Engine Controls - Acceleration Control: Specifications Ford Econoline E150

Engine Control Systems 12 illustrations ~319 words

TORQUE SPECIFICATIONS

DescriptionNm
Accelerator pedal and shaft bolts (gasoline)25
Accelerator pedal and sensor assembly bolts (diesel)25
Accelerator cable bracket bolts10

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: Acceleration Control

The throttle is controlled by an accelerator cable attached to the accelerator pedal and shaft. The accelerator pedal and shaft should travel smoothly from the idle to the wide open throttle positions. Hesitation on return or prevention of return to the idle position must not occur. Surrounding components such as wiring, hoses, sound insulator and floor carpet must not contact the sliding inner member of the accelerator cable or the accelerator pedal and shaft. The throttle assembly is not adjustable.

Scheme 2

Scheme 2: Inspection and Verification
  1. Verify the customer's concern by operating the acceleration control system to duplicate the condition.
  2. Inspect to determine if any of the following mechanical concerns apply.
  3. If the inspection reveals an obvious concern that can be readily identified, repair it as required.
  4. If the concern remains after the inspection, determine the symptom(s). GO to «SYMPTOM CHART»(ref-210165-S17071848732005121400000) .

Scheme 3

Scheme 3: Symptom Chart

Scheme 4

Scheme 4: Removal and Installation

Scheme 5

Scheme 5
  1. Hold the accelerator pedal in place and disconnect the accelerator cable from the accelerator pedal and shaft.
  2. Remove the bolts and the accelerator pedal and shaft.
  3. To install, reverse the removal procedure.

Scheme 6

Scheme 6: Removal and Installation

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12
  1. Hold the accelerator pedal in place and disconnect the accelerator cable from the accelerator pedal and shaft.
  2. Remove the accelerator cable from the bulkhead. From inside the vehicle, compress the retaining tabs on the cable end and remove the cable from the bulkhead.
  3. Remove the engine air cleaner (ACL) and outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-210150) .
  4. Depress the tab and remove the accelerator control splash shield.
  5. Remove the accelerator cable from the throttle body cam.
  6. Remove the accelerator cable from the clip.
  7. Remove the accelerator cable from the clip.
  8. Compress the retaining tabs on the accelerator cable and remove the cable from the bracket.
  9. To install, reverse the removal procedure.
