DTC P0108: MAP SENSOR CIRCUIT HIGH Dodge Pickup R1500

Testing & Diagnostics 2 illustrations

Note. For component location, see COMPONENT LOCATIONS . For connector identification, see CONNECTOR IDENTIFICATION . For circuit identification and wiring diagram, see WIRING DIAGRAMS . If Powertrain Control Module (PCM) is replaced, PCM must be reprogrammed. See PROGRAMMING .

For testing procedures (Scheme 426)and (Scheme 427).

Scheme 426

Scheme 426: DTC P0108: MAP SENSOR CIRCUIT HIGH

Scheme 426: DTC P0108: MAP SENSOR CIRCUIT HIGH

Scheme 427

Scheme 427

Scheme 427
