Engine Controls - Acceleration Control: Removal & Installation Ford Econoline E150

Removal and Installation

Scheme 13

1. Disconnect the accelerator pedal position sensor electrical connector.
2. Remove the two bolts and slide the accelerator pedal and sensor assembly up and off the anchor bolt.
3. To install, reverse the removal procedure.

Scheme 14

Scheme 15

Scheme 16

Scheme 17

1. Remove the engine air cleaner (ACL) and the outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-210150) .
2. Depress the tab and remove the accelerator control splash shield.
3. Disconnect the cables and spring. Disconnect the accelerator cable. Disconnect the speed control cable. Disconnect and remove the spring.
4. Compress the retaining tabs and remove the cables from the bracket.
5. Remove the bolts and accelerator cable bracket.
6. To install, reverse the removal procedure.
