Interior Lighting: Removal & Installation Ford Econoline E150

Installation

1. To install, reverse the removal procedure.

Scheme 1

Scheme 2

Scheme 3

1. Rotate both dome/reading lamp to the stop position, then continue until both dome/reading lamps are in the vertical position.
2. Remove the dome/reading lamp screws.
3. Disconnect the dome/reading lamp electrical connector.

1. To install, reverse the removal procedure.

Scheme 4

Scheme 5

1. Remove the lens to interior lamp body (13786) (cargo lamp) screws.
2. Remove the interior lamp body (cargo lamp) screws.
3. Disconnect the electrical connector.

1. To install, reverse the removal procedure.

Scheme 6

Scheme 7

Scheme 8

1. Remove the lens to interior lamp door (13788) (cargo lamp) screws.
2. Remove the interior lamp door (cargo lamp) screws.
3. Remove the bulb sockets from the rear hi-mount lamp (13A613) and remove the interior lamp door.

1. To install, reverse the removal procedure.

Scheme 9

1. Remove the front door trim panel; refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
2. Remove the interior lamp switch. Disconnect the electrical connector. Rotate switch counterclockwise. Remove the interior lamp switch.

1. To install, reverse the removal procedure.
