Steering Control Module (Scm) - Electrical Diagnostics: Diagnosis Dodge Durango III

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

DIAGNOSTIC TEST

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press each Remote Radio Switch twice. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Check for a stuck Remote Radio Switch. Repair as necessary. NOTE: Visually and physically inspect the wiring harness between the Remote Radio Switch harness connectors and the Right Steering Wheel Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Control Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Once switch has been replaced, press it twice to initialize it. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press each switch on the Left Steering Wheel Switch assembly twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Check for a stuck Left Steering Wheel Control Switch. NOTE: Visually and physically inspect the wiring harness between the Left Steering Wheel Control Switch harness connector and the Right Steering Wheel Control Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Left Steering Wheel Control Switch in accordance with the Service Information. Refer to «SWITCH, EVIC CONTROL , REMOVAL»(ref-465952-S37749352132012042300000) . Once switch has been replaced, press it twice to initialize it. If problem persists, replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press the Steering Column Tilt Switch twice in all directions. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press the Steering Column Tilt Switch twice in all directions. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

Scheme 10

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press the Front Washer Switch twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press the Rear Washer Switch twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Horn Switch harness connector and the Right Steering Wheel Switch (Speed Control Switch) harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Horn Switch in accordance with the Service Information. Refer to «SWITCH, HORN , REMOVAL»(ref-465969-S26235229682012042300000) . Once the switch has been replaced, press it twice to initialize it. If problem still persists, replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Actuate the Flash To Pass/Optical Horn Switch twice. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC NOTE: If steering system service has been performed and the Steering Angle Sensor (SAS) has been installed incorrectly, this DTC may set. Refer to the Service Information to verify repairs have been performed correctly. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. RELATED DTC(S) PRESENT IN THE PCM Ignition on, engine not running. With the scan tool, select View DTCs in the Powertrain Control Module (PCM). Are there any charging system or related battery voltage DTCs present in the PCM? Yes Perform the appropriate diagnostic procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Go To 2 .
2. CHECK FOR AN ACTIVE DTC Ignition on, engine not running. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. RELATED DTC(S) PRESENT IN PCM Turn the ignition on. With the scan tool, select View DTCs in the Powertrain Control Module (PCM). Are there any charging system or related battery voltage DTCs present in the PCM? Yes Perform the appropriate diagnostic procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) . No Go To 2 .
2. CHECK FOR AN ACTIVE DTC With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go To 3 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
3. (A909) FUSED B(+) CIRCUIT OPEN OR SHORTED TO GROUND Turn the ignition off. Disconnect the Steering Control Module C1 harness connector. Turn the ignition on. Measure the voltage of the (A909) Fused B(+) circuit. Is battery voltage present? Yes Go To 4 . No Repair the (A909) Fused B(+) circuit for an open or short to ground. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
4. (Z912) GROUND CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Measure the resistance between ground and the (Z912) Ground circuit. Is the resistance below 5.0 Ohms? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Repair the (Z912) Ground circuit for an open or high resistance. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. RELATED DTC(S) PRESENT IN THE PCM Ignition on, engine not running. With the scan tool, select View DTCs in the Powertrain Control Module (PCM). Are there any charging system or related battery voltage DTCs present in the PCM? Yes Perform the appropriate diagnostic procedure. Refer to «DIAGNOSTIC CODE INDEX»(ref-466007) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Go To 2 .
2. CHECK FOR AN ACTIVE DTC Ignition on, engine not running. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
2. SPEED CONTROL SWITCH Turn the ignition off. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Turn the ignition on. Move the Speed Control Switch to each position several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the Steering Column Control Module (SCCM) in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test Complete. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, proceed with test. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. ACTIVE DTC Ignition on, engine not running. With the scan tool, select view DTCs. Is the DTC Active at this time? Yes Diagnose the U0002-00-CAN C BUS OFF PERFORMANCE as the U0001-CAN C BUS CIRCUIT test. Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0001-CAN C Bus diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. Using the scan tool, read the active DTCs. Is the DTC active at this time? Yes Perform the U0100-Lost Communication with PCM diagnostic procedure. Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) . . No Perform the Stored Lost Communication DTCs diagnostic procedure. Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) . .

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-465991-S16226542852012042300000) and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-465945-S21111524872012042300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs Does the scan tool display this DTC as active? Yes WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Do not place an intact non-deployed airbag face down on a hard surface, the airbag propels into the air if accidentally deployed. Failure to follow these instructions may result in possible serious or fatal injury. NOTE: Visually and physically inspect the wiring harness between the Right Steering Wheel Switch (Speed Control Switch) harness connector and the SCCM harness connector. Repair any damaged wires, connectors, and open/spread terminals. If harness is OK, view repair. Replace the Right Steering Wheel Switch (Speed Control Switch) in accordance with the Service Information. Refer to «SWITCH, SPEED CONTROL , REMOVAL»(ref-465949-S17175216742012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .

1. CHECK FOR AN ACTIVE DTC NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. NOTE: Diagnose any CAN Bus DTCs that may be set in other modules before proceeding with this diagnostic procedure. Turn the ignition on. With the scan tool, read active DTCs. Dose the scan tool display this DTC as active? Yes If no other CAN Bus DTCs are set in other modules and the SCCM is the only one reporting this DTC, replace the SCCM in accordance with the Service Information. Refer to «MODULE, STEERING COLUMN , REMOVAL»(ref-465939-S27107529732012042300000) . Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-465990-S29694203322012042300000) .
