SPECIFICATIONS
| DESCRIPTION | SPECIFICATION |
|---|---|
| Transaxle Type | Fully adaptive, electronically controlled, four speed automatic with torque converter and integral differential |
| Cooling Method | Air-to-oil heat exchanger |
| Lubrication | Pump (internal-external gear-type |
GENERAL SPECIFICATIONS
| DESCRIPTION | SPECIFICATION |
|---|---|
| First Gear | 2.84 :1 |
| Second Gear | 1.57 :1 |
| Direct Gear | 1.00 :1 |
| Overdrive Gear | 0.69 :1 |
| Reverse Gear | 2.21 :1 |
GEAR RATIOS
| DESCRIPTION | METRIC | STANDARD |
|---|---|---|
| Differential Assembly | 0.6-2 N.m | 5-18 in. lbs. |
| Output Hub | 0.3-2 N.m | 3-8 in. lbs. |
| Transfer Shaft (End Play) | 0.051-0.102 mm | 0.002-0.004 in. |
| Overall Drag At Output Hub | 0.3-1.9 N.m | 3-16 in. lbs. |
BEARING SETTINGS (END PLAY AND TURNING TORQUE)
| DESCRIPTION | METRIC | STANDARD |
|---|---|---|
| Low/Reverse Clutch (Select Reaction Plate) | 0.89-1.47 mm | 0.035-0.058 in. |
| 2/4 Clutch (No Selection) | 0.76-2.64 mm | 0.030-0.104 in. |
| Reverse Clutch (Select Snap Ring) | 0.89-1.37 mm | 0.035-0.054 in. |
| Overdrive Clutch (No Selection) | 1.07-3.25 mm | 0.042-0.128 in. |
| Underdrive Clutch (Select Pressure Plate) | 0.94-1.50 mm | 0.037-0.059 in. |
CLUTCH CLEARANCES
| Description | Metric | Standard |
|---|---|---|
| Front Sun Gear Bushings | 29.55 - 29.60 mm | 1.163 -1.165 in. |
| Rear Carrier Bushing | 29.75 - 30.00 mm | 1.171 - 1.181 in. |
| Overdrive Hub / Shaft Bushing | 21.52 - 21.58 mm | 0.847 - 0.850 in. |
| Front / Rear Carrier Pinion end Play | 0.15 - 0.61 mm | 0.006 - 0.024 in. |
| Torque Converter Hub Bushing | 38.019 - 38.11 | 1.499 - 1.501 in. |
GEAR TRAIN MEASUREMENTS
| DESCRIPTION | METRIC | STANDARD |
|---|---|---|
| Outer Gear-to-Crescent | 0.060-0.298 mm | 0.0023-0.0117 in. |
| Inner Gear-to-Crescent | 0.093-0.385 mm | 0.0036-0.0151 in. |
| Outer Gear-to-Pocket | 0.089-0.202 mm | 0.0035-0.0079 in. |
| Outer Gear Side Clearance | 0.020-0.046 mm | 0.0008-0.0018 in. |
| Inner Gear Side Clearance | 0.020-0.046 mm | 0.0008-0.0018 in. |
| Reaction Support Sleeve | 45.27 - 45.31 mm | 1.782 - 1.784 in. |
OIL PUMP CLEARANCES
| DESCRIPTION | METRIC | SPECIFICATION |
|---|---|---|
| End Play | 0.13-0.64 mm | 0.005-0.025 in. |
INPUT SHAFT
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Bolt, Differential Cover-to-Case | 19 | 165 | |
| Bolt, Differential Ring Gear-to-Differential | 95 | 70 | |
| Bolt, Differential Bearing Retainer-to-Case | 28 | 21 | 250 |
| Bolt, Driveplate-to-Crankshaft | 95 | 70 | |
| Bolt, Extension Housing/Plate-to-Case | 28 | 21 | 250 |
| Bolt, Oil Pan-to-Case | 19 | 165 | |
| Bolt, Output Gear | 271 | 200 | |
| Bolt, Output Gear Stirrup/Strap | 23 | 17 | 200 |
| Bolt, Oil Pump-to-Case | 27 | 20 | |
| Bolt, Reaction Support-to-Case | 27 | 20 | |
| Bolt, Solenoid/Pressure Switch Assy.-to-Case | 12 | 106 | |
| Bolt, Torque Converter-to-Driveplate | 88 | 65 | |
| Bolt, Transfer Gear Cover | 20 | 175 | |
| Bolt, Valve Body-to-Case | 12 | 105 | |
| Fitting, Oil Cooler Line | 12 | 105 | |
| Nut, Transfer Gear | 271 | 200 | |
| Tap, Transaxle Pressure | 5 | 45 | |
| Screw, L/R Clutch Retainer | 5 | 45 | |
| Screw, Solenoid/Pressure Switch Assy. Connector | 4 | 35 | |
| Screw, Valve Body-to-Transfer Plate | 5 | 45 | |
| Sensor, Input Speed | 27 | 20 | |
| Sensor, Output Speed | 27 | 20 | |
| Sensor, Transmission Range Sensor | 5 | 45 | |
| Bolts, Transaxle-to-Engine | 75 | 55 | |
| Bolts, Differental Cover | 28 | 21 | 250 |
| Screw, Shifter Cable to Transaxle | 14 | 125 | |
| Nut, Cable Adjuster | 23 | 200 | |
| Nuts, Shifter Mechanism to Floor Pan | 17 | 150 | |
| Bolt, Rear Mount through | 70 | 55 |
TORQUE SPECIFICATIONS
Scheme 222
Scheme 223
Scheme 224
Scheme 225
Scheme 226
Scheme 227
Scheme 228
Scheme 229
Scheme 230
Scheme 231
Scheme 232
Scheme 233
Scheme 234
Scheme 235
Scheme 236
Scheme 237
Scheme 238
Scheme 239
Scheme 240
Scheme 241
Scheme 242
Scheme 243
Scheme 244
Scheme 245
Scheme 246
Scheme 247
Scheme 248
Scheme 249
Scheme 250
Scheme 251
Scheme 252
Scheme 253
Scheme 254
Scheme 255
Scheme 256
Scheme 257
Scheme 258
Scheme 259
Scheme 260
Scheme 261
Scheme 262
Scheme 263
Scheme 264
Scheme 265
Scheme 266
Scheme 267
| 1 - RETURN SPRING |
|---|
| 2 - UNDERDRIVE CLUTCH ACCUMULATOR |
| 3 - SEAL RING (2) |
| 4 - OVERDRIVE CLUTCH ACCUMULATOR |
The 41TE underdrive, overdrive, low/reverse, and 2/4 clutch hydraulic circuits each contain an accumulator. An accumulator typically consists of a piston (2), seal rings (3) return spring(s) (1) and a cover or plug. The overdrive and underdrive accumulators are located within the transaxle case, and are retained by the valve body.
| 1 - ACCUMULATOR PISTON |
|---|
| 2 - SEAL RINGS |
| 3 - RETURN SPRINGS |
| 4 - (NOTE NOTCH) |
The low reverse accumulator (1) is also located within the transaxle case, but the assembly is retained by a cover and a snap-ring.
Scheme 268
| 1 - VALVE BODY |
|---|
| 2 - RETAINER PLATE |
| 3 - DETENT SPRING |
| 4 - SPRINGS |
| 5 - SEALS |
| 6 - PISTON |
The 2/4 accumulator is located in the valve body (1) . It is retained by a cover and retaining screws.
TORQUE CONVERTER CLUTCH (TCC)
In a standard torque converter, the impeller and turbine are rotating at about the same speed and the stator is freewheeling, providing no torque multiplication. By applying the turbine's piston to the front cover's friction material, a total converter engagement can be obtained. The result of this engagement is a direct 1:1 mechanical link between the engine and the transmission.
The engagement and disengagement of the TCC are automatic and controlled by the Powertrain Control Module (PCM). The engagement cannot be activated in the lower gears because it eliminates the torque multiplication effect of the torque converter necessary for acceleration. Inputs that determine clutch engagement are: coolant temperature, vehicle speed and throttle position. The torque converter clutch is engaged by the clutch solenoid on the valve body. The clutch will engage at approximately 56 km/h (35 mph) with light throttle, after the shift to third gear.
