DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION
Note. Some DTCs may not apply to this model.
| DTC In General Scan Tool Mode | DTC In DRB-III Scan Tool Mode | DTC TestNo. | System Malfunction |
|---|---|---|---|
| P0100 | P0100 | 1 | Volume Airflow Sensor |
| P0105 | P0105 | 2 | Barometric Pressure Senso |
| P0110 | P0110 | 3 | Intake Air. Temp. Sensor |
| P0115 | P0115 | 4 | Engine Coolant Temp. Sensor |
| P0120 | P0120 | 5 | Throttle Position Circuit |
| P0125 | (1) | 6 | Excessive Time To Enter Closed Loop |
| P0130 | (1) | 7 | Front Oxygen Sensor |
| P0135 | (1) | 8 | Front Oxygen Sensor Heater |
| P0136 | (1) | 9 | Rear Oxygen Sensor |
| P0141 | (1) | 10 | Rear Oxygen Sensor Heater |
| P0170 | (1) | 11 | Fuel Trim Malfunction |
| P0201 | P0201 | 12 | No. 1 Injector Circuit |
| P0202 | P0202 | 12 | No. 2 Injector Circuit |
| P0203 | P0203 | 12 | No. 3 Injector Circuit |
| P0204 | P0204 | 12 | No. 4 Injector Circuit |
| P0300 | (1) | 13 | Random Misfire |
| P0301 | (1) | 14 | Cylinder No. 1 Misfire |
| P0302 | (1) | 14 | Cylinder No. 2 Misfire |
| P0303 | (1) | 14 | Cylinder No. 3 Misfire |
| P0304 | (1) | 14 | Cylinder No. 4 Misfire |
| P0325 | P0325 | 15 | Knock Sensor |
| P0335 | P0335 | 16 | Crankshaft Position Sensor |
| P0340 | P0340 | 17 | Camshaft Position Sensor |
| P0400 | (1) | 18 | EGR Malfunction |
| P0403 | (1) | 19 | EGR Solenoid |
| P0420 | (1) | 20 | Catalytic System Efficiency |
| P0440 | (1) | 21 | EVAP Emission Control System |
| P0443 | (1) | 22 | EVAP Purge Solenoid |
| P0500 | P0500 | 23 | Vehicle Speed Sensor |
| P0505 | (1) | 24 | Idle Control System |
| P0510 | (1) | 25 | Closed Throttle Position Switch |
| P0700 | (1) | 26 | Transaxle Control System |
| P0705 | (1) | 27 | Transaxle Range Sensor |
| P0710 | (1) | 28 | Transaxle Fluid Temp. Sensor |
| P1103 | (1) | 29 | Turbocharger Wastegate Actuator |
| P1104 | (1) | 30 | Turbocharger Wastegate Solenoid |
| P1105 | (1) | 31 | Fuel Pressure Solenoid |
| P1300 | P1300 | 32 | Ignition Timing Adjustment Circuit |
| P1400 | (1) | 33 | Manifold Differential Pressure Sensor |
| P1500 | P1500 | 34 | Generator FR Terminal Circuit |
| P1715 | (1) | 35 | Pulse Generator Assembly |
| P1750 | (1) | 36 | Solenoid Assembly Malfunction |
| (1) Scan tool does not display DTC when using this mode. | |||
| (1) | Scan tool does not display DTC when using this mode. |
DTC CODES IDENTIFICATION & DTC TESTS
CONNECTOR IDENTIFICATION
Note. For ECM connector terminal identification (Scheme 57)
Scheme 57
INSPECTION PROCEDURE 24 - FUEL PUMP SYSTEM OPERATION
Note. For wiring diagram, see the WIRING DIAGRAMS article.
Note. Possible causes are: defective fuel pump relay, defective fuel pump, loose connector, open or shorted fuel pump wiring circuit or defective ECM.
- Using scan tool, actuate fuel pump. Fuel pump is located in fuel tank. If fuel pump operates, go to step 4). If fuel pump does not operate, go to next step.
- Ensure ignition is off. Apply battery voltage to fuel pump check terminal. Fuel pump check terminal is a 1-pin Black connector located on firewall, near battery and contains a Black/Blue wire. see scheme 17 see scheme 17: Ignition Timing Adjustment Connector & Fuel Pump Check Terminal
- If fuel pump operates, go to step 4). If fuel pump does not operate, check fuel pump circuit. Perform INSPECTION PROCEDURE 41.
- Check fuel pump relay. See the SYSTEM/COMPONENT TESTS article. If fuel pump relay is okay, go to next step. Replace fuel pump relay if defective and recheck operation.
- Note location of fuel pump relay on passenger's side of center console, just in front of emergency brake lever. see scheme 16 Using voltmeter, check voltage between ground and terminal No. 1 (Black/Blue wire) at fuel pump relay connector while using scan tool to actuate fuel pump. Battery voltage should exist.
- If battery voltage exists, check wiring harness between fuel pump relay and fuel pump check terminal. Repair wiring harness if defective. If battery voltage does not exist, check fuel pump drive control circuit. Perform INSPECTION PROCEDURE 42.
SCAN TOOL OPERATION
- The DRB-III scan tool is used to monitor a specified component operating range. Component operating range is then compared to a normal operating range to determine if component is operating properly. When using DRB-III scan tool, scan tool can may be used in 2 modes, general scan tool mode and DRB-III scan tool mode.
- Specified scan tool mode must be used on scan tool when monitoring specified component. See SCAN TOOL MODE OPERATION table.
- Once proper scan tool mode operation is determined, use scan tool to monitor specified component operation under specified operating condition. See SCAN TOOL SERVICE DATA SPECIFICATIONS table.
- Specified component operating range should be within specified normal operating range. See SCAN TOOL SERVICE DATA SPECIFICATIONS table. If component operating range is not within normal operating range, perform specified Diagnostic Trouble Code (DTC) test or specified trouble symptom inspection procedure (if available). See SCAN TOOL SERVICE DATA SPECIFICATIONS table.
- The DTC TESTS are listed under «SELF-DIAGNOSTIC TESTS»(ref-11311-S36467877102000111300000) . Trouble symptom inspection procedures listed under «TROUBLE SYMPTOMS»(ref-11311-S11493446212000111300000) .
| Component Inspection | General Scan Tool Mode | DRB-III Scan Tool Mode | |
|---|---|---|---|
| A/C Compressor Clutch Relay | No | Yes | |
| A/C Switch | No | Yes | |
| Barometric Pressure Sensor | No | Yes | |
| Calculation Load | Yes | No | |
| Closed Throttle Position | |||
| Switch | No | Yes | |
| Cranking Signal | |||
| (Ign. Switch ST Signal) | No | Yes | |
| Crankshaft Position Sensor | Yes | Yes | |
| Engine Coolant Temp. Sensor | Yes | Yes | |
| Front Oxygen Sensor | Yes | Yes | |
| Fuel Control Condition | Yes | No | |
| Idle Air Control Motor | No | Yes | |
| Ignition Coil & Ignition | |||
| Power Transistor | No | Yes | |
| Ign Timing Adjustment Mode | Yes | No | |
| Injectors | No | Yes | |
| Intake Air Temp. Sensor | Yes | Yes | |
| Long Term Fuel Compensation | Yes | No | |
| Manifold Differential | |||
| Pressure Sensor | Yes | Yes | |
| Park/Neutral Switch (A/T) | No | Yes | |
| Power Steering Pressure Switch | No | Yes | |
| Power Supply Voltage | No | Yes | |
| Rear Oxygen Sensor | Yes | Yes | |
| Short Term Fuel Compensation | Yes | No | |
| Throttle Position Sensor | Yes | Yes | |
| Vehicle Speed Sensor | Yes | No | |
| Volume Airflow Sensor | Yes | Yes | |
SCAN TOOL MODE OPERATION
SCAN TOOL SERVICE DATA SPECIFICATIONS (1 of 2). Scheme 58
SCAN TOOL SERVICE DATA SPECIFICATIONS (2 of 2). Scheme 59
- The DRB-III scan tool is used perform actuator test on a specified component to determine if the component operates correctly. Use scan tool to actuate specified component under specified operating condition. See «SCAN TOOL ACTUATOR TESTS»(ref-11311-S36429429792000111300000) table.
- Specified component normal operation should be as described. See «SCAN TOOL ACTUATOR TESTS»(ref-11311-S36159689142000111300000) table. If component does not operate correctly, perform specified Diagnostic Trouble Code (DTC) test or specified trouble symptom inspection procedure (if available). See «SCAN TOOL ACTUATOR TESTS»(ref-11311-S36159689142000111300000) table.
- The DTC TESTS are listed under «SELF-DIAGNOSTIC TESTS»(ref-11311-S36467877102000111300000) . Trouble symptom inspection procedures listed under «TROUBLE SYMPTOMS»(ref-11311-S11493446212000111300000) .
| Component | Specified Operating Condition | Normal Operating Range | DTC Test | Inspec. Procedure |
|---|---|---|---|---|
| Injector (1) | With Engine Idling, Use Scan Tool To Cut Fuel To Injector | Idle Speed Should Drop | 12 | |
| Fuel Pump (1) | Engine Cranking & Fuel Pump Energized | (2) | 24 | |
| EVAP | Ign. On & Solenoid Actuated Purge Solenoid | Solenoid Should Click | 22 | |
| Fuel Pressure Solenoid | Ign. On & Solenoid Actuated | Solenoid Should Click | 31 | |
| EGR Solenoid | Ign. On & Solenoid Actuated | Solenoid Should Click | 19 | |
| Turbo- charger WastegateSolenoid | Ign. On & Solenoid Actuated | Solenoid Should Click | 30 | |
| Radiator Cooling Fan On High & A/C Condenser Cooling Fan On High | Ign. On, A/C Switch ON & Fans Actuated | Fans Operate At High Speed | 29 | |
| Radiator Cooling Fan On High & A/C Condenser Cooling Fan On Low | Ign. On, A/C Switch ON & Fans Actuated | Fans Operate At Low Speed | 29 | |
| (1) Check with engine at normal operating temperature. (2) Pulse should be felt on fuel return hose when slightly pinching fuel return hose. Operating sound should be heard at fuel pump in the fuel tank. | ||||
| (1) | Check with engine at normal operating temperature. |
| (2) | Pulse should be felt on fuel return hose when slightly pinching fuel return hose. Operating sound should be heard at fuel pump in the fuel tank. |
SCAN TOOL ACTUATOR TESTS
