Engine Emission Control: Other Ford Econoline E150

Auxiliary Emission Control Systems 7 illustrations ~242 words

Exhaust Gas Recirculation (EGR) Cooler - 6.0L Diesel

ItemSpecification
SAE 15W-40 Super Duty Motor Oil XO-15W40-QSD or equivalentWSS-M2C171-B

MATERIALS

Scheme 53

Scheme 53: Removal

Scheme 54

Scheme 54
  1. Remove the intake manifold. For additional information, refer to «ENGINE 6.0L DIESEL»(ref-213720) .
  2. Remove the exhaust gas recirculation (EGR) cooler stud bolts.
  3. Remove the bolt and the EGR cooler.
  4. Remove and discard the gasket and O-ring seal.

Scheme 55

Scheme 55: Installation

Scheme 56

Scheme 56

Scheme 57

Scheme 57
  1. Install the O-ring seal and gasket.
  2. Install the EGR cooler and stud bolts hand-tight.
  3. Install the EGR cooler bolt. EGR cooler with a M6 bolt, tighten to 13 Nm (10 lb-ft). EGR cooler with a M8 bolt, tighten to 31 Nm (23 lb-ft)
  4. Tighten the EGR cooler stud bolts.
  5. Install the intake manifold. For additional information, refer to «ENGINE 6.0L DIESEL»(ref-213720) .

Scheme 58

Scheme 58: Removal and Installation
  1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-210181) .
  2. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
  3. Remove the differential pressure feedback exhaust gas recirculation (EGR) system. Disconnect the electrical connector. Disconnect the hoses. Remove the bolts (nuts if applicable).
  4. To install, reverse the removal procedure.

Scheme 59

Scheme 59: Removal and Installation
  1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-210181) .
  2. Remove the engine cover. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-210204) .
  3. Remove the exhaust gas recirculation (EGR) vacuum regulator solenoid. Disconnect the electrical connector. Disconnect the vacuum lines. Remove the bolts (nuts if applicable).
  4. To install, reverse the removal procedure
