Automatic Transmission - 4R100: Adjustments Ford Econoline E150

Automatic Trans 3 illustrations

TRANSMISSION RANGE (TR) SENSOR ADJUSTMENT

SPECIAL TOOL(S)

Scheme 21

Scheme 21: TRANSMISSION RANGE (TR) SENSOR ADJUSTMENT
Scheme 21: TRANSMISSION RANGE (TR) SENSOR ADJUSTMENT

Scheme 22

Scheme 22: Adjustment
Scheme 22: Adjustment

Scheme 23

Scheme 23
Scheme 23
  1. Position the vehicle on a hoist. Place in NEUTRAL. For additional information, refer to «JACKING & LIFTING»(ref-210109) .
  2. Loosen the digital TR sensor bolts.
  3. Using the special tool, align the digital TR sensor.
  4. Tighten the bolts.
  5. Lower the vehicle.
