TRANSFER CASE - MP2010

DIAGNOSIS CHART

TORQUE SPECIFICATIONS

Scheme 16

Scheme 17

1. Raise vehicle.
2. Remove drain plug (1) and drain fluid.
3. Reinstall drain plug and tighten to 22-28 N.m (16-21 ft.lbs.). CAUTION: Do not allow propshafts to hang at attached end. Damage to joint can result.
4. Remove the front and rear propeller shafts. Refer to «SHAFT, DRIVE, FRONT , REMOVAL»(ref-465926-S08575329782012042300000) and «SHAFT, DRIVE, REAR , REMOVAL»(ref-465926-S36963294482012042300000) .
5. Support transmission with jack stand.
6. Remove rear crossmember and skid plate, if equipped.
7. Support transfer case with transmission jack and secure with chains.
8. Remove all bolts (2) attaching transfer case to transmission (1).
9. Pull transfer case and jack rearward to disengage transfer case.
10. Remove transfer case from under vehicle.

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Place the transfer case in a shallow pan and remove the fill and drain plugs to drain the remainder of the fluid.
2. Remove all the case bolts (1).
3. Using a prybar at notches (2, 3), carefully separate the case halves.
4. While lifting evenly, remove the chain (1) and sprockets (2, 3) from the input shaft and front output shaft.
5. Remove the snap ring (1) and the thrust washer (2) from the input shaft (3).
6. Remove the input shaft snap ring (1) from the input shaft (2).
7. Properly support the case half with input shaft off the work bench.
8. Using a plastic hammer (1), gently tap the input shaft (2) and remove from case half (3).
9. Remove the snap ring (1).
10. Using seal remover (special tool #7794-A, Remover, Seal) and slide hammer (special tool #C-637, Slide Hammer, Universal), remove input shaft seal (2) and discard.
11. Reinstall the input shaft into bearing and using a plastic hammer (1) gently tap on the input shaft (2) to remove input shaft bearing from the case half (3). NOTE: There is a small snap ring on the shaft that sits in a grove in the bearing. To remove the shaft, it requires the snap ring be squeezed all the way around. A simple way of squeezing the snap ring is to use a small paper clip and work it in between the snap ring and the grove in the bearing all the way around. Once squeezed, lightly tap on the shaft to remove.
12. Remove the front output shaft from the transfer case.
13. Remove the differential (1) and oil slinger (2).
14. Remove the rear output shaft in the same manner as the front output shaft.
15. Using seal remover (special tool #7794-A, Remover, Seal) and slide hammer (special tool #C-637, Slide Hammer, Universal), remove the front and rear output shaft seals and discard. (Rear output seal shown in illustration, front similar.)
16. Using bearing race remover (special tool #9585, Remover, Bearing Race) and slide hammer (special tool #C-637, Slide Hammer, Universal), remove the front and rear output shaft bearings and the support bearing in the rear case half. (Front output support bearing shown in illustration, all others similar.)
