4.6L, 5.4L, 6.8L Engines
A primary 72 ampere-hour, maintenance-free battery, mounted in the forward right-hand side of the engine compartment, is standard.
The primary battery system consists of the following components
- Primary battery
- Battery cables
- Primary battery case
The auxiliary battery option includes a remotely packaged auxiliary 75 ampere-hour, serviceable, deep cycle battery. The auxiliary battery is located on the right-hand frame rail to the rear of the B-pillar. The auxiliary battery is used to supply the trailer circuits with power when the vehicle is not running. The auxiliary battery is connected in parallel with the primary battery through the auxiliary battery relay when the engine is running. The auxiliary battery uses the same primary cable as the primary battery.
6.0L Engines
Two 78 ampere-hour, maintenance-free batteries are mounted on the right hand frame rail.
The diesel battery system consists of the following components
- Primary battery
- Secondary battery
- Battery cables
- Battery cases
Scheme 69
Ford Motor Company strongly recommends that lead-acid batteries be returned to an authorized recycling facility for disposal.
SPECIAL TOOL(S)
Scheme 70
Scheme 71
- Verify the customer concern by operating the system.
- Visually inspect for obvious signs of mechanical or electrical damage.
- If an obvious cause for a concern is found, correct the cause before proceeding to the next step.
- If the fault is not visually evident, proceed to the «PINPOINT TEST»(ref-210181-S41783494242005121400000) .
Scheme 72
Scheme 73
Scheme 74
Scheme 75
- Disconnect the primary battery ground cable.
- Disconnect the auxiliary battery frame ground. Remove the ground bolt. Pull the cable away from the frame and make sure the cable does not contact the frame.
Scheme 76
Scheme 77
- Reconnect the auxiliary battery frame ground.
- Reconnect the primary battery ground cable.
Scheme 78
- Disconnect the secondary battery ground cable.
Scheme 79
- Reconnect the secondary battery ground cable.
Battery Disconnect
| WARNING | Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery, always shield your face and protect your eyes. Always provide ventilation. Failure to follow these instructions may result in personal injury. |
| WARNING | To avoid accidental deployment and possible injury, the backup power supply must be depleted before repairing or installing any front or side air bag supplemental restraint system (SRS) components and before repairing, installing, adjusting or striking components near the front or side air bag sensors, such as doors, instrument panel, console, door latches, strikers, seats and hood latches. Failure to follow these procedures may result in personal injury. Refer to the AIR BAG RESTRAINT SYSTEMS to determine location of the front air bag sensors. To deplete the backup power supply energy, disconnect the battery ground cable and wait at least one minute. Be sure to disconnect auxiliary batteries and power supplies (if equipped). Failure to follow these instructions may result in personal injury. |
| WARNING | When lifting a battery, excessive pressure on the end walls could cause acid to spew through the vent caps, resulting in personal injury. Lift with a battery carrier or with your hands on opposite corners. Failure to follow these instructions may result in personal injury. |
| WARNING | Keep out of the reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Also, shield your eyes when working near the battery to protect against possible splashing of the acid solution. In case of acid contact with the skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention. If acid is swallowed, call a physician immediately. Failure to follow these instructions may result in personal injury. |
- Disconnect the battery ground cable.
- Disconnect the positive battery cable.
- To install, reverse the removal procedure.
