. To install, reverse the removal procedure. Install a new high pressure hose O-ring seal (N803256-S) and a new return hose O-ring seal (N802357-S).
  12. Fill and leak check the system. For additional information, refer to «STEERING SYSTEM-GENERAL INFORMATION»(ref-210123) .

Scheme 47

Scheme 47: Steering Gear
ItemSpecification
Multi-Purpose Grease D0AZ-19584-AAESB-M1C93-A

MATERIALS
