CYLINDER COMBUSTION PRESSURE LEAKAGE

The combustion pressure leakage test provides an accurate means for determining engine condition.

Combustion pressure leakage testing will detect

1. Exhaust and intake valve leaks (improper seating).
2. Leaks between adjacent cylinders or into water jacket.
3. Any causes for combustion/compression pressure loss.

1. Check the coolant level and fill as required. DO NOT install the radiator cap.
2. Start and operate the engine until it attains normal operating temperature, then turn the engine OFF.
3. Remove the spark plugs.
4. Remove the oil filler cap.
5. Remove the air cleaner.
6. Calibrate the tester according to the manufacturer's instructions. The shop air source for testing should maintain 483 kPa (70 psi) minimum, 1,379 kPa (200 psi) maximum and 552 kPa (80 psi) recommended.
7. Perform the test procedures on each cylinder according to the tester manufacturer's instructions. Set piston of cylinder to be tested at TDC compression. While testing, listen for pressurized air escaping through the throttle body, tailpipe and oil filler cap opening. Check for bubbles in the radiator coolant.

All gauge pressure indications should be equal, with no more than 25% leakage.

FOR EXAMPLE: At 552 kPa (80 psi) input pressure, a minimum of 414 kPa (60 psi) should be maintained in the cylinder.

Refer to CYLINDER COMBUSTION PRESSURE LEAKAGE DIAGNOSIS CHART .

CYLINDER COMBUSTION PRESSURE LEAKAGE DIAGNOSIS CHART

CYLINDER COMPRESSION PRESSURE

The results of a cylinder compression pressure test can be utilized to diagnose several engine malfunctions.

Ensure the battery is completely charged and the engine starter motor is in good operating condition. Otherwise the indicated compression pressures may not be valid for diagnosis purposes.

1. Clean the spark plug recesses with compressed air.
2. Remove the spark plugs.
3. Secure the throttle in the wide-open position.
4. Disable the fuel system (Refer to «FUEL DELIVERY - GAS»(ref-306144-S40891717032008120900000) ).
5. Remove the ASD relay. Refer to «REMOVAL»(ref-306179-S11629687262008120900000) .
6. Insert a compression pressure gauge and rotate the engine with the engine starter motor for three revolutions.
7. Record the compression pressure on the 3rd revolution. Continue the test for the remaining cylinders.
8. See «SPECIFICATIONS»(ref-306142-S09472127992008120900000) for the correct engine compression pressures.

REPAIR DAMAGED OR WORN THREADS

Damaged or worn threads can be repaired. Essentially, this repair consists of

1. Drilling out worn or damaged threads.
2. Tapping the hole with a special Heli-Coil Tap, or equivalent.
3. Installing an insert into the tapped hole to bring the hole back to its original thread size.

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. Disconnect the battery negative cable.
2. Remove hood. Mark hood hinge location for reinstallation.
3. Remove air cleaner assembly.
4. Remove radiator core support bracket.
5. Remove fan shroud with electric fan assembly.
6. Remove mechanical cooling fan.
7. Remove drive belt. NOTE: It is NOT necessary to discharge the A/C system to remove the engine.
8. Remove A/C compressor (2) and secure away from engine with lines attached. 1 - LOWER BOLTS 2 - REAR BOLT 3 - GENERATOR NOTE: Do NOT remove the phenolic pulley from the P/S pump. It is not required for P/S pump removal.
9. Remove power steering pump with lines attached and secure away from engine.
10. Drain cooling system.
11. Remove coolant bottle.
12. Disconnect the heater hoses from the engine.
13. Disconnect heater hoses from heater core and remove hose assembly.
14. Remove generator (3) and secure away from engine.
15. Disconnect throttle and speed control cables.
16. Remove upper radiator hose from engine.
17. Remove lower radiator hose from engine. 1 - CRANKSHAFT POSITION SENSOR 2 - CYLINDER HEAD COVER 3 - CAMSHAFT POSITION SENSOR 4 - RIGHT SIDE CYLINDER BLOCK
18. Disconnect the engine wiring harness at the following points: Intake air temperature (IAT) sensor Fuel Injectors Electronic Throttle Control (ETC) Idle Air Control (IAC) Motor Engine Oil Pressure Switch Engine Coolant Temperature (ECT) Sensor Manifold Absolute Pressure MAP) Sensor Camshaft Position (CMP) Sensor Coil Over Plugs Crankshaft Position Sensor (2)
19. Remove coil over plugs.
20. Release fuel rail pressure.
21. Remove fuel rail and secure away from engine. 1 - NUT 2 - GROUND STRAP 3 - BRAKE BOOSTER NOTE: It is not necessary to release the quick connect fitting from the fuel supply line for engine removal.
22. Remove the PCV hose.
23. Remove the breather hoses.
24. Remove the vacuum hose for the power brake booster.
25. Disconnect knock sensors.
26. Disconnect the engine to body ground straps (2) at the cowl.
27. Remove intake manifold.
28. Remove engine oil dipstick tube.
29. Install Engine Lifting Fixture 8427. NOTE: Recheck bolt torque for engine lift plate before removing engine.
30. Secure the left and right engine wiring harnesses away from engine.
31. Raise vehicle.
32. Disconnect oxygen sensor wiring.
33. Disconnect the engine block heater power cable, if equipped.
34. Disconnect the front propeller shaft at the front differential and secure out of way. NOTE: It is necessary to disconnect the front propeller shaft for access to the starter and left side exhaust flange.
35. Remove the ground straps from the left and right side of the block.
36. Disconnect the right and left exhaust pipes at the manifolds and from the crossover, and remove from the vehicle. NOTE: The exhaust clamps at the manifolds cannot be reused. New clamps must be used or leaks may occur. NOTE: For manual transmission vehicles, the transmission must be removed from the vehicle, before the engine can be removed. The manual transmission will contact the floorpan before the engine clears the motor mounts, so it must be removed.
37. Remove the starter. Refer to «REMOVAL»(ref-306163-S04724120662008120900000) . 1 - BOLT 2 - BOLT 3 - BOLT
38. Remove the structural cover retaining bolts (1), and cover. See «REMOVAL»(ref-306142-S09090662322008120900000) .
39. Remove torque convertor bolts, and mark location for reassembly.
40. Remove transmission bellhousing to engine bolts.
41. Loosen left and right engine mount thru bolts. NOTE: It is not necessary to completely remove engine mount thru bolts, for engine removal.
42. Lower the vehicle.
43. Support the transmission with a suitable jack.
44. Connect a suitable engine hoist to the engine lift plate.
45. Remove engine from vehicle.

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. Position the engine in the vehicle.
2. Install both left and right side engine mounts onto engine.
3. Raise the vehicle.
4. Install the transmission bellhousing to engine mounting bolts. Tighten the bolts to 41 N.m (30 ft. lbs.).
5. Tighten the engine mount thru bolts.
6. Install the torque convertor bolts.
7. Connect the ground straps on the left and right side of the engine.
8. Install the starter (2). Refer to «INSTALLATION»(ref-306163-S19299772542008120900000) . 1 - BOLT 2 - BOLT 3 - BOLT
9. Install the engine block heater power cable, if equipped. CAUTION: The structural cover requires a specific torque sequence. Failure to follow this sequence may cause severe damage to the cover.
10. Install the structural cover, and torque bolts (1). See «INSTALLATION»(ref-306142-S05508443952008120900000) . NOTE: New clamps must be used on exhaust manifold flanges. Failure to use new clamps may result in exhaust leaks.
11. Install the left and right exhaust pipes.
12. Connect the left and right oxygen sensors.
13. Lower vehicle. 1 - NUT 2 - GROUND STRAP 3 - BRAKE BOOSTER
14. Connect the engine to body ground straps at the cowl.
15. Remove the engine lift plate.
16. Connect the knock sensors.
17. Install the intake manifold. See «INSTALLATION»(ref-306142-S30306992222008120900000) .
18. Install the engine oil dipstick tube.
19. Install the power brake booster vacuum hose.
20. Install the breather hoses.
21. Install the PCV hose.
22. Install the fuel rail.
23. Install the coil over plugs. 1 - CRANKSHAFT POSITION SENSOR 2 - CYLINDER HEAD COVER 3 - CAMSHAFT POSITION SENSOR 4 - RIGHT SIDE CYLINDER BLOCK
24. Connect the engine wiring harness at the following points: Intake air temperature (IAT) sensor Fuel Injectors Electronic Throttle Control (ETC) Idle Air Control (IAC) Motor Engine Oil Pressure Switch Engine Coolant Temperature (ECT) Sensor Manifold Absolute Pressure MAP) Sensor Camshaft Position (CMP) Sensor Coil Over Plugs Crankshaft Position Sensor (2) 1 - LOWER BOLTS 2 - REAR BOLT 3 - GENERATOR
25. Connect lower radiator hose.
26. Connect upper radiator hose.
27. Connect throttle and speed control cables.
28. Install the heater hose assembly.
29. Install coolant recovery bottle.
30. Install the power steering pump.
31. Install the generator (3). Refer to «INSTALLATION»(ref-306161-S23448537052008120900000) .
32. Install the A/C compressor (2).
33. Install the drive belt. Refer to «INSTALLATION»(ref-306154-S38527570572008120900000) .
34. Install the fan shroud with the electric fan assembly. Refer to «INSTALLATION»(ref-306154-S41209272742008120900000) .
35. Install the radiator core support bracket.
36. Install the air cleaner assembly.
37. Refill the engine cooling system.
38. Install the hood.
39. Check and fill engine oil.
40. Connect the battery negative cable.
41. Start the engine and check for leaks.

GENERAL SPECIFICATIONS

CYLINDER BLOCK

PISTONS

PISTON PINS

PISTON RINGS

CONNECTING RODS

CRANKSHAFT

CAMSHAFT

VALVE TIMING

VALVES

VALVE SPRING

CYLINDER HEAD

OIL PUMP

OIL PRESSURE

VALVE GUIDES

The valve guides are made of powered metal and are pressed into the cylinder head. The guides are not replaceable or serviceable, and valve guide reaming is not recommended. If the guides are worn beyond acceptable limits, replace the cylinder heads.

CYLINDER HEAD GASKET

A cylinder head gasket leak can be located between adjacent cylinders or between a cylinder and the adjacent water jacket.

Possible indications of the cylinder head gasket leaking between adjacent cylinders are

1. Loss of engine power
2. Engine misfiring
3. Poor fuel economy

Possible indications of the cylinder head gasket leaking between a cylinder and an adjacent water jacket are

1. Engine overheating
2. Loss of coolant
3. Excessive steam (white smoke) emitting from exhaust
4. Coolant foaming

COOLING SYSTEM TESTER METHOD

Install Cooling System Tester 7700 or equivalent to pressure cap neck. Start the engine and observe the tester's pressure gauge. If gauge pulsates with every power stroke of a cylinder a combustion pressure leak is evident.

HYDRAULIC LASH ADJUSTER

A tappet-like noise may be produced from several items. Check the following items.

1. Engine oil level too high or too low. This may cause aerated oil to enter the adjusters and cause them to be spongy.
2. Insufficient running time after rebuilding cylinder head. Low speed running up to 1 hour may be required.
3. Turn engine off and let set for a few minutes before restarting. Repeat this several times after engine has reached normal operating temperature.
4. Low oil pressure.
5. The oil restrictor in cylinder head gasket or the oil passage to the cylinder head is plugged with debris.
6. Air ingested into oil due to broken or cracked oil pump pick up.
7. Worn valve guides.
8. Rocker arm ears contacting valve spring retainer.
9. Rocker arm loose, adjuster stuck or at maximum extension and still leaves lash in the system.
10. Oil leak or excessive cam bore wear in cylinder head.
11. Faulty lash adjuster. Check lash adjusters for sponginess while installed in cylinder head and cam on camshaft at base circle. Depress part of rocker arm over adjuster. Normal adjusters should feel firm when pressed quickly. When pressed very slowly, lash adjusters should collapse. Remove suspected lash adjusters, and replace. Before installation, make sure adjusters are full of oil. This can be verified by little plunger travel when lash adjuster is depressed quickly.

Scheme 49

Scheme 50

Scheme 51

Scheme 52

1. Disconnect the negative cable from the battery.
2. Raise the vehicle on a hoist.
3. Disconnect the exhaust pipe at the left side exhaust manifold.
4. Drain the engine coolant. Refer to «COOLING»(ref-306154) article.
5. Lower the vehicle.
6. Remove the intake manifold. Refer to «REMOVAL»(ref-306142-S16054353982008120900000).
7. Remove the cylinder head cover. Refer to «REMOVAL»(ref-306142-S12051049862008120900000) for left side or «REMOVAL»(ref-306142-S07155423102008120900000) for right side.
8. Remove the fan shroud and fan blade assembly. Refer to «COOLING»(ref-306154) article.
9. Remove accessory drive belt. Refer to «COOLING»(ref-306154) article.
10. Remove the power steering pump and set aside.
11. Rotate the crankshaft until the damper timing mark is aligned with TDC indicator mark (2). (Scheme 49) 1 - LEFT CYLINDER HEAD 2 - RIGHT CYLINDER HEAD
12. Verify the V6 mark on the camshaft sprocket is at the 12 o'clock position. (Scheme 50) Rotate the crankshaft one turn if necessary.
13. Remove the crankshaft damper. See «REMOVAL»(ref-306142-S14186681422008120900000).
14. Remove the timing chain cover. See «REMOVAL»(ref-306142-S29598169092008120900000). 1 - SPECIAL TOOL 8429 2 - CAMSHAFT CHAIN 3 - CRANKSHAFT TIMING GEAR
15. Lock the secondary timing chains to the idler sprocket using Secondary Camshaft Chain Holder 8429 (1). (Scheme 51) NOTE: Mark the secondary timing chain prior to removal to aid in installation.
16. Mark the secondary timing chain, one link on each side of the V6 mark on the camshaft drive gear.
17. Remove the left side secondary chain tensioner. 1 - RIGHT CYLINDER HEAD ACCESS PLUG 2 - LEFT CYLINDER HEAD ACCESS PLUG
18. Remove the cylinder head access plug (1) (2). (Scheme 52)
19. Remove the left side secondary chain guide.
20. Remove the retaining bolt and the camshaft drive gear. CAUTION: Do not allow the engine to rotate. Severe damage to the valve train can occur. CAUTION: Do not overlook the four smaller bolts at the front of the cylinder head. Do not attempt to remove the cylinder head without removing these four bolts. NOTE: The cylinder head is attached to the cylinder block with twelve bolts.
21. Remove the cylinder head retaining bolts.
22. Remove the cylinder head and gasket. Discard the gasket.

Scheme 53

To ensure engine gasket sealing, proper surface preparation must be performed, especially with the use of aluminum engine components. (Scheme 53) See STANDARD PROCEDURE.

Scheme 54

Note. The cylinder head bolts are tightened using a torque plus angle procedure. The bolts must be examined BEFORE reuse. If the threads are necked down the bolts should be replaced.

Necking can be checked by holding a straight edge against the threads. If all the threads do not contact the scale (1), the bolt should be replaced. (Scheme 54)

Scheme 55

1. Clean the cylinder head and cylinder block mating surfaces. see scheme 54
2. Position the new cylinder head gasket on the locating dowels. CAUTION: When installing cylinder head, use care not damage the tensioner arm or the guide arm.
3. Position the cylinder head onto the cylinder block. Make sure the cylinder head seats fully over the locating dowels. * - INDICATES SEALANT ON THREADS NOTE: The four smaller cylinder head mounting bolts require sealant to be added to them before installing. Failure to do so may cause leaks.
4. Lubricate the cylinder head bolt threads with clean engine oil and install the eight M11 bolts.
5. Coat the four M8 cylinder head bolts with Mopar® Lock and Seal Adhesive then install the bolts. NOTE: The cylinder head bolts are tightened using an angle torque procedure, however, the bolts are not a torque-to-yield design.
6. Tighten the bolts in sequence using the following steps and torque values: Step 1: Tighten bolts 1-8, 27 N.m (20 ft. lbs.). Step 2: Verify that bolts 1-8, all reached 27 N.m (20 ft. lbs.), by repeating step 1 without loosening the bolts. Tighten bolts 9 through 12 to 14 N.m (10 ft. lbs.). Step 3: Tighten bolts 1-8, 90 degrees. (Scheme 55) Step 4: Tighten bolts 1-8, 90 degrees, again. Tighten bolts 9-12, 26 N.m (19 ft. lbs.)
7. Position the secondary chain onto the camshaft drive gear, making sure one marked chain link is on either side of the V6 mark on the gear then using Camshaft Holder 8428, position the gear onto the camshaft. CAUTION: Remove excess oil from camshaft sprocket retaining bolt before reinstalling bolt. Failure to do so may cause over-torqueing of bolt resulting in bolt failure.
8. Install the camshaft drive gear retaining bolt.
9. Install the left side secondary chain guide.
10. Install the cylinder head access plug.
11. Reset and Install the left side secondary chain tensioner.
12. Remove Secondary Camshaft Chain Holder 8429.
13. Install the timing chain cover.
14. Install the crankshaft damper. Tighten damper bolt 175 N.m (130 Ft. Lbs.)
15. Install the power steering pump.
16. Install the fan blade assembly and fan shroud.
17. Install the cylinder head cover.
18. Install the intake manifold.
19. Refill the cooling system
20. Raise the vehicle.
21. Install the exhaust pipe onto the left exhaust manifold.
22. Lower the vehicle.
23. Connect the negative cable to the battery.
24. Start the engine and check for leaks.

CAMSHAFT - LEFT

The camshafts consist of powdered metal steel lobes which are sinter-bonded to a steel tube. Four bearing journals are machined into the camshaft. Camshaft end play is controlled by two thrust walls that border the nose piece journal.

Scheme 56

Scheme 57

1. Remove cylinder head cover. See «REMOVAL»(ref-306142-S12051049862008120900000). 1 - SPECIAL TOOL 8379 2 - CAMSHAFT SPROCKET 3 - CAMSHAFT SPROCKET BOLT 4 - CYLINDER HEAD
2. Set engine to TDC cylinder #1, camshaft sprocket V6 marks at the 12 o'clock position.
3. Mark one link on the secondary timing chain on both sides of the V6 mark on the camshaft sprocket to aid in installation. CAUTION: Do not hold or pry on the camshaft target wheel (Located on the right side camshaft sprocket) for any reason. Severe damage will occur to the target wheel resulting in a vehicle no start condition.
4. Loosen but DO NOT remove the camshaft sprocket retaining bolt. Leave the bolt snug against the sprocket. NOTE: The timing chain tensioners must be secured prior to removing the camshaft sprockets. Failure to secure tensioners will allow the tensioners to extend, requiring timing chain cover removal in order to reset tensioners. CAUTION: Do not force wedge past the narrowest point between the chain strands. Damage to the tensioners may occur.
5. Position the Wedge Locking Tool 8379 between the timing chain strands, tap the tool to securely wedge the timing chain against the tensioner arm and guide. (Scheme 56) 1 - Camshaft hole 2 - Special Tool 8428
6. Hold the camshaft with Camshaft Holder 8428 while removing the camshaft sprocket bolt and sprocket. (Scheme 57)
7. Using the Camshaft Holder 8428, gently allow the camshaft to rotate 5° clockwise until the camshaft is in the neutral position (no valve load).
8. Starting at the outside working inward, loosen the camshaft bearing cap retaining bolts 1/2 turn at a time. Repeat until all load is off the bearing caps. CAUTION: DO NOT STAMP OR STRIKE THE CAMSHAFT BEARING CAPS. SEVERE DAMAGE WILL OCCUR TO THE BEARING CAPS. NOTE: When the camshaft is removed the rocker arms may slide downward, mark the rocker arms before removing camshaft.
9. Remove the camshaft bearing caps and the camshaft.

Scheme 58

1. Lubricate camshaft journals with clean engine oil. NOTE: Position the left side camshaft so that the camshaft sprocket dowel is near the 1 o'clock position, This will place the camshaft at the neutral position easing the installation of the camshaft bearing caps.
2. Position the camshaft into the cylinder head.
3. Install the camshaft bearing caps, hand tighten the retaining bolts. NOTE: Caps should be installed so that the stamped numbers on the caps are in numerical order, (1 through 4) from the front to the rear of the engine. All caps should be installed so that the stamped arrows on the caps point toward the front of the engine.
4. Working in 1/2 turn increments, tighten the bearing cap retaining bolts starting with the middle cap working outward.
5. Tighten the camshaft bearing cap retaining bolts to 11 N.m (100 in. lbs.). (Scheme 58)
6. Position the camshaft drive gear into the timing chain aligning the V6 mark between the two marked chain links (Two links marked during removal).
7. Using the Camshaft Holder 8428, rotate the camshaft until the camshaft sprocket dowel is aligned with the slot in the camshaft sprocket. Install the sprocket onto the camshaft. CAUTION: Remove excess oil from camshaft sprocket bolt. Failure to do so can cause bolt over-torque resulting in bolt failure.
8. Remove excess oil from bolt, then install the camshaft sprocket retaining bolt and hand tighten.
9. Remove Wedge Locking Tool 8379.
10. Using the Spanner Wrench 6958 with adapter pins 8346, tighten the camshaft sprocket retaining bolt to 122 N.m (90 ft. lbs.).
11. Install the cylinder head cover. See «INSTALLATION»(ref-306142-S22568602322008120900000).

Scheme 59

The cylinder head covers (1,2) are made of glass re-enforced thermoset plastic, and are not interchangeable from side-to-side. (Scheme 59)

Scheme 60

1. Disconnect negative cable from battery.
2. Remove the resonator assemble and air inlet hose.
3. Disconnect injector connectors and unclip the injector harness.
4. Route injector harness in front of cylinder head cover.
5. Disconnect the left side breather tube and remove the breather tube.
6. Remove the cylinder head cover mounting bolts (1).
7. Remove cylinder head cover (1) and gasket. (Scheme 60)

Note. The gasket may be used again, providing no cuts, tears, or deformation has occurred.

CYLINDER HEAD COVER

Note. The gasket may be used again, provided no cuts, tears, or deformation has occurred.

1. Clean cylinder head cover and both sealing surfaces. Inspect and replace gasket as necessary.
2. Install cylinder head cover (2). see scheme 61
3. Tighten cylinder head cover bolts (1) and double ended studs to 12 N.m (105 in. lbs.).
4. Install left side breather and connect breather tube.
5. Connect injector electrical connectors and injector harness retaining clips.
6. Install the resonator and air inlet hose.
7. Connect negative cable to battery.

VALVES

The valves are made of heat resistant steel and have chrome plated stems to prevent scuffing. Each valve is actuated by a roller rocker arm which pivots on a stationary lash adjuster. All valves use three bead lock keepers to retain the springs and promote valve rotation.

Scheme 61

Note. Valve seats that are worn or burned can be reworked, provided that correct angle and seat width are maintained. Otherwise the cylinder head must be replaced.

Note. When refacing valves (4) and valve seats, it is important that the correct size valve guide pilot be used for reseating stones. A true and complete surface must be obtained.

1. Using a suitable dial indicator measure the center of the valve seat. Total run out must not exceed 0.051 mm (0.002 in).
2. Apply a small amount of Prussian blue to the valve seat, insert the valve into the cylinder head, while applying light pressure on the valve rotate the valve. Remove the valve and examine the valve face. If the blue is transferred below the top edge of the valve face, lower the valve seat using a 15 degree stone. If the blue is transferred to the bottom edge of the valve face, raise the valve seat using a 65 degree stone.
3. When the seat is properly positioned the width of the intake seat must be 1.75 - 2.36 mm (0.0689 - 0.0928 in.) and the exhaust seat must be 1.71 - 2.32 mm (0.0673 - 0.0911 in.).
4. Check the valve spring (6) installed height after refacing the valve and seat. The installed height for both intake and exhaust valve springs must not exceed 40.74 mm (1.6039 in.)
5. The valve seat and valve face must maintain a face angle of 44.5 - 45° angle.

Scheme 62

Note. The cylinder heads must be removed in order to perform this procedure.

1. Remove rocker arms and lash adjusters. See «REMOVAL»(ref-306142-S33933368352008120900000) .
2. Remove the camshaft bearing caps and the camshaft. NOTE: All valve springs and valves are removed in the same manner; this procedure only covers one valve and valve spring.
3. Using Valve Spring Compressor C-3422-B or C-3422-C and Adapter 8519, compress the valve spring. NOTE: It may be necessary to tap the top of the valve spring to loosen the spring retainers locks enough to be removed.
4. Remove the two spring retainer lock halves. NOTE: the valve spring is under tension use care when releasing the valve spring compressor.
5. Remove the valve spring compressor.
6. Remove the spring retainer, and the spring. NOTE: Check for sharp edges on the keeper grooves. Remove any burrs from the valve stem before removing the valve from the cylinder head.
7. Remove the valve from the cylinder head. NOTE: The valve stem seals are common between intake and exhaust.
8. Remove the valve stem seal. Mark the valve for proper installation.

Scheme 63

Note. Whenever the valves are removed from the cylinder head it is recommended that the valve springs be inspected and tested for reuse.

Inspect the valve springs for physical signs of wear or damage. Turn table of tool C-647 (1) until surface is in line with the 40.12 mm (1.579 in.) mark on the threaded stud and the zero mark on the front. Place spring over the stud on the table and lift compressing lever to set tone device. Pull on torque wrench until a Ping is heard. Take reading on torque wrench at this instant. Multiply this reading by two. This will give the spring load at test length. Fractional measurements are indicated on the table for finer adjustments. Refer to SPECIFICATIONS to obtain specified height and allowable tensions. Replace any springs that do not meet specifications.

Scheme 64

Scheme 65

1. coat the valve stem with clean engine oil and insert it into the cylinder head.
2. Install the valve stem seal. make sure the seal is fully seated and that the garter spring at the top of the seal is intact.
3. Install the spring and the spring retainer.
4. Using the valve spring compressor, compress the spring and install the two valve spring retainer halves.
5. Release the valve spring compressor and make sure the two spring retainer halves and the spring retainer are fully seated. (Scheme 64)
6. Lubricate the camshaft journal with clean engine oil then Position the camshaft (with the sprocket dowel on the left camshaft at 11 o'clock and the right camshaft at 12 o'clock), then position the camshaft bearing caps.
7. Install the camshaft bearing cap retaining bolts. Tighten the bolts 9-13 N.m (100 in. lbs.) in 1/2 turn increments in the sequence (Scheme 65)
8. Position the hydraulic lash adjusters and rocker arms. See «INSTALLATION»(ref-306142-S12648860592008120900000).

VALVE ROCKER ARM

The rocker arms are steel stampings with an integral roller bearing. The rocker arms incorporate a 2.8 mm (0.5 inch) oil jet hole in the lash adjuster socket for roller and camshaft lubrication.

Scheme 66

Note. Disconnect the battery negative cable to prevent accidental starter engagement.

1. Remove the cylinder head cover. See «REMOVAL»(ref-306142-S12051049862008120900000).
2. For rocker arm removal on cylinder No. 4, Rotate the crankshaft until cylinder No. 1 is at BDC intake stroke.
3. For rocker arm removal on cylinder No. 1, Rotate the crankshaft until cylinder No. 1 is at BDC combustion stroke.
4. For rocker arm removal on cylinders No. 3 and No. 5, Rotate the crankshaft until cylinder No. 1 is at TDC exhaust stroke.
5. For rocker arm removal on cylinders No. 2 and No. 6, Rotate the crankshaft until cylinder No. 1 is at TDC ignition stroke.
6. Using the Rocker Arm Remover/Installer 8516A (2), press downward on the valve spring, remove rocker arm. (Scheme 66)

VALVE GUIDE SEAL

The valve guide seals are made of rubber and incorporate an integral steel valve spring seat. The integral garter spring maintains consistent lubrication control to the valve stems.

VALVE SPRINGS

The valve springs are made from high strength chrome silicon steel. The springs are NOT common for intake and exhaust applications. The exhaust spring has an external damper. The valve spring seat is integral with the valve stem seal, which is a positive type seal to control lubrication.

1. Remove the cylinder head cover. See «REMOVAL»(ref-306142-S12051049862008120900000) .
2. Using the Valve Spring Remover/Installer 8516A, remove the rocker arms and the hydraulic lash adjusters.
3. Remove the spark plug for the cylinder the valve spring and seal are to be removed from.
4. Apply shop air to the cylinder to hold the valves in place when the spring is removed. NOTE: All six valve springs and seals are removed in the same manner; this procedure only covers one valve seal and valve spring.
5. Using the Valve Spring Compressor 8387, compress the valve spring. NOTE: It may be necessary to tap the top of the valve spring to loosen the spring retainers locks enough to be removed.
6. Remove the two spring retainer lock halves. NOTE: the valve spring is under tension use care when releasing the valve spring compressor.
7. Remove the valve spring compressor. NOTE: The valve springs are NOT common between intake and exhaust.
8. Remove the spring retainer, and the spring.
9. Remove the valve stem seal.

Note. The valve stem seals are common between intake and exhaust.

Note. All six valve springs and seals are removed in the same manner; this procedure only covers one valve seal and valve spring.

1. Apply shop air to the cylinder to hold the valves in place while the spring is installed. NOTE: The valve stem seals are common between intake and exhaust.
2. Install the valve stem seal. NOTE: The valve springs are NOT common between intake and exhaust.
3. Install the spring retainer, and the spring.
4. Using the Valve Spring Compressor 8387, compress the valve spring.
5. Install the two spring retainer lock halves. NOTE: the valve spring is under tension use care when releasing the valve spring compressor.
6. Remove the valve spring compressor.
7. Disconnect the shop air to the cylinder.
8. Install the spark plug for the cylinder the valve spring and seal was installed on.
9. Using Valve Spring Remover/Installer 8516, install the rocker arms and the hydraulic lash adjusters.
10. Install the cylinder head cover. See «INSTALLATION»(ref-306142-S22568602322008120900000) .

CYLINDER HEAD

The cylinder heads are made of an aluminum alloy. The cylinder head features two valves per cylinder with pressed in powdered metal valve guides. The cylinder heads also provide enclosures for the timing chain drain, necessitating unique left and right cylinder heads.

The valve guides are made of powered metal and are pressed into the cylinder head. The guides are not replaceable or serviceable, and valve guide reaming is not recommended. If the guides are worn beyond acceptable limits, replace the cylinder heads.

The valves are made of heat resistant steel and have chrome plated stems to prevent scuffing. Each valve is actuated by a roller rocker arm which pivots on a stationary lash adjuster. All valves use three bead lock keepers to retain the springs and promote valve rotation.

A cylinder head gasket leak can be located between adjacent cylinders or between a cylinder and the adjacent water jacket.

Possible indications of the cylinder head gasket leaking between adjacent cylinders are

1. Loss of engine power
2. Engine misfiring
3. Poor fuel economy

Possible indications of the cylinder head gasket leaking between a cylinder and an adjacent water jacket are

1. Engine overheating
2. Loss of coolant
3. Excessive steam (white smoke) emitting from exhaust
4. Coolant foaming

Install Cooling System Tester 7700 or equivalent to pressure cap neck. Start the engine and observe the tester's pressure gauge. If gauge pulsates with every power stroke of a cylinder a combustion pressure leak is evident.

A tappet-like noise may be produced from several items. Check the following items.

1. Engine oil level too high or too low. This may cause aerated oil to enter the adjusters and cause them to be spongy.
2. Insufficient running time after rebuilding cylinder head. Low speed running up to 1 hour may be required.
3. Turn engine off and let set for a few minutes before restarting. Repeat this several times after engine has reached normal operating temperature.
4. Low oil pressure.
5. The oil restrictor in cylinder head gasket or the oil passage to the cylinder head is plugged with debris.
6. Air ingested into oil due to broken or cracked oil pump pick up.
7. Worn valve guides.
8. Rocker arm ears contacting valve spring retainer.
9. Rocker arm loose, adjuster stuck or at maximum extension and still leaves lash in the system.
10. Oil leak or excessive cam bore wear in cylinder head.
11. Faulty lash adjuster. Check lash adjusters for sponginess while installed in cylinder head and cam on camshaft at base circle. Depress part of rocker arm over adjuster. Normal adjusters should feel very firm. Spongy adjusters can be bottomed out easily. Remove suspected lash adjusters, and replace. Before installation, make sure adjusters are at least partially full of oil. This can be verified by little or no plunger travel when lash adjuster is depressed.

Scheme 67

Scheme 68

Scheme 69

1. Disconnect battery negative cable.
2. Raise the vehicle on a hoist.
3. Disconnect the exhaust pipe at the right side exhaust manifold.
4. Drain the engine coolant. Refer to «STANDARD PROCEDURE»(ref-306154-S25259837052008120900000).
5. Lower the vehicle.
6. Remove the intake manifold. See «REMOVAL»(ref-306142-S16054353982008120900000).
7. Remove the cylinder head cover. See «REMOVAL»(ref-306142-S19326271212008120900000).
8. Remove the fan shroud. Refer to «REMOVAL»(ref-306154-S21887878352008120900000).
9. Remove oil fill housing from cylinder head.
10. Remove accessory drive belt. Refer to «REMOVAL»(ref-306154-S30160988302008120900000).
11. Rotate the crankshaft until the damper timing mark is aligned with TDC indicator mark (2). (Scheme 67)
12. Verify the V6 mark on the camshaft sprocket is at the 12 o'clock position. (Scheme 68) Rotate the crankshaft one turn if necessary.
13. Remove the crankshaft damper. See «REMOVAL»(ref-306142-S14186681422008120900000).
14. Remove the timing chain cover. See «REMOVAL»(ref-306142-S29598169092008120900000). 1 - SPECIAL TOOL 8429 2 - CAMSHAFT CHAIN 3 - CRANKSHAFT TIMING GEAR
15. Lock the secondary timing chains to the idler sprocket using the Secondary Camshaft Chain Holder 8429 (1). see scheme 70 NOTE: Mark the secondary timing chain prior to removal to aid in installation.
16. Mark the secondary timing chain, one link on each side of the V6 mark on the camshaft drive gear.
17. Remove the right side secondary chain tensioner. See «REMOVAL»(ref-306142-S28673550012008120900000). 1 - RIGHT CYLINDER HEAD ACCESS PLUG 2 - LEFT CYLINDER HEAD ACCESS PLUG
18. Remove the cylinder head access plug (1,2). (Scheme 69)
19. Remove the right side secondary chain guide. See «REMOVAL»(ref-306142-S28673550012008120900000). CAUTION: The nut on the right side camshaft sprocket should not be removed for any reason, as the sprocket and camshaft sensor target wheel is serviced as an assembly. If the nut was removed, tighten nut to 5 N.m (44 in. lbs.).
20. Remove the retaining bolt and the camshaft drive gear. CAUTION: Do not allow the engine to rotate. severe damage to the valve train can occur. CAUTION: Do not overlook the four smaller bolts at the front of the cylinder head. Do not attempt to remove the cylinder head without removing these four bolts. CAUTION: Do not hold or pry on the camshaft target wheel for any reason. A damaged target wheel can result in a vehicle no start condition. * - INDICATES SEALANT ON THREADS NOTE: The cylinder head is attached to the cylinder block with twelve bolts.
21. Remove the cylinder head retaining bolts. see scheme 72
22. Remove the cylinder head and gasket. Discard the gasket.

CYLINDER HEADS

To ensure engine gasket sealing, proper surface preparation must be performed, especially with the use of aluminum engine components. see scheme 73 See STANDARD PROCEDURE.

1. Inspect the cylinder head for out-of-flatness, using a straightedge and a feeler gauge. If measurements exceed 0.0508 mm (0.002 in.) replace the cylinder head.
2. Inspect the valve seats for damage. Service the valve seats as necessary.
3. Inspect the valve guides for wear, cracks or looseness. If either condition exist, replace the cylinder head.

CYLINDER HEAD - RIGHT

Note. The cylinder head bolts are tightened using a torque plus angle procedure. The bolts must be examined BEFORE reuse. If the threads are necked down (2) the bolts should be replaced.

Necking can be checked by holding a straight edge against the threads. If all the threads do not contact the scale, the bolt should be replaced. see scheme 74

1. Clean the cylinder head and cylinder block mating surfaces. see scheme 75 * - INDICATES SEALANT ON THREADS
2. Position the new cylinder head gasket on the locating dowels. CAUTION: When installing cylinder head, use care not damage the tensioner arm or the guide arm.
3. Position the cylinder head onto the cylinder block. Make sure the cylinder head seats fully over the locating dowels. NOTE: The four M8 cylinder head mounting bolts (1) require sealant to be added to them before installing. Failure to do so may cause leaks.
4. Lubricate the cylinder head bolt threads with clean engine oil and install the eight M10 bolts.
5. Coat the four M8 cylinder head bolts with Mopar Lock and Seal Adhesive then install the bolts. NOTE: The cylinder head bolts are tightened using an angle torque procedure, however, the bolts are not a torque-to-yield design.
6. Tighten the bolts in sequence using the following steps and torque values. see scheme 76: Step 1: Tighten bolts 1-8, 27 N.m (20 ft. lbs.). Step 2: Verify that bolts 1-8, all reached 27 N.m (20 ft. lbs.), by repeating step 1 without loosening the bolts. Tighten bolts 9 thru 12 to 14 N.m (10 ft. lbs.). Step 3: Tighten bolts 1-8, 90°. Step 4: Tighten bolts 1-8, 90°, again. Tighten bolts 9-12, 26 N.m (19 ft. lbs.) 1 - SPECIAL TOOL 8429 2 - CAMSHAFT CHAIN 3 - CRANKSHAFT TIMING GEAR
7. Position the secondary chain (2) onto the camshaft drive gear, making sure one marked chain link is on either side of the V6 mark (1) on the gear then using the Camshaft Holder 8428, position the gear onto the camshaft. see scheme 77and see scheme 78. CAUTION: Remove excess oil from camshaft sprocket retaining bolt before reinstalling bolt. Failure to do so may cause over-torquing of bolt resulting in bolt failure.
8. Install the camshaft drive gear retaining bolt.
9. Install the right side secondary chain guide. See «INSTALLATION»(ref-306142-S24119590672008120900000). 1 - RIGHT CYLINDER HEAD ACCESS PLUG 2 - LEFT CYLINDER HEAD ACCESS PLUG
10. Install the cylinder head access plug (1,2). see scheme 79
11. Reset and install the right side secondary chain tensioner. See «INSTALLATION»(ref-306142-S24119590672008120900000). 1 - SPECIAL TOOL 8429 2 - CAMSHAFT CHAIN 3 - CRANKSHAFT TIMING GEAR
12. Remove the Camshaft Holder 8429 (1). see scheme 80
13. Install the timing chain cover. See «REMOVAL»(ref-306142-S29598169092008120900000).
14. Install the crankshaft damper. See «INSTALLATION»(ref-306142-S42050284672008120900000). Tighten damper bolt 175 N.m (130 Ft. Lbs.).
15. Install accessory drive belt. Refer to «INSTALLATION»(ref-306154-S38527570572008120900000).
16. Install the fan shroud. Refer to «INSTALLATION»(ref-306154-S41209272742008120900000).
17. Install the cylinder head cover. See «INSTALLATION»(ref-306142-S22568602322008120900000).
18. Install the intake manifold. See «INSTALLATION»(ref-306142-S30306992222008120900000).
19. Install oil fill housing onto cylinder head.
20. Refill the cooling system. Refer to «STANDARD PROCEDURE»(ref-306154-S25259837052008120900000).
21. Raise the vehicle.
22. Install the exhaust pipe onto the right exhaust manifold.
23. Lower the vehicle.
24. Reconnect battery negative cable.
25. Start the engine and check for leaks.

CAMSHAFT - RIGHT

The camshafts consist of powdered metal steel lobes which are sinter-bonded to a steel tube. Four bearing journals are machined into the camshaft. Camshaft end play is controlled by two thrust walls that border the nose piece journal.

1. Remove the cylinder head cover. See «REMOVAL»(ref-306142-S07155423102008120900000).
2. Set engine to TDC cylinder No. 1, camshaft sprocket V6 marks at the 12 o'clock position (1). see scheme 81
3. Mark one link on the secondary timing chain on both sides of the V6 mark on the camshaft sprocket to aid in installation. 1 - Camshaft hole 2 - Special Tool 8428 CAUTION: Do not hold or pry on the camshaft target wheel for any reason, Severe damage will occur to the target wheel. A damaged target wheel could cause a vehicle no start condition.
4. Loosen but DO NOT remove the camshaft sprocket retaining bolt. see scheme 83 Leave bolt snug against sprocket. 1 - SPECIAL TOOL 8379 2 - CAMSHAFT SPROCKET 3 - CAMSHAFT SPROCKET BOLT 4 - CYLINDER HEAD NOTE: The timing chain tensioners must be secured prior to removing the camshaft sprockets. Failure to secure tensioners will allow the tensioners to extend, requiring timing chain cover removal in order to reset tensioners. CAUTION: Do not force wedge past the narrowest point between the chain strands. Damage to the tensioners may occur.
5. Position the Wedge Locking Tool 8379 (1) between the timing chain strands. Tap the tool to securely wedge the timing chain against the tensioner arm and guide. see scheme 83 1 - Camshaft hole 2 - Special Tool 8428
6. Remove the camshaft position sensor.
7. Hold the camshaft with Camshaft Holder 8428 (2), while removing the camshaft sprocket bolt and sprocket. see scheme 84
8. Starting at the outside working inward, loosen the camshaft bearing cap retaining bolts 1/2 turn at a time. see scheme 85 Repeat until all load is off the bearing caps. CAUTION: DO NOT STAMP OR STRIKE THE CAMSHAFT BEARING CAPS. SEVERE DAMAGE WILL OCCUR TO THE BEARING CAPS. NOTE: When the camshaft is removed the rocker arms may slide downward, mark the rocker arms before removing camshaft.
9. Remove the camshaft bearing caps and the camshaft.

1. Lubricate camshaft journals with clean engine oil. NOTE: Position the right side camshaft so that the camshaft sprocket dowel is near the 10 o'clock position, This will place the camshaft at the neutral position easing the installation of the camshaft bearing caps.
2. Position the camshaft into the cylinder head.
3. Install the camshaft bearing caps, hand tighten the retaining bolts. NOTE: Caps should be installed so that the stamped numbers on the caps are in numerical order, (1 through 4) from the front to the rear of the engine. All caps should be installed so that the stamped arrows on the caps point toward the front of the engine.
4. Working in 1/2 turn increments, tighten the bearing cap retaining bolts starting with the middle cap working outward.
5. Tighten the camshaft bearing cap retaining bolts to 11 N.m (100 in. lbs.). see scheme 86
6. Position the camshaft drive gear into the timing chain aligning the V6 mark between the two marked chain links (Two links marked during removal). see scheme 87 1 - Camshaft hole 2 - Special Tool 8428
7. Using the Camshaft Holder 8428 (2), rotate the camshaft until the camshaft sprocket dowel is aligned with the slot in the camshaft sprocket. Install the sprocket onto the camshaft. see scheme 88 CAUTION: Remove excess oil from camshaft sprocket bolt. Failure to do so can cause bolt over-torque resulting in bolt failure.
8. Remove excess oil from camshaft sprocket bolt, then install the camshaft sprocket retaining bolt and hand tighten. 1 - SPECIAL TOOL 8379 2 - CAMSHAFT SPROCKET 3 - CAMSHAFT SPROCKET BOLT 4 - CYLINDER HEAD
9. Remove timing chain wedge special tool 8379 (1). see scheme 89
10. Using Spanner Wrench 6958 with adapter pins 8346, tighten the camshaft sprocket retaining bolt to 122 N.m (90 ft. lbs.)
11. Install the camshaft position sensor.
12. Install the cylinder head cover. See «INSTALLATION»(ref-306142-S22568602322008120900000).

1. Disconnect battery negative cable.
2. Remove air cleaner assembly, resonator assembly and air inlet hose.
3. Drain cooling system, below the level of the heater hoses. Refer to «STANDARD PROCEDURE»(ref-306154-S25259837052008120900000) .
4. Remove accessory drive belt. Refer to «REMOVAL»(ref-306154-S30160988302008120900000) .
5. Remove air conditioning compressor retaining bolts and move compressor to the left.
6. Remove heater hoses.
7. Disconnect injector and ignition coil connectors.
8. Disconnect and remove positive crankcase ventilation (PCV) hose.
9. Remove oil fill tube.
10. Unclip injector and ignition coil harness and move away from cylinder head cover.
11. Remove right rear breather tube and filter assembly.
12. Remove cylinder head cover retaining bolts.
13. Remove cylinder head cover.

Note. The gasket may be used again, provided no cuts, tears, or deformation has occurred.

1. Clean cylinder head cover and both sealing surfaces. Inspect and replace gasket as necessary.
2. Tighten cylinder head cover bolts and double ended studs to 12 N.m (105 in. lbs).
3. Install right rear breather tube and filter assembly.
4. Connect injector, ignition coil electrical connectors and harness retaining clips.
5. Install the oil fill tube.
6. Install PCV hose.
7. Install heater hoses.
8. Install air conditioning compressor retaining bolts.
9. Install accessory drive belt. Refer to «INSTALLATION»(ref-306154-S38527570572008120900000) .
10. Fill Cooling system. Refer to «STANDARD PROCEDURE»(ref-306154-S25259837052008120900000) .
11. Install air cleaner assembly, resonator assembly and air inlet hose.
12. Connect battery negative cable.

The valves are made of heat resistant steel and have chrome plated stems to prevent scuffing. Each valve is actuated by a roller rocker arm which pivots on a stationary lash adjuster. All valves use three bead lock keepers to retain the springs and promote valve rotation.

REFACING

Note. Valve seats that are worn or burned can be reworked, provided that correct angle and seat width are maintained. Otherwise the cylinder head must be replaced.

Note. When refacing valves (4) and valve seats, it is important that the correct size valve guide pilot be used for reseating stones. A true and complete surface must be obtained.

1. Using a suitable dial indicator measure the center of the valve seat. Total run out must not exceed 0.051 mm (0.002 in).
2. Apply a small amount of Prussian blue to the valve seat, insert the valve into the cylinder head, while applying light pressure on the valve rotate the valve. Remove the valve and examine the valve face. If the blue is transferred below the top edge of the valve face, lower the valve seat using a 15 degree stone. If the blue is transferred to the bottom edge of the valve face, raise the valve seat using a 65 degree stone.
3. When the seat is properly positioned the width of the intake seat must be 1.75 - 2.36 mm (0.0689 - 0.0928 in.) and the exhaust seat must be 1.71 - 2.32 mm (0.0673 - 0.0911 in.).
4. Check the valve spring (6) installed height after refacing the valve and seat. The installed height for both intake and exhaust valve springs must not exceed 40.74 mm (1.6039 in.)
5. The valve seat and valve face must maintain a face angle of 44.5 - 45° angle.

VALVES AND VALVE SPRINGS

Note. The cylinder heads must be removed in order to perform this procedure.

1. Remove rocker arms and lash adjusters. See «REMOVAL»(ref-306142-S33933368352008120900000) .
2. Remove the camshaft bearing caps and the camshaft. NOTE: All valve springs and valves are removed in the same manner; this procedure only covers one valve and valve spring.
3. Using Valve Spring Compressor C-3422-B or C-3422-C and Adapter 8519, compress the valve spring. NOTE: It may be necessary to tap the top of the valve spring to loosen the spring retainers locks enough to be removed.
4. Remove the two spring retainer lock halves. NOTE: the valve spring is under tension use care when releasing the valve spring compressor.
5. Remove the valve spring compressor.
6. Remove the spring retainer, and the spring. NOTE: Check for sharp edges on the keeper grooves. Remove any burrs from the valve stem before removing the valve from the cylinder head.
7. Remove the valve from the cylinder head. NOTE: The valve stem seals are common between intake and exhaust.
8. Remove the valve stem seal. Mark the valve for proper installation.

1. coat the valve stem with clean engine oil and insert it into the cylinder head.
2. Install the valve stem seal. make sure the seal is fully seated and that the garter spring at the top of the seal is intact.
3. Install the spring and the spring retainer.
4. Using the valve spring compressor, compress the spring and install the two valve spring retainer halves.
5. Release the valve spring compressor and make sure the two spring retainer halves and the spring retainer are fully seated. (Scheme 64)
6. Lubricate the camshaft journal with clean engine oil then Position the camshaft (with the sprocket dowel on the left camshaft at 11 o'clock and the right camshaft at 12 o'clock), then position the camshaft bearing caps.
7. Install the camshaft bearing cap retaining bolts. Tighten the bolts 9-13 N.m (100 in. lbs.) in 1/2 turn increments in the sequence (Scheme 65)
8. Position the hydraulic lash adjusters and rocker arms. See «INSTALLATION»(ref-306142-S12648860592008120900000).

The rocker arms are steel stampings with an integral roller bearing. The rocker arms incorporate a 0.5 mm oil jet hole in the lash adjuster socket for roller and camshaft lubrication.

Note. Disconnect the battery negative cable to prevent accidental starter engagement.

1. Remove the cylinder head cover. See «REMOVAL»(ref-306142-S12051049862008120900000).
2. For rocker arm removal on cylinder No. 4, Rotate the crankshaft until cylinder No. 1 is at BDC intake stroke.
3. For rocker arm removal on cylinder No. 1, Rotate the crankshaft until cylinder No. 1 is at BDC combustion stroke.
4. For rocker arm removal on cylinders No. 3 and No. 5, Rotate the crankshaft until cylinder No. 1 is at TDC exhaust stroke.
5. For rocker arm removal on cylinders No. 2 and No. 6, Rotate the crankshaft until cylinder No. 1 is at TDC ignition stroke.
6. Using the Rocker Arm Remover/Installer 8516A (2), press downward on the valve spring, remove rocker arm. (Scheme 66)

Note. Coat the rocker arms with clean engine oil prior to installation.

1. For rocker arm installation on cylinders No. 4, Rotate the crankshaft until cylinder No. 1 is at BDC intake stroke.
2. For rocker arm installation on cylinder No. 1, Rotate the crankshaft until cylinder No. 1 is at BDC combustion stroke.
3. For rocker arm installation on cylinders No. 3 and No. 5, Rotate the crankshaft until cylinder No. 1 is at TDC exhaust stroke.
4. For rocker arm installation on cylinders No. 2 and No. 6, Rotate the crankshaft until cylinder No. 1 is at TDC ignition stroke.
5. Using the Rocker Arm Remover/Installer 8516A (2) press downward on the valve spring, install rocker arm. see scheme 96
6. Install the cylinder head cover. See «INSTALLATION»(ref-306142-S22568602322008120900000).

VALVE GUIDE SEALS

The valve guide seals are made of rubber and incorporate an integral steel valve spring seat. The integral garter spring maintains consistent lubrication control to the valve stems.

The valve springs are made from high strength chrome silicon steel. There are different springs for intake and exhaust applications. The exhaust spring has an external damper. The valve spring seat is integral with the valve stem seal, which is a positive type seal to control lubrication.

1. Remove the cylinder head cover. See «REMOVAL»(ref-306142-S12051049862008120900000) .
2. Using the Valve Spring Remover/Installer 8516A, remove the rocker arms and the hydraulic lash adjusters.
3. Remove the spark plug for the cylinder the valve spring and seal are to be removed from.
4. Apply shop air to the cylinder to hold the valves in place when the spring is removed. NOTE: All six valve springs and seals are removed in the same manner; this procedure only covers one valve seal and valve spring.
5. Using the Valve Spring Compressor 8387, compress the valve spring. NOTE: It may be necessary to tap the top of the valve spring to loosen the spring retainers locks enough to be removed.
6. Remove the two spring retainer lock halves. NOTE: the valve spring is under tension use care when releasing the valve spring compressor.
7. Remove the valve spring compressor. NOTE: The valve springs are NOT common between intake and exhaust.
8. Remove the spring retainer, and the spring.
9. Remove the valve stem seal.

Note. The valve stem seals are common between intake and exhaust.

Note. All six valve springs and seals are removed in the same manner; this procedure only covers one valve seal and valve spring.

1. Apply shop air to the cylinder to hold the valves in place while the spring is installed. NOTE: The valve stem seals are common between intake and exhaust.
2. Install the valve stem seal. NOTE: The valve springs are NOT common between intake and exhaust.
3. Install the spring retainer, and the spring.
4. Using Valve Spring Compressor 8387, compress the valve spring.
5. Install the two spring retainer lock halves. NOTE: the valve spring is under tension use care when releasing the valve spring compressor.
6. Remove the valve spring compressor.
7. Disconnect the shop air to the cylinder.
8. Install the spark plug for the cylinder the valve spring and seal was installed on.
9. Using the Valve Spring Remover/Installer Special Tool 8516A, install the rocker arms and the hydraulic lash adjusters.
10. Install the cylinder head cover. See «INSTALLATION»(ref-306142-S22568602322008120900000) .

ENGINE BLOCK

The cylinder block is made of cast iron. The block is a closed deck design with the left bank forward. To provide high rigidity and improved NVH an enhanced compacted graphite bedplate is bolted to the block. The block design allows coolant flow between the cylinders bores, and an internal coolant bypass to a single poppet inlet thermostat is included in the cast aluminum front cover.

Scheme 70

Before honing, stuff plenty of clean shop towels under the bores and over the crankshaft to keep abrasive materials from entering the crankshaft area.

1. Used carefully, the Cylinder Bore Sizing Hone C-823, equipped with 220 grit stones, is the best tool for this job. In addition to deglazing, it will reduce taper and out-of-round, as well as removing light scuffing, scoring and scratches. Usually, a few strokes will clean up a bore and maintain the required limits. CAUTION: DO NOT use rigid type hones to remove cylinder wall glaze.
2. Deglazing of the cylinder walls may be done if the cylinder bore is straight and round. Use a cylinder surfacing hone, Honing Tool C-3501, equipped with 280 grit stones (C-3501-3810). about 20-60 strokes, depending on the bore condition, will be sufficient to provide a satisfactory surface. Using honing oil C-3501-3880, or a light honing oil, available from major oil distributors. CAUTION: DO NOT use engine or transmission oil, mineral spirits, or kerosene.
3. Honing should be done by moving the hone up and down fast enough to get a crosshatch pattern (1). The hone marks should INTERSECT at 50° to 60° for proper seating of rings (2).
4. A controlled hone motor speed between 200 and 300 RPM is necessary to obtain the proper crosshatch angle. The number of up and down strokes per minute can be regulated to get the desired 50° to 60° angle. Faster up and down strokes increase the crosshatch angle.
5. After honing, it is necessary that the block be cleaned to remove all traces of abrasive. Use a brush to wash parts with a solution of hot water and detergent. Dry parts thoroughly. Use a clean, white, lint-free cloth to check that the bore is clean. Oil the bores after cleaning to prevent rusting.

CYLINDER BLOCK

Thoroughly clean the oil pan and engine block gasket surfaces.

Use compressed air to clean out

1. The galley at the oil filter Adapter hole.
2. The front and rear oil galley holes.
3. The feed holes for the crankshaft main bearings.

Once the block has been completely cleaned, apply Loctite PST pipe sealant with Teflon 592 to the threads of the front and rear oil galley plugs. Tighten the plugs to 34 N.m (25 ft. lbs.)

Scheme 71

1. It is mandatory to use a dial bore gauge to measure each cylinder bore diameter. To correctly select the proper size piston, a cylinder bore gauge, capable of reading in 0.003 mm (.0001 in.) INCREMENTS is required. If a bore gauge is not available, do not use an inside micrometer.
2. Measure the inside diameter of the cylinder bore at three levels below top of bore. Start perpendicular (across or at 90 degrees) to the axis of the crankshaft and then take two additional reading.
3. Measure the cylinder bore diameter crosswise to the cylinder block near the top of the bore. Repeat the measurement near the middle of the bore, then repeat the measurement near the bottom of the bore.
4. Determine taper by subtracting the smaller diameter from the larger diameter.
5. Rotate measuring device 90° and repeat steps above.
6. Determine out-of-roundness by comparing the difference between each measurement.
7. If cylinder bore taper does not exceed 0.025 mm (0.001 inch) and out-of-roundness does not exceed 0.015 mm (0.0006 inch), the cylinder bore can be honed. If the cylinder bore taper or out- of-round condition exceeds these maximum limits, the cylinder block must be replaced. A slight amount of taper always exists in the cylinder bore after the engine has been in use for a period of time.

CRANKSHAFT

The crankshaft is constructed of nodular cast iron. The crankshaft is a three throw split pin design with six counterweights for balancing purposes. The crankshaft is supported by four select fit main bearings with the number two serving as the thrust washer location. The main journals of the crankshaft are cross drilled to improve rod bearing lubrication. The number six counterweight has provisions for crankshaft position sensor target wheel mounting. The select fit main bearing markings are located on the rear side of the target wheel. The crankshaft oil seals are one piece design. The front oil seal is retained in the timing chain cover, and the rear seal is pressed in to a bore formed by the cylinder block and the bedplate assembly. (Scheme 72)

Scheme 72

Scheme 73

Note. To remove the crankshaft from the engine, the engine must be removed from the vehicle.

1. Remove the engine. See «REMOVAL»(ref-306142-S07058402912008120900000).
2. Remove the engine oil pump. See «REMOVAL»(ref-306142-S08929013882008120900000). CAUTION: DO NOT pry on the oil pan gasket when removing the oil pan, The oil pan gasket is mounted to the cylinder block in three locations and will remain attached to block when removing oil pan. Gasket can not be removed with oil pan.
3. Remove the bedplate mounting bolts. Note the location of the two stud bolts for installation.
4. Remove the connecting rods from the crankshaft. CAUTION: The bedplate to cylinder block mating surface is a critical sealing surface. Do not pry on or damage this surface in anyway. NOTE: The bedplate contains the lower main bearing halves. Use care when handling bedplate as not to drop or damage bearing halves. Installing main bearing halves in the wrong position will cause severe damage to the crankshaft. NOTE: The bedplate has pry points cast into it. Use these points only. The pry points are shown in illustration.
5. Carefully pry on the pry points to loosen the bedplate then remove the bedplate. (Scheme 73) CAUTION: When removing the crankshaft, use care not to damage bearing surfaces on the crankshaft.
6. Remove the crankshaft.
7. Remove the crankshaft tone wheel.

Note. Thoroughly inspect the connecting rod bearing bores and main bearing bores for scoring, blueing or severe scratches. Further disassembly may be required.

If connecting rod bearing bores show damage, the cylinder heads must be removed to service the piston and rod assemblies. If the bedplate or the cylinder block main bearing bores show damage the engine must be replaced.

1. If required, remove the main bearing halves from the cylinder block and bedplate.
2. Thoroughly clean the bedplate to cylinder block sealing surfaces and main bearing bores. Remove all oil and sealant residue.
3. Inspect the bedplate main bearing bores for cracks, scoring or severe blueing. If either condition exists the engine must be replaced.
4. Inspect the crankshaft thrust washers for scoring, scratches, wear or blueing. If either condition exist replace the thrust washers.
5. Inspect the oil pan gasket/windage tray for splits, tears or cracks in the gasket sealing surfaces. Replace gasket as necessary.

Scheme 74

Note. Apply sealant to the tone wheel retaining screws prior to installation.

Scheme 75

Scheme 76

1. Lubricate upper main bearing halves with clean engine oil.
2. Install the crankshaft tone wheel. Tighten the mounting screws to 15 N.m (11 ft. lbs.)
3. Position crankshaft in cylinder block.
4. Install the thrust washers (1). 1 - CYLINDER BLOCK 2 - SEALANT 3 - SEALANT CAUTION: The bedplate to cylinder block mating surface must be coated with Mopar® Engine RTV sealant prior to installation. Failure to do so will cause severe oil leaks. NOTE: Make sure that the bedplate and cylinder block sealing surfaces are clean and free of oil or other contaminants. Contaminants on the sealing surfaces may cause main bearing distortion and/or oil leaks.
5. Apply a 2.5 mm (0.100 inch) bead of Mopar® Engine RTV sealant to the cylinder block-to-bedplate mating surface (2,3) (Scheme 75)
6. Coat the crankshaft main bearing journals with clean engine oil and position the bedplate onto the cylinder block. NOTE: Lubricate the bedplate retaining bolts with clean engine oil prior to installation.
7. Install the bedplate retaining bolts, making sure to place the stud bolts in the correct location, Tighten the bolts in the sequence (Scheme 76) Hand tighten bolts 1D, 1G and 1F until the bedplate contacts the block. Tighten bolts 1A - 1J to 54 N.m (40 ft. lbs.) Tighten bolts 1 - 8 to 7 N.m (5 ft. lbs.) Turn bolts 1 - 8 an additional 90°. Tighten bolts A - E 27 N.m (20 ft. lbs.).
8. Measure crankshaft end play.
9. Install the connecting rods and measure side clearance. See «STANDARD PROCEDURE»(ref-306142-S12781092502008120900000).
10. Install oil pump. See «INSTALLATION»(ref-306142-S07909706492008120900000).
11. Install the engine. See «INSTALLATION»(ref-306142-S13879575462008120900000).

Scheme 77

The main bearings are "select fit" to achieve proper oil clearances. For main bearing selection, the crankshaft position sensor target wheel (2) has grade identification marks stamped into it. These marks are read from left to right, corresponding with journal number 1, 2, 3, 4. The crankshaft position sensor target wheel is mounted to the number 6 counter weight (1) on the crankshaft. (Scheme 77)

MAIN BEARING JOURNAL DIAMETER (CRANKSHAFT REMOVED)

Remove the crankshaft from the cylinder block. See REMOVAL .

Clean the oil off the main bearing journal.

Determine the maximum diameter of the journal with a micrometer. Measure at two locations 90° apart at each end of the journal.

The maximum allowable taper is 0.008 mm (0.0004 inch.) and maximum out of round is 0.005 mm (0.002 inch). Compare the measured diameter with the journal diameter specification (Main Bearing Fitting Chart). Select inserts required to obtain the specified bearing-to-journal clearance.

Install the crankshaft into the cylinder block. See INSPECTION .

Check crankshaft end play.

CRANKSHAFT MAIN BEARING SELECTION

1. Service main bearings are available in four grades. The chart identifies the four service grades available.

Scheme 78

Scheme 79

1. Disconnect negative cable from battery.
2. Remove accessory drive belt. Refer to «REMOVAL»(ref-306154-S30160988302008120900000).
3. Remove A/C compressor mounting fasteners and set aside.
4. Drain cooling system. Refer to «STANDARD PROCEDURE»(ref-306154-S25259837052008120900000).
5. Remove upper radiator hose.
6. Disconnect electrical connector for fan mounted inside radiator shroud.
7. Remove radiator shroud attaching fasteners.
8. Remove radiator cooling fan and shroud. Refer to «REMOVAL»(ref-306154-S21887878352008120900000).
9. Remove crankshaft damper bolt.
10. Remove damper using the Crankshaft Insert 8513A (1) and the Three Jaw Puller 1026 (2). (Scheme 78) 1 - SPECIAL TOOL 8511
11. Using Seal Remover 8511, remove crankshaft front seal (1). (Scheme 79)

Scheme 80

1. Using the Seal Installer 8348 (2) and Damper Installer 8512 (3), install crankshaft front seal. (Scheme 80)
2. Install vibration damper. See «INSTALLATION»(ref-306142-S42050284672008120900000).
3. Install radiator cooling fan and shroud. Refer to «INSTALLATION»(ref-306154-S41209272742008120900000).
4. Install upper radiator hose.
5. Install A/C compressor and tighten fasteners to 54 N.m (40 ft. lbs.).
6. Install accessory drive belt refer. Refer to «INSTALLATION»(ref-306154-S38527570572008120900000).
7. Refill cooling system. Refer to «STANDARD PROCEDURE»(ref-306154-S25259837052008120900000).
8. Connect negative cable to battery.

REAR CRANKSHAFT OIL SEAL AREA LEAKS

Since it is sometimes difficult to determine the source of an oil leak in the rear seal area of the engine, a more involved inspection is necessary. The following steps should be followed to help pinpoint the source of the leak.

If the leakage occurs at the crankshaft rear oil seal area

1. Disconnect the battery.
2. Raise the vehicle.
3. Remove torque converter or clutch housing cover and inspect rear of block for evidence of oil. Use a black light to check for the oil leak: Circular spray pattern generally indicates seal leakage or crankshaft damage. Where leakage tends to run straight down, possible causes are a porous block, oil galley pipe plugs, oil filter runoff, and main bearing cap to cylinder block mating surfaces. Refer to the appropriate component service information for proper repair procedures of these items.
4. If no leaks are detected, pressurize the crankcase as outlined in «AIR LEAK DETECTION TEST METHOD»(ref-306142-S37438529602008120900000) . CAUTION: Do not exceed 20.6 kPa (3 psi).
5. If the leak is not detected, very slowly turn the crankshaft and watch for leakage. If a leak is detected between the crankshaft and seal while slowly turning the crankshaft, it is possible the crankshaft seal surface is damaged. The seal area on the crankshaft could have minor nicks or scratches that can be polished out with emery cloth. CAUTION: Use extreme caution when crankshaft polishing is necessary to remove minor nicks or scratches. The crankshaft seal flange is specially machined to complement the function of the rear oil seal.
6. For bubbles that remain steady with shaft rotation, no further inspection can be done until disassembled. See «ENGINE LUBRICATION DIAGNOSTIC TABLE»(ref-306142-S41896910262008120900000) , under the OIL LEAK row, for components inspections on possible causes and corrections.
7. After the oil leak root cause and appropriate corrective action have been identified, see «REMOVAL»(ref-306142-S24832871802008120900000) .

Scheme 81

Note. This procedure can be performed in vehicle.

1. If being performed in vehicle, remove the transmission.
2. Remove the flexplate. See «REMOVAL»(ref-306142-S08368017532008120900000) . NOTE: The crankshaft oil seal CAN NOT be reused after removal. NOTE: The crankshaft rear oil seal remover 8506 must be installed deeply into the seal. Continue to tighten the removal tool into the seal until the tool can not be turned farther. Failure to install tool correctly the first time will cause tool to pull free of seal without removing seal from engine.
3. Using Seal Remover 8506 (2), remove the crankshaft rear oil seal (1).

Scheme 82

Scheme 83

1. Lubricate the crankshaft flange with engine oil.
2. Position the magnetic seal guide 8349-2 onto the crankshaft rear face. Then position the crankshaft rear oil seal (1) onto the guide (2). 1 - REAR CRANKSHAFT SEAL 2 - SPECIAL TOOL 8349-1 INSTALLER 3 - SPECIAL TOOL C-4171 HANDLE
3. Using Crankshaft Rear Oil Seal Installer 8349 (2) and Driver Handle C-4171 (3), with a hammer, tap the seal (1) into place. Continue to tap on the driver handle until the seal installer seats against the cylinder block crankshaft bore.
4. Install the flexplate.
5. Install the transmission.

FLEXPLATE

1. Remove the transmission.
2. Remove the bolts and flexplate.

Scheme 84

1. Position the flexplate (1) onto the crankshaft and install the bolts hand tight.
2. Tighten the flexplate retaining bolts to 95 N.m (70 ft. lbs.) in the sequence (Scheme 84)
3. Install the transmission.

Scheme 85

The pistons (2) are made of a high strength aluminum alloy. The connecting rods (1) are made of forged powdered metal, with a "fractured cap" design. A full floating piston pin is used to attach the piston to the connecting rod. (Scheme 85)

Scheme 86

Inspect the connecting rod bearings for scoring. Check the bearings for normal wear patterns, scoring, grooving, fatigue and pitting. (Scheme 86) Replace any bearing that shows abnormal wear.

Inspect the connecting rod journals for signs of scoring, nicks and burrs.

Misaligned or bent connecting rods can cause abnormal wear on pistons, piston rings, cylinder walls, connecting rod bearings and crankshaft connecting rod journals. If wear patterns or damage to any of these components indicate the probability of a misaligned connecting rod, inspect it for correct rod alignment. Replace misaligned, bent or twisted connecting rods.

Scheme 87

Scheme 88

Scheme 89

1. Wipe the oil from the connecting rod journal.
2. Lubricate the upper bearing insert and position in connecting rod. Center bearing insert (2) in connecting rod (1). (Scheme 87) 1 - "F" TOWARD FRONT OF ENGINE 2 - OIL SLINGER SLOT 3 - RING COMPRESSOR 4 - SPECIAL TOOL 8507
3. Use piston ring compressor (3) and Connecting Rod Guides 8507 to install the rod and piston assemblies. The oil slinger slots in the rods must face front of the engine. The "F's" near the piston wrist pin bore (1) should point to the front of the engine. (Scheme 88) 1 - PLASTIGAGE SCALE 2 - COMPRESSED PLASTIGAGE
4. Install the lower bearing insert in the bearing cap. Center bearing insert in connecting rod.. The lower insert must be dry. Place strip of Plastigage across full width of the lower insert at the center of bearing cap. (Scheme 89) Plastigage must not crumble in use. If brittle, obtain fresh stock.
5. Install bearing cap and connecting rod on the journal and tighten bolts to 27 N.m (20 ft. lbs.) plus a 90° turn. DO NOT rotate crankshaft. Plastigage will smear, resulting in inaccurate indication.
6. Remove the bearing cap and determine amount of bearing-to-journal clearance by measuring the width of compressed Plastigage (2). Refer to «SPECIFICATIONS»(ref-306142-S09472127992008120900000) for the proper clearance. Plastigage should indicate the same clearance across the entire width of the insert. If the clearance varies, it may be caused by either a tapered journal, bent connecting rod or foreign material trapped between the insert and cap or rod.
7. If the correct clearance is indicated, replacement of the bearing inserts is not necessary. Remove the Plastigage from crankshaft journal and bearing insert. Proceed with installation. Bearing Mark SIZE USED WITH JOURNAL SIZE.025 US.025 mm 57.883 - 57.867 mm (.001 in.) (2.2788 - 2.2783 in.) Std. STANDARD 57.908 - 57.892 mm (2.2798 - 2.2792 in.).250 US.250 mm 57.658 - 57.646 mm - (.010 in.) (2.2700 - 2.2695 in.)
8. If bearing-to-journal clearance exceeds the specification, determine which services bearing set to use the bearing sizes are as follows: CAUTION: Connecting Rod Bolts are Torque to Yield Bolts and Must Not Be Reused. Always replace the Rod Bolts whenever they are loosened or removed.
9. Repeat the Plastigage measurement to verify your bearing selection prior to final assembly.
10. Once you have selected the proper insert, install the insert and cap. Tighten the connecting rod bolts to 27 N.m (20 ft. lbs.) plus a 90° turn.

Scheme 90

Slide snug-fitting feeler gauge between the connecting rod and crankshaft journal flange. Refer to SPECIFICATIONS for the proper clearance. Replace the connecting rod if the side clearance is not within specification. (Scheme 90)

Scheme 91

Scheme 92

1. To correctly select the proper size piston, a cylinder bore gauge (2), capable of reading in 0.003 mm (.0001 in.) INCREMENTS is required. If a bore gauge is not available, do not use an inside micrometer. (Scheme 91)
2. Measure the inside diameter of the cylinder bore (3) at a point 38.0 mm (1.5 inches) below top of bore. Start perpendicular (across or at 90 degrees) to the axis of the crankshaft at point A and then take an additional bore reading 90 degrees to that at point B. 1 - MOLY COATED 2 - MOLY COATED
3. The coated pistons (1,2) will be serviced with the piston pin and connecting rod pre-assembled. (Scheme 92)
4. The coating material is applied to the piston after the final piston machining process. Measuring the outside diameter of a coated piston (1,2) will not provide accurate results. Therefore measuring the inside diameter of the cylinder bore with a dial Bore Gauge is MANDATORY. To correctly select the proper size piston, a cylinder bore gauge capable of reading in 0.003 mm (.0001 in.) increments is required.
5. Piston installation into the cylinder bore requires slightly more pressure than that required for non-coated pistons. The bonded coating on the piston will give the appearance of a line-to-line fit with the cylinder bore.

PISTON AND CONNECTING ROD

1. Using a suitable cleaning solvent clean the pistons in warm water and towel dry.
2. Use a wood or plastic scraper to clean the ring land grooves.

Check the connecting rod journal for excessive wear, taper and scoring.

Check the connecting rod for signs of twist or bending.

Check the piston for taper and elliptical shape before it is fitted into the cylinder bore.

Check the piston for scoring, or scraping marks in the piston skirts. Check the ring lands for cracks and/or deterioration.

Scheme 93

Scheme 94

1. Before installing piston and connecting rod assemblies into the bore, install the piston rings.
2. Immerse the piston head and rings in clean engine oil. Position a ring compressor over the piston and rings. Tighten ring compressor. Ensure position of rings do not change during this operation.
3. Position bearing onto connecting rod. Ensure that tabs in bearing shell aligns with slots in connecting rod. Verify that parting line of bearing is aligned with parting line of connecting rod.
4. Lubricate bearing surface with clean engine oil.
5. Install Connecting Rod Guides 8507 (4) onto connecting rod bolt threads. (Scheme 93) 1 - MAJOR THRUST SIDE OF PISTON 2 - OIL SLINGER SLOT
6. The pistons are marked on the piston pin bore surface with an raised "F" indicating installation position. This mark must be pointing toward the front of engine on both cylinder banks. The connecting rod oil slinger slot (2) faces the front of the engine. (Scheme 94)
7. Wipe cylinder bore clean and lubricate with engine oil.
8. Rotate crankshaft until connecting rod journal is on the center of cylinder bore. Insert rod and piston into cylinder bore and carefully position connecting rod guides over crankshaft journal.
9. Tap piston down in cylinder bore using a hammer handle. While at the same time, guide connecting rod into position on rod journal. CAUTION: Connecting Rod Bolts are Torque to Yield Bolts and Must Not Be Reused. Always replace the Rod Bolts whenever they are loosened or removed.
10. Lubricate rod bolts and bearing surfaces with engine oil. Install connecting rod cap and bearing. Tighten bolts to 27 N.m (20 ft. lbs.) plus 90°.
11. Install the following components: Cylinder head(s). See «INSTALLATION»(ref-306142-S04455426552008120900000) for left side or «INSTALLATION»(ref-306142-S35295556842008120900000) for right side. Timing chain and cover. See «INSTALLATION»(ref-306142-S34953854812008120900000). Cylinder head covers. See «INSTALLATION»(ref-306142-S22568602322008120900000) for left side or «INSTALLATION»(ref-306142-S07052064472008120900000) for right side. Oil pan and gasket/windage tray. See «INSTALLATION»(ref-306142-S16036183492008120900000).
12. Fill crankcase with proper engine oil to correct level.
13. Connect negative cable to battery.

Scheme 95

Before reinstalling used rings or installing new rings, the ring clearances must be checked.

Scheme 96

Scheme 97

Scheme 98

Scheme 99

1. Wipe the cylinder bore clean.
2. Insert the ring in the cylinder bore. NOTE: The ring gap measurement must be made with the ring positioned at least 12 mm (0.50 inch.) from bottom of cylinder bore.
3. Using a piston, to ensure that the ring is squared in the cylinder bore, slide the ring downward into the cylinder.
4. Using a feeler gauge (1) check the ring end gap. Replace any rings not within specification. 1 - FEELER GAUGE PISTON RING SIDE CLEARANCE NOTE: Make sure the piston ring grooves are clean and free of nicks and burrs.
5. Measure the ring side clearance (Scheme 96) Make sure the feeler gauge (1) fits snugly between the ring land and the ring. Replace any ring not within specification.
6. Rotate the ring around the piston, the ring must rotate in the groove with out binding. PISTON RING SPECIFICATION CHART Ring Position Groove Clearance Maximum Clearance Upper Ring 0.051 - 0.094 mm 0.11 mm (0.0020 - 0.0037 in.) (0.004 in.) Intermediate Ring 0.04 - 0.08 mm 0.10 mm (0.0016 - 0.0031 in.) (0.004 in.) Oil Control Ring 0.019 - 0.229 mm 0.25 mm (Steel Rails) (0.0007-.0090 in.) (0.010 in.) Ring Position Ring Gap Wear Limit Upper Ring 0.20 - 0.36 mm 0.43 mm - (0.0079 - 0.0142 in.) (0.0017 in.) Intermediate Ring 0.37 - 0.63 mm 0.74 mm - (0.0146 - 0.0249 in.) (0.029 in.) Oil Control Ring 0.025 - 0.76 mm 1.55 mm (Steel Rail) (0.0099 - 0.03 in.) (0.061 in.) 1 - SIDE RAIL END
7. The No. 1 and No. 2 piston rings have a different cross section. Ensure No. 2 ring is installed with manufacturers I.D. mark (Dot) facing up, towards top of the piston. NOTE: Piston rings are installed in the following order: Oil ring expander. Upper oil ring side rail. Lower oil ring side rail. No. 2 Intermediate piston ring. No. 1 Upper piston ring.
8. Install the oil ring expander.
9. Install upper side rail (1) by placing one end between the piston ring groove and the expander ring. Hold end firmly and press down the portion to be installed until side rail is in position. Repeat this step for the lower side rail.
10. Install No. 2 intermediate piston ring using a piston ring installer.
11. Install No. 1 upper piston ring using a piston ring installer. 1 - SIDE RAIL UPPER 2 - NO. 1 RING GAP 3 - PISTON PIN 4 - SIDE RAIL LOWER 5 - NO. 2 RING GAP AND SPACER EXPANDER GAP
12. Position piston ring end gaps (Scheme 95) It is important that expander ring gap (5) is at least 45° from the side rail gaps, but not on the piston pin center or on the thrust direction.

CRANKSHAFT DAMPER

1. Disconnect negative cable from battery.
2. Remove accessory drive belt. Refer to «REMOVAL»(ref-306154-S30160988302008120900000) . NOTE: Transmission cooler line snaps into shroud lower right hand corner.
3. Remove crankshaft damper bolt.
4. Remove damper using Crankshaft Insert 8513A (1) and Three Jaw Puller 1026(2).

Scheme 100

Scheme 101

1. Align crankshaft damper slot with key in crankshaft. Slide damper onto crankshaft slightly. CAUTION: Damper Installer 8512A, is assembled in a specific sequence. Failure to assemble this tool in this sequence can result in tool failure and severe damage to either the tool or the crankshaft.
2. Assemble the Damper Installer 8512A as follows, The nut is threaded onto the shaft first. Then the roller bearing (1) is placed onto the threaded rod (3) (The hardened bearing surface of the bearing MUST face the nut). Then the hardened washer slides onto the threaded rod. (Scheme 100) Once assembled coat the threaded rod's threads with Mopar® Nickel Anti-Seize or (Loctite No. 771). 1 - SPECIAL TOOL 8512A
3. Using the Damper Installer 8512A (1), press damper onto the crankshaft. (Scheme 101)
4. Install then tighten crankshaft damper bolt to 175 N.m (130 ft. lbs.).
5. Install accessory drive belt. Refer to «INSTALLATION»(ref-306154-S38527570572008120900000).
6. Connect negative cable to battery.

STRUCTURAL DUST COVER

The structural dust cover is made of die cast aluminum and joins the lower half of the transmission bell housing to the engine bedplate.

The structural cover provides additional powertrain stiffness and reduces noise and vibration.

Scheme 102

1. Raise vehicle on hoist.
2. Remove the bolts (1) retaining structural cover. (Scheme 102)
3. Remove the structural cover.

STRUCTURAL COVER

1. Position the structural cover in the vehicle.
2. Install all bolts (1) retaining the cover-to-engine. DO NOT tighten the bolts at this time.
3. Install the cover-to-transmission bolts. Do NOT tighten at this time. CAUTION: The structural cover must be held tightly against both the engine and the transmission bell housing during tightening sequence. Failure to do so may cause damage to the cover.
4. Starting with the two rear cover-to-engine bolts, tighten bolts (1) to 54 N.m (40 ft. lbs.), then tighten bolts (2) and (3) to 54 N.m (40 ft. lbs.) in the sequence see scheme 131

Scheme 103

Scheme 104

1. Disconnect the negative cable from the battery. CAUTION: Remove the fan blade, fan clutch and fan shroud before raising engine. Failure to do so may cause damage to the fan blade, fan clutch and fan shroud.
2. Remove the fan blade, fan clutch and fan shroud. Refer to «COOLING»(ref-306154) article for procedure.
3. Remove the engine oil filter.
4. Support the engine with a suitable jack and a block of wood across the full width of the engine oil pan.
5. Remove the four cylinder block-to-insulator mount bolts (5) and the nut from the engine insulator mount through bolt. 1 - MOUNT 2 - THRU BOLT 3 - BOLT 4 - NUT
6. Using the jack, raise the engine high enough to remove the engine insulator mount thru bolt (2) and the insulator mount and. (Scheme 103)and (Scheme 104).

ENGINE MOUNT - REAR

Note. A resilient rubber cushion supports the transmission at the rear between the transmission extension housing and the rear support crossmember or skid plate.

1. Disconnect negative cable from battery.
2. Raise the vehicle and support the transmission.
3. Remove the nuts holding the support cushion to the crossmember. Remove the crossmember.

MANUAL TRANSMISSION

1. Remove the support cushion nuts and remove the cushion.
2. Remove the transmission support bracket bolts and remove the bracket from the transmission.

AUTOMATIC TRANSMISSION

1. Remove the support cushion bolts and remove the cushion and the support bracket from the transmission (4WD) or from the Adapter bracket (2WD).
2. On 2WD vehicles, remove the bolts holding the transmission support Adapter bracket to the transmission. Remove the Adapter bracket.

Scheme 105

Scheme 106

1. Install the transmission mount (1) to the transmission. Install the bolts (2) and tighten.
2. Position the crossmember in the vehicle. Install the crossmember to mount through bolt and nut.
3. Install crossmember-to-sill bolts and tighten to 41 N.m (30 ft. lbs.)
4. Remove the transmission support.
5. Lower the vehicle.
6. Connect negative cable to battery.

Scheme 107

Scheme 108

1. Install the transmission mount to transmission and install the bolts. (Scheme 107)and (Scheme 108).
2. Position the crossmember in the vehicle. Install the crossmember to mount through bolt and nut.
3. Remove the transmission support.
4. Lower the vehicle.
5. Connect negative cable to battery.

ENGINE OIL LEAK

Begin with a thorough visual inspection of the engine, particularly at the area of the suspected leak. If an oil leak source is not readily identifiable, the following steps should be followed

1. Do not clean or degrease the engine at this time because some solvents may cause rubber to swell, temporarily stopping the leak.
2. Add an oil soluble dye (use as recommended by manufacturer). Start the engine and let idle for approximately 15 minutes. Check the oil dipstick to make sure the dye is thoroughly mixed as indicated with a bright yellow color under a black light.
3. Using a black light, inspect the entire engine for fluorescent dye, particularly at the suspected area of oil leak. If the oil leak is found and identified, repair per service information instructions.
4. If dye is not observed, drive the vehicle at various speeds for approximately 24 km (15 miles), and repeat inspection. If the oil leak source is not positively identified at this time , proceed with the AIR LEAK DETECTION TEST METHOD.

Since it is sometimes difficult to determine the source of an oil leak in the rear seal area of the engine, a more involved inspection is necessary. The following steps should be followed to help pinpoint the source of the leak.

If the leakage occurs at the crankshaft rear oil seal area

1. Disconnect the battery.
2. Raise the vehicle.
3. Remove torque converter or clutch housing cover and inspect rear of block for evidence of oil. Use a black light to check for the oil leak: Circular spray pattern generally indicates seal leakage or crankshaft damage. Where leakage tends to run straight down, possible causes are a porous block, oil galley pipe plugs, oil filter runoff, and main bearing cap to cylinder block mating surfaces. Refer to the appropriate component service information for proper repair procedures of these items.
4. If no leaks are detected, pressurize the crankcase as outlined in «AIR LEAK DETECTION TEST METHOD»(ref-306142-S37438529602008120900000) . CAUTION: Do not exceed 20.6 kPa (3 psi).
5. If the leak is not detected, very slowly turn the crankshaft and watch for leakage. If a leak is detected between the crankshaft and seal while slowly turning the crankshaft, it is possible the crankshaft seal surface is damaged. The seal area on the crankshaft could have minor nicks or scratches that can be polished out with emery cloth. CAUTION: Use extreme caution when crankshaft polishing is necessary to remove minor nicks or scratches. The crankshaft seal flange is specially machined to complement the function of the rear oil seal.
6. For bubbles that remain steady with shaft rotation, no further inspection can be done until disassembled. See «ENGINE LUBRICATION DIAGNOSTIC TABLE»(ref-306142-S41896910262008120900000) , under the OIL LEAK row, for components inspections on possible causes and corrections.
7. After the oil leak root cause and appropriate corrective action have been identified, see «REMOVAL»(ref-306142-S24832871802008120900000) .

Scheme 109

The engine oil level indicator (1) is located at the right rear of the engine on the 3.7L/4.7L engines. (Scheme 109)

ENGINE OIL CHANGE

Change engine oil at mileage and time intervals described in Maintenance Schedules.

Run engine until achieving normal operating temperature.

1. Position the vehicle on a level surface and turn engine off.
2. Hoist and support vehicle on safety stands.
3. Remove oil fill cap.
4. Place a suitable drain pan under crankcase drain.
5. Remove drain plug from crankcase and allow oil to drain into pan. Inspect drain plug threads for stretching or other damage. Replace drain plug if damaged.
6. Install drain plug in crankcase.
7. Lower vehicle and fill crankcase with specified type and amount of engine oil described in «SPECIFICATIONS»(ref-306142-S09472127992008120900000) .
8. Install oil fill cap.
9. Start engine and inspect for leaks.
10. Stop engine and inspect oil level.

Note. Care should be exercised when disposing used engine oil after it has been drained from a vehicle engine. Refer to the WARNING at beginning of this information .

Scheme 110

All engines are equipped with a high quality full-flow, disposable type oil filter. DaimlerChrysler Corporation recommends a Mopar® or equivalent oil filter be used.

1. Position a drain pan under the oil filter (1).
2. Using a suitable oil filter wrench loosen filter.
3. Rotate the oil filter counterclockwise to remove it from the cylinder block oil filter boss. (Scheme 110)
4. When filter separates from cylinder block oil filter boss, tip gasket end upward to minimize oil spill. Remove filter from vehicle. NOTE: Make sure filter gasket was removed with filter.
5. With a wiping cloth, clean the gasket sealing surface of oil and grime.

Scheme 111

1. Lightly lubricate oil filter gasket (2) with engine oil. (Scheme 111)
2. Thread filter (3) onto adapter nipple. When gasket makes contact with sealing surface, hand tighten filter one full turn, do not over tighten.
3. Add oil, verify crankcase oil level and start engine. Inspect for oil leaks.

Scheme 112

The engine oil pan (1) is made of laminated steel and has a single plane sealing surface. The sandwich style oil pan gasket has an integrated windage tray (2) and steel carrier. (Scheme 112) The sealing area of the gasket is molded with rubber and is designed to be reused as long as the gasket is not cut, torn or ripped.

OIL PAN

1. Clean oil pan in solvent and wipe dry with a clean cloth.
2. Clean the oil pan gasket surface. DO NOT use a grinder wheel or other abrasive tool to clean sealing surface.
3. Clean oil screen and tube thoroughly in clean solvent.

1. Inspect oil drain plug and plug hole for stripped or damaged threads. Repair as necessary.
2. Inspect the oil pan mounting flange for bends or distortion. Straighten flange, if necessary.

Scheme 113

1. Clean the oil pan gasket mating surface of the bedplate and oil pan.
2. Clean the oil pan and block gasket mating surfaces.
3. Inspect integrated oil pan gasket, and replace as necessary.
4. Drop the oil pump pick-up tube into the oil pan, and install the oil pan, pick-up tube, and the windage tray, as an assembly, from the front of the vehicle.
5. Install the windage tray, then the oil pump pick-up tube, and the (2) nuts and (1) bolt holding the oil pump pick-up tube, in place. NOTE: It will be necessary to move the oil pan from side to side to gain access to these fasteners.
6. Tighten the pick-up tube fasteners.
7. Install the oil pan.
8. Install and tighten the oil pan bolts. (Scheme 113)
9. Install the engine to transmission structural cover, (if equipped).
10. Lower the vehicle.
11. Lower the engine using Engine Support Fixture 8534.
12. Remove the Engine Support Fixture 8534.
13. Raise the vehicle.
14. Tighten both engine mount through bolts.
15. Install the transmission oil cooler line bracket.
16. Lower the vehicle.
17. Refill engine oil.
18. Reconnect battery.
19. Start engine and check for leaks.

OIL PRESSURE SENSOR

The oil pressure switch is a pressure sensitive switch that is activated by the engine's oil pressure (in the main oil gallery). The switch is a two terminal device (one terminal is provided to the wiring harness and the other terminal is the switch's metal housing that screws into the engine block).

OIL PRESSURE SWITCH

The oil pressure switch is normally "Closed." The switch changes from a "Closed" circuit to an "Open" circuit, on increasing pressure of 7 psig. The oil pressure switch changes from an "Open" circuit to a "Closed" circuit, on decreasing pressure, between 2 psig and 4 psig.

1. Disconnect the negative cable from the battery.
2. Raise vehicle on hoist.
3. Remove front splash shield.
4. Disconnect oil pressure sender wire (4).
5. Remove the pressure sender (2). see scheme 146

1. Install oil pressure sender.
2. Connect oil pressure sender wire.
3. Install front splash shield.
4. Lower vehicle.
5. Connect the negative battery cable.

OIL PUMP

1. Remove the oil pan and pick-up tube. See «REMOVAL»(ref-306142-S29879319962008120900000) .
2. Remove the timing chain cover. See «REMOVAL»(ref-306142-S29598169092008120900000) .
3. Remove the timing chains and tensioners. See «REMOVAL»(ref-306142-S28673550012008120900000) .
4. Remove the four bolts, primary timing chain tensioner and the oil pump.

1. Remove oil pump cover screws and lift off cover plate.
2. Remove pump inner and outer rotors. NOTE: Once the oil pressure relief valve, cup plug, and pin are removed, the pump assembly must be replaced.
3. If it is necessary to remove the pressure relief valve, drive the roll pin from pump housing and remove cup plug, spring and valve.

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

1. Clean all parts thoroughly. Mating surface of the oil pump housing should be smooth. If the pump cover is scratched or grooved the oil pump assembly should be replaced.
2. Lay a straight edge across the pump cover surface (3). If a 0.025 mm (0.001 in.) feeler gauge (2) can be inserted between the cover and the straight edge the oil pump assembly should be replaced.
3. Measure the thickness of the outer rotor. If the outer rotor thickness measures at 12.005 mm (0.472 in.) or less the oil pump assembly must be replaced.
4. Measure the diameter of the outer rotor. If the outer rotor diameter measures at 85.925 mm (3.382 in.) or less the oil pump assembly must be replaced.
5. Measure the thickness of the inner rotor. If the inner rotor thickness measures at 12.005 mm (0.472 in.) or less then the oil pump assembly must be replaced. 1 - FEELER GAUGE 2 - OUTER ROTOR
6. Slide outer rotor (2) into the body of the oil pump. Press the outer rotor to one side of the oil pump body and measure clearance between the outer rotor and the body. If the measurement is 0.235 mm (0.009 in.) or more the oil pump assembly must be replaced. 1 - OUTER ROTOR 2 - FEELER GAUGE 3 - INNER ROTOR
7. Install the inner rotor into the oil pump body. Measure the clearance between the inner (3) and outer (1) rotors. If the clearance between the rotors is .150 mm (0.006 in.) or more the oil pump assembly must be replaced. 1 - STRAIGHT EDGE 2 - FEELER GAUGE
8. Place a straight edge (1) across the body of the oil pump (between the bolt holes), if a feeler gauge (2) of .095 mm (0.0038 in.) or greater can be inserted between the straightedge and the rotors, the pump must be replaced.

Note. The 3.7L/4.7L Oil pump is released as an assembly. There are no DaimlerChrysler part numbers for Sub-Assembly components. In the event the oil pump is not functioning or out of specification it must be replaced as an assembly.

1. Wash all parts in a suitable solvent and inspect carefully for damage or wear.
2. Install inner and outer rotors
3. Install oil pump cover plate and install cover bolts and tighten them to 12 N.m (105 in. lbs.).
4. Prime oil pump before installation by filling rotor cavity with engine oil.
5. If oil pressure is low and pump is within specifications, inspect for worn engine bearings or other causes for oil pressure loss.

Scheme 120

1. Position the oil pump onto the crankshaft and install two oil pump retaining bolts.
2. Position the primary timing chain tensioner and install the two retaining bolts.
3. Tighten the oil pump and primary timing chain tensioner retaining bolts to 28 N.m (250 in. lbs.) in the sequence (Scheme 120)
4. Install the secondary timing chain tensioners and timing chains. See «INSTALLATION»(ref-306142-S24119590672008120900000).
5. Install the timing chain cover. See «INSTALLATION»(ref-306142-S34953854812008120900000).
6. Install the pick-up tube and oil pan. See «INSTALLATION»(ref-306142-S16036183492008120900000).

INTAKE MANIFOLD

The intake manifold is made of a composite material and features 300 mm (11.811 in.) long runners which maximizes low end torque. see scheme 154

Scheme 121

The intake manifold uses single plane sealing which consist of six individual press in place port gaskets (2) to prevent leaks. The throttle body attaches directly to the intake manifold.

INTAKE MANIFOLD LEAKS

An intake manifold air leak is characterized by lower than normal manifold vacuum. Also, one or more cylinders may not be functioning.

1. Start the engine.
2. Spray a small stream of water (spray bottle) at the suspected leak area.
3. If engine RPM'S change, the area of the suspected leak has been found.
4. Repair as required.

Scheme 122

Scheme 123

Scheme 124

1. Bleed the fuel system. Refer to «STANDARD PROCEDURE»(ref-306144-S17322326742008120900000) .
2. Disconnect the negative cable from battery.
3. Remove the resonator assembly and air inlet hose.
4. Drain the cooling system below coolant temperature sensor level.
5. Disconnect the electronic throttle control (ETC) connector (3). 1 - MOUNTING SCREWS 2 - MAP SENSOR 3 - ECT SENSOR 4 - FRONT OF INTAKE MANIFOLD
6. Disconnect electrical connectors for the following components: Coolant Temperature Sensor Manifold Absolute Pressure (MAP) Sensor (2)
7. Disconnect vapor purge hose, brake booster hose, and positive crankcase ventilation (PCV) hose.
8. Disconnect and remove ignition coil towers.
9. Remove the top oil dipstick tube retaining bolt.
10. Remove the EGR tube (1). Refer to «REMOVAL»(ref-306155-S28804806382008120900000) .
11. Remove fuel rail. Refer to «REMOVAL»(ref-306144-S07131895532008120900000) . 1 - THROTTLE BODY 2 - MOUNTING BOLTS 3 - ELEC. CONNECTOR
12. Remove throttle body assembly (1).
13. Remove the intake manifold retaining fasteners in reverse order of tightening sequence.
14. Remove the intake manifold.

Scheme 125

Scheme 126

Scheme 127

1. Install the intake manifold seals.
2. Install the intake manifold.
3. Install the intake manifold retaining bolts and tighten in sequence see scheme 161to 12 N.m (105 in. lbs.). 1 - THROTTLE BODY 2 - MOUNTING BOLTS 3 - ELEC. CONNECTOR CAUTION: Proper torque of the throttle body is critical to normal operation. If the throttle body is over-torqued, damage to the throttle body can occur resulting in throttle plate malfunction.
4. Install the throttle body-to-intake manifold O-ring.
5. Install the throttle body (1) to intake manifold.
6. Install the four mounting bolts (2). Tighten bolts to 7 N.m (60 in. lbs.).
7. Install electrical connector (3).
8. Install the fuel rail.
9. Install the EGR tube (1). Refer to «INSTALLATION»(ref-306155-S28175715192008120900000).
10. Install ignition coil towers. 1 - MOUNTING SCREWS 2 - MAP SENSOR 3 - ECT SENSOR 4 - FRONT OF INTAKE MANIFOLD
11. Connect electrical connectors for the following components: Manifold Absolute Pressure (MAP) Sensor (2) Coolant Temperature (CTS) Sensor Ignition coil towers
12. Install top oil dipstick tube retaining bolt.
13. Connect Vapor purge hose, Brake booster hose, Positive crankcase ventilation (PCV) hose.
14. Fill the cooling system.
15. Install the resonator assembly and air inlet hose.
16. Connect the negative cable to battery.
17. Using the scan tool, perform the ETC Relearn function.

Scheme 128

Scheme 129

The exhaust manifolds (1,2) are log style with a patented flow enhancing design to maximize performance. (Scheme 129) The exhaust manifolds are made of high silicon molybdenum cast iron. A perforated core graphite exhaust manifold gasket is used to improve sealing to the cylinder head. The exhaust manifolds are covered by a three layer laminated heat shield (3) for thermal protection and noise reduction. The heat shields are fastened with a torque prevailing nut that is backed off slightly to allow for the thermal expansion of the exhaust manifold.

Scheme 130

1. Disconnect the negative cable from the battery.
2. Raise and support the vehicle.
3. Remove the bolts and nuts attaching the exhaust pipe to the engine exhaust manifold.
4. Lower the vehicle.
5. Remove the exhaust heat shield (1).
6. Remove bolts, nuts and washers attaching manifold to cylinder head.
7. Remove manifold and gasket from the cylinder head. (Scheme 130)

Scheme 131

1. Disconnect the negative cable from the battery.
2. Raise and support the vehicle.
3. Remove the bolts and nuts attaching the exhaust pipe to the engine exhaust manifold.
4. Lower the vehicle.
5. Remove the exhaust heat shields (1).
6. Remove bolts, nuts and washers attaching manifold to cylinder head.
7. Remove manifold and gasket from the cylinder head. (Scheme 131)

RIGHT EXHAUST MANIFOLD

1. Position the engine exhaust manifold and gasket on the two studs located on the cylinder head. Install conical washers and nuts on these studs.
2. Install remaining conical washers. Starting at the center arm and working outward, tighten the bolts and nuts to 25 N.m (18 ft. lbs.)
3. Install the exhaust heat shields.
4. Raise and support the vehicle. CAUTION: Over tightening heat shield fasteners, may cause shield to distort and/or crack.
5. Assemble exhaust pipe to manifold and secure with bolts, nuts and retainers. Tighten the bolts and nuts to 34 N.m (25 ft. lbs.)

LEFT EXHAUST MANIFOLD

1. Position the engine exhaust manifold and gasket on the two studs located on the cylinder head. Install conical washers and nuts on these studs.
2. Install remaining conical washers. Starting at the center arm and working outward, tighten the bolts and nuts to 25 N.m (18 ft. lbs.)
3. Install the exhaust heat shields.
4. Raise and support the vehicle. CAUTION: Over tightening heat shield fasteners, may cause shield to distort and/or crack.
5. Assemble exhaust pipe to manifold and secure with bolts, nuts and retainers. Tighten the bolts and nuts to 34 N.m (25 ft. lbs.)

Scheme 132

The timing drive system has been designed to provide quiet performance and reliability to support a non-free wheeling engine. Specifically the intake valves are non-free wheeling and can be easily damaged with forceful engine rotation if camshaft-to-crankshaft timing is incorrect. The timing drive system consists of a primary chain (6), two secondary timing chain drives (1,4) and a counterbalance shaft drive. (Scheme 132)

TIMING DRIVE

The primary timing chain is a single inverted tooth chain type. The primary chain drives the large 50 tooth idler sprocket directly from a 25 tooth crankshaft sprocket. Primary chain motion is controlled by a pivoting leaf spring tensioner arm and a fixed guide. The arm and the guide both use nylon plastic wear faces for low friction and long wear. The primary chain receives oil splash lubrication from the secondary chain drive and designed oil pump leakage. The idler sprocket assembly connects the primary chain drive, secondary chain drives, and the counterbalance shaft. The idler sprocket assembly consists of two integral 26 tooth sprockets a 50 tooth sprocket and a helical gear that is press-fit to the assembly. The spline joint for the 50 tooth sprocket is a non serviceable press fit anti rattle type. The idler sprocket assembly spins on a stationary idler shaft. The idler shaft is a light press-fit into the cylinder block. A large washer on the idler shaft bolt and the rear flange of the idler shaft are used to control sprocket thrust movement. Pressurized oil is routed through the center of the idler shaft to provide lubrication for the two bushings used in the idler sprocket assembly.

There are two secondary drive chains, both are roller type, one to drive the camshaft in each SOHC cylinder head. There are no shaft speed changes in the secondary chain drive system. Each secondary chain drives a 26 tooth cam sprocket directly from the 26 tooth sprocket on the idler sprocket assembly. A fixed chain guide and a hydraulic oil damped tensioner are used to maintain tension in each secondary chain system. The hydraulic tensioners for the secondary chain systems are fed pressurized oil from oil reservoir pockets in the block. Each tensioner incorporates a controlled leak path through a device known as a vent disc located in the nose of the piston to manage chain loads. Each tensioner also has a mechanical ratchet system that limits chain slack if the tensioner piston bleeds down after engine shut down. The tensioner arms and guides also utilize nylon wear faces for low friction and long wear. The secondary timing chains receive lubrication from a small orifice in the tensioners. This orifice is protected from clogging by a fine mesh screen which is located on the back of the hydraulic tensioners.

Scheme 133

Note. This procedure must be performed with the timing chain cover removed.

1. Remove the timing chain cover. See «REMOVAL»(ref-306142-S28673550012008120900000).
2. To determine if the secondary timing chains are worn, rotate the engine clockwise until maximum tensioner piston (2) extension is obtained. Measure the distance between the secondary timing chain tensioner housing and the step ledge on the piston. The measurement at point (A) must be less than 15 mm (.5906 inches). (Scheme 133)
3. If the measurement exceeds the specification the secondary timing chains are worn and require replacement. See «REMOVAL»(ref-306142-S28673550012008120900000).

TIMING VERIFICATION

Note. Components referred to as left hand or right hand are as viewed from the drivers position inside the vehicle.

Note. The blue link plates on the chains and the dots on the camshaft drive sprockets may not line up during the timing verification procedure. The blue link plates are lined up with the sprocket dots only when re-timing the complete timing drive. Once the timing drive is rotated blue link-to-dot alignment is no longer valid.

Engine base timing can be verified by the following procedure

Scheme 134

1. Remove the cylinder head covers. Refer to «REMOVAL»(ref-306142-S12051049862008120900000) for left side or «REMOVAL»(ref-306142-S07155423102008120900000) for right side.
2. Using a mirror, locate the TDC arrow on the front cover. Rotate the crankshaft until the mark on the crankshaft damper (2) is aligned with the TDC arrow on the front cover (2). The engine is now at TDC. see scheme 171 1 - LEFT CYLINDER HEAD 2 - RIGHT CYLINDER HEAD
3. Note the location of the V6 mark stamped into the camshaft drive gears (1,2). If the V6 mark on each camshaft drive gear is at the twelve o'clock position, the engine is at TDC on the exhaust stroke. If the V6 mark on each gear is at the six o'clock position, the engine is at TDC on the compression stroke. (Scheme 134)
4. If both of the camshaft drive gears are off in the same or opposite directions, the primary chain or both secondary chains are at fault. Refer to «CHAIN AND SPROCKETS-TIMING»(ref-306142-S36793491762008120900000).
5. If only one of the camshaft drive gears is off and the other is correct, the problem is confined to one secondary chain. Refer to «TIMING - SINGLE CAMSHAFT»(ref-306142-S14722536052008120900000).
6. If both camshaft drive gear V6 marks are at the twelve o'clock or the six o'clock position the engine base timing is correct. Reinstall the cylinder head covers.

Scheme 135

1. Ensure that the engine is at TDC with both camshaft sprocket V6 marks in the 12 o'clock position.
2. Look down the left cylinder head chain cavity. The timing dot (2) on the counter balance shaft drive gear should be in the 6 o'clock position. (Scheme 135)

Scheme 136

Note. to adjust the timing on one camshaft, preform the following procedure.

Scheme 137

1. Using the Wedge Locking Tool 8379 (2), stabilize the secondary chain drive. For reference purposes, mark the chain-to-sprocket position. (Scheme 136) 1 - SPECIAL TOOL 8379 TIMING CHAIN WEDGE 2 - CAMSHAFT DRIVE GEAR 3 - RETAINING BOLT 4 - CYLINDER HEAD
2. Remove the camshaft drive gear retaining bolt (3). (Scheme 137)
3. Carefully remove the camshaft drive gear from the camshaft. 1 - LEFT CYLINDER HEAD 2 - RIGHT CYLINDER HEAD
4. Re-index the camshaft drive gear in the chain until the V6 mark is at the same position as the V6 mark on the opposite camshaft drive gear (1,2). see scheme 176
5. Using the Camshaft Holder 8428, rotate the camshaft until the alignment dowel on the camshaft is aligned with the slot in the camshaft drive gear. CAUTION: Remove excess oil from camshaft sprocket retaining bolt before reinstalling bolt. Failure to do so may cause over-torqueing of bolt resulting in bolt failure.
6. Position the camshaft drive gear onto the camshaft, remove oil from bolt then install the retaining bolt. Using Special Tools, Spanner Wrench 6958 with Adapter Pins 8346 and a suitable torque wrench. Tighten the retaining bolt to 122 N.m (90 ft. lbs.).
7. Remove the Wedge Locking Tool 8379.
8. Rotate the crankshaft two full revolutions, then verify that the camshaft drive gear V6 marks are in fact aligned.
9. Install the cylinder head covers. Refer to «INSTALLATION»(ref-306142-S22568602322008120900000) for left side or «INSTALLATION»(ref-306142-S07052064472008120900000) for right side.

Scheme 138

Scheme 139

1. Remove the primary and secondary timing chains. Refer to «CHAIN AND SPROCKETS-TIMING»(ref-306142-S36793491762008120900000). NOTE: The balance shaft and gear are serviced as an assembly. Do not attempt to remove the gear from the balance shaft. Remove the retaining bolt (4) from the counterbalance shaft thrust plate (2). (Scheme 138) 1 - COUNTERBALANCE SHAFT REMOVAL AND INSTALLATION TOOL 2 - COUNTERBALANCE SHAFT THRUST PLATE
2. Using the Counterbalance Shaft Remover/Installer tool 8641 (1), remove the counterbalance shaft from the engine. (Scheme 139)

BALANCE SHAFT

Note. The balance shaft and gear are serviced as an assembly. Do not attempt to remove the gear from the balance shaft.

1. Coat counterbalance shaft bearing journals with clean engine oil. NOTE: The balance shaft is heavy, and care should be used when installing shaft, so bearings are not damaged.
2. Using the Counterbalance Shaft Remover/Installer 8641 (1), carefully install counterbalance shaft into engine. see scheme 179 1 - IDLER SHAFT 2 - COUNTERBALANCE SHAFT THRUST PLATE 3 - COUNTERBALANCE SHAFT DRIVE GEAR 4 - RETAINING BOLT
3. Install Counterbalance shaft thrust plate retaining bolt (4) finger tight. Do not tighten bolt at this time.
4. Position the right side of the thrust plate with the right chain guide bolt, install bolt finger tight.
5. Tighten the thrust plate retaining bolt (4) to 28 N.m (250 in. lbs.). see scheme 180
6. Remove the chain guide bolt so that guide can be installed.

Scheme 140

Scheme 141

1. Disconnect the battery negative cable.
2. Drain cooling system. Refer to «STANDARD PROCEDURE»(ref-306154-S25259837052008120900000).
3. Remove electric cooling fan and fan shroud assembly.
4. Remove fan and fan drive assembly.
5. Disconnect both heater hoses at timing cover.
6. Disconnect lower radiator hose at engine.
7. Remove accessory drive belt tensioner assembly (1). (Scheme 140)
8. Remove crankshaft damper. See «REMOVAL»(ref-306142-S14186681422008120900000).
9. Remove the generator. Refer to «REMOVAL»(ref-306161-S35576092952008120900000).
10. Remove the A/C compressor. Refer to «REMOVAL»(ref-306135-S11256117642008120900000). CAUTION: The 3.7L engine uses an anaerobic sealer instead of a gasket to seal the front cover to the engine block, from the factory. For service, Mopar® Grey Engine RTV sealant must be substituted. NOTE: It is not necessary to remove the water pump for timing cover removal.
11. Remove the bolts holding the timing cover to engine block. (Scheme 141)
12. Remove the timing cover.

Scheme 142

1. Clean timing chain cover and block surface using rubbing alcohol. CAUTION: The 3.7L uses a special anaerobic sealer instead of a gasket to seal the timing cover to the engine block, from the factory. For service repairs, Mopar® Grey Engine RTV must be used as a substitute.
2. Inspect the water passage o-rings for any damage, and replace as necessary.
3. Apply Mopar® Grey Engine RTV sealer (3) to the front cover following the path below, using a 3 to 4 mm thick bead. (Scheme 142)
4. Install cover. Tighten flange head fasteners in sequence see scheme 184to 58 N.m (43 ft. lbs.).
5. Install crankshaft damper. See «INSTALLATION»(ref-306142-S42050284672008120900000).
6. Install the A/C compressor. Refer to «INSTALLATION»(ref-306135-S17764719442008120900000).
7. Install the generator. Refer to «INSTALLATION»(ref-306161-S23448537052008120900000).
8. Install accessory drive belt tensioner assembly. Refer to «INSTALLATION»(ref-306154-S23311004022008120900000).
9. Install radiator upper and lower hoses.
10. Install both heater hoses.
11. Install electric fan shroud and viscous fan drive assembly.
12. Fill cooling system. Refer to «STANDARD PROCEDURE»(ref-306154-S25259837052008120900000).
13. Connect the battery negative cable.

IDLER SHAFT

1. Remove the primary and secondary timing chains and sprockets. Refer to «CHAIN AND SPROCKETS-TIMING»(ref-306142-S36793491762008120900000) . NOTE: To remove the idler shaft, it is necessary to tap threads into the shaft, to install the removal tool.
2. Using a 12 mm X 1.75 tap, cut threads in the idler shaft center bore.
3. Cover the radiator core with a suitable cover. CAUTION: Use care when removing the idler shaft, Do not strike the radiator cooling fins with the slide hammer.
4. Using Slide Hammer 8517 remove the idler shaft.

1. Thoroughly clean the idler shaft bore.
2. Position the idler shaft in the bore. NOTE: The two lubrication holes in the idler shaft do not require any special alignment. NOTE: Before using the retaining bolt to install the idler shaft, coat the threads and the pilot on the idler shaft, with clean engine oil.
3. Using the primary idler sprocket retaining bolt and washer, carefully draw the idler shaft into the bore until fully seated.
4. Coat the idler shaft with clean engine oil.
5. Install the timing chains and sprockets. Refer to «CHAIN AND SPROCKETS-TIMING»(ref-306142-S36793491762008120900000) .

Scheme 143

Scheme 144

Scheme 145

Scheme 146

1. Disconnect negative cable from battery.
2. Drain cooling system. Refer to «STANDARD PROCEDURE»(ref-306154-S25259837052008120900000).
3. Remove right and left cylinder head covers. See «REMOVAL»(ref-306142-S12051049862008120900000) for left side or «REMOVAL»(ref-306142-S07155423102008120900000) for right side.
4. Remove radiator fan shroud. Refer to «REMOVAL»(ref-306154-S21887878352008120900000).
5. Rotate engine until timing mark on crankshaft damper (2) aligns with TDC mark on timing chain cover (2) and the camshaft sprocket "V6" marks are at the 12 o'clock position (No. 1 TDC exhaust stroke). (Scheme 143)and (Scheme 144). 1 - RIGHT CYLINDER HEAD ACCESS PLUG 2 - LEFT CYLINDER HEAD ACCESS PLUG
6. Remove power steering pump. Refer to «REMOVAL»(ref-306136-S10202713142008120900000).
7. Remove access plug from left and right cylinder heads for access to chain guide fasteners. (Scheme 145)
8. Remove the oil fill housing to gain access to the right side tensioner arm fastener.
9. Remove crankshaft damper and timing chain cover. See «REMOVAL»(ref-306142-S14186681422008120900000) and «REMOVAL»(ref-306142-S29598169092008120900000). 1 - CYLINDER HEAD 2 - CAMSHAFT POSITION SENSOR 3 - SCREW
10. Collapse and pin primary chain tensioner. CAUTION: Plate behind left secondary chain tensioner could fall into oil pan. Therefore, cover pan opening.
11. Remove secondary chain tensioners.
12. Remove camshaft position sensor (2). (Scheme 146) 1 - Camshaft hole 2 - Special Tool 8428 CAUTION: Care should be taken not to damage camshaft target wheel. Do not hold target wheel while loosening or tightening camshaft sprocket. Do not place the target wheel near a magnetic source of any kind. A damaged or magnetized target wheel could cause a vehicle no start condition. CAUTION: Do not forcefully rotate the camshafts or crankshaft independently of each other. Damaging intake valve to piston contact will occur. Ensure negative battery cable is disconnected to guard against accidental starter engagement.
13. Remove left and right camshaft sprocket bolts.
14. While holding the left camshaft steel tube with Camshaft Holder 8428 (2), remove the left camshaft sprocket. see scheme 189 Slowly rotate the camshaft approximately 5 degrees clockwise to a neutral position.
15. While holding the right camshaft steel tube with Camshaft Holder 8428 (2), remove the right camshaft sprocket.
16. Remove idler sprocket assembly bolt.
17. Slide the idler sprocket assembly and crank sprocket forward simultaneously to remove the primary and secondary chains.
18. Remove both pivoting tensioner arms and chain guides.
19. Remove primary chain tensioner.

TIMING CHAIN AND SPROCKETS

Inspect the following components

1. Sprockets for excessive tooth wear. Some tooth markings are normal and not a cause for sprocket replacement.
2. Idler sprocket assembly bushing and shaft for excessive wear.
3. Idler sprocket assembly spline joint. The joint should be tight with no backlash or axial movement.
4. Chain guides and tensioner arms. Replace these parts if grooving in plastic face is more than 1 mm (0.039 in.) deep. If plastic face is severely grooved or melted, the tensioner lube jet may be clogged. The tensioner should be replaced.
5. Secondary chain tensioner piston and ratcheting device. Inspect for evidence of heavy contact between tensioner piston and tensioner arm. If this condition exist the tensioner arm and chain should be replaced.
6. Primary chain tensioner plastic faces. Replace as required.

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

1. Using a vise, lightly compress the secondary chain tensioner piston (5) until the piston step is flush with the tensioner body. Using a pin or suitable tool, release ratchet pawl by pulling pawl back against spring force through access hole on side of tensioner. While continuing to hold pawl back, Push ratchet device to approximately 2 mm from the tensioner body. Install Tensioner pin 8514 (3) into hole on front of tensioner. Slowly open vise (1) to transfer piston spring force to lock pin. (Scheme 147)
2. Position primary chain tensioner over oil pump and insert bolts into lower two holes on tensioner bracket. Tighten bolts to 28 N.m (250 in. lbs.). 1 - SPECIAL TOOL 8429 2 - PRIMARY CHAIN IDLER SPROCKET 3 - CRANKSHAFT SPROCKET
3. Install right side chain tensioner arm. Install Torx® bolt. Tighten Torx® bolt to 28 N.m (250 in. lbs.). CAUTION: The silver bolts retain the guides to the cylinder heads and the black bolts retain the guides to the engine block.
4. Install the left side chain guide. Tighten the bolts to 28 N.m (250 in. lbs.).
5. Install left side chain tensioner arm, and Torx® bolt. Tighten Torx® bolt to 28 N.m (250 in. lbs.).
6. Install the right side chain guide. Tighten the bolts to 28 N.m (250 in. lbs.).
7. Install both secondary chains onto the idler sprocket. Align two plated links on the secondary chains to be visible through the two lower openings on the idler sprocket (4 o'clock and 8 o'clock). Once the secondary timing chains are installed, position the Secondary Camshaft Chain Holder 8429 (1) to hold chains in place for installation. (Scheme 148)
8. Align primary chain double plated links with the timing mark at 12 o'clock on the idler sprocket. Align the primary chain single plated link with the timing mark at 6 o'clock on the crankshaft sprocket.
9. Lubricate idler shaft and bushings with clean engine oil. 1 - COUNTERBALANCE SHAFT GEAR 2 - TIMING MARK 3 - IDLER SPROCKET GEAR NOTE: The idler sprocket must be timed to the counterbalance shaft drive gear before the idler sprocket is fully seated.
10. Install all chains, crankshaft sprocket, and idler sprocket as an assembly. After guiding both secondary chains through the block and cylinder head openings, affix chains with a elastic strap or equivalent. This will maintain tension on chains to aid in installation. Align the timing mark (2) on the idler sprocket gear (3) to the timing mark on the counterbalance shaft drive gear (1), then seat idler sprocket fully. Before installing idler sprocket bolt, lubricate washer with oil, and tighten idler sprocket assembly retaining bolt to 34 N.m (25 ft. lbs.). see scheme 192 NOTE: It will be necessary to slightly rotate camshafts for sprocket installation.
11. Align left camshaft sprocket "L" dot to plated link on chain.
12. Align right camshaft sprocket "R" dot to plated link on chain. see scheme 193 CAUTION: Remove excess oil from the camshaft sprocket bolt. Failure to do so can result in over-torque of bolt resulting in bolt failure.
13. Remove Secondary Camshaft Chain Holder 8429, then attach both sprockets to camshafts. Remove excess oil from bolts, then Install sprocket bolts, but do not tighten at this time.
14. Verify that all plated links are aligned with the marks on all sprockets and the "V6" marks on camshaft sprockets are at the 12 o'clock position. 1 - TORQUE WRENCH 2 - CAMSHAFT SPROCKET 3 - LEFT CYLINDER HEAD 4 - SPECIAL TOOL 6958 SPANNER WITH ADAPTER PINS 8346 1 - TORQUE WRENCH 2 - SPECIAL TOOL 6958 WITH ADAPTER PINS 8346 3 - LEFT CAMSHAFT SPROCKET 4 - RIGHT CAMSHAFT SPROCKET CAUTION: Ensure the plate between the left secondary chain tensioner and block is correctly installed.
15. Install both secondary chain tensioners. Tighten bolts to 28 N.m (250 in. lbs.). NOTE: Left and right secondary chain tensioners are not common.
16. Remove all 3 locking pins from tensioners. CAUTION: After pulling locking pins out of each tensioner, DO NOT manually extend the tensioner(s) ratchet. Doing so will over tension the chains, resulting in noise and/or high timing chain loads.
17. Using Spanner Wrench 6958 with Adapter Pins 8346, (4) tighten left and right camshaft sprocket bolts to 122 N.m (90 ft. lbs.). (Scheme 149)and (Scheme 150).
18. Rotate engine two full revolutions. Verify timing marks are at the follow locations: primary chain idler sprocket dot is at 12 o'clock primary chain crankshaft sprocket dot is at 6 o'clock secondary chain camshaft sprockets "V6" marks are at 12 o'clock counterbalancer shaft drive gear dot is aligned to the idler sprocket gear dot
19. Lubricate all three chains with engine oil. 1 - IDLER SPROCKET ASSEMBLY 2 - DIAL INDICATOR
20. After installing all chains, it is recommended that the idler gear end play be checked. The end play must be within 0.10 - 0.25 mm (0.004 - 0.010 in.). If not within specification, the idler gear must be replaced. (Scheme 151)
21. Install timing chain cover and crankshaft damper. Refer to «INSTALLATION»(ref-306142-S34953854812008120900000) for timing cover and «INSTALLATION»(ref-306142-S42050284672008120900000) for damper.
22. Install cylinder head covers. See «INSTALLATION»(ref-306142-S22568602322008120900000) for left side or «INSTALLATION»(ref-306142-S07052064472008120900000) for right side. 1 - RIGHT CYLINDER HEAD ACCESS PLUG 2 - LEFT CYLINDER HEAD ACCESS PLUG NOTE: Before installing threaded plug in right cylinder head, the plug must be coated with sealant to prevent leaks.
23. Coat the large threaded access plug with Mopar® Thread Sealant with Teflon, then install into the right cylinder head (1) and tighten to 81 N.m (60 ft. lbs.). see scheme 197
24. Install the oil fill housing.
25. Install access plug in left cylinder head (2).
26. Install power steering pump. Refer to «INSTALLATION»(ref-306136-S41108533942008120900000).
27. Fill cooling system. Refer to «STANDARD PROCEDURE»(ref-306154-S25259837052008120900000).
28. Connect negative cable to battery.
