SPECIFICATIONS
| Component | Mm | In. |
|---|---|---|
| Output Shaft End Play | 0.22-0.55 | 0.009-0.021 |
| Input Shaft End Play | 0.46-0.89 | 0.018-0.035. |
| 2C Clutch Pack Clearance | 0.455-1.335 | 0.018-0.053. |
| 4C Clutch Pack Clearance | 0.770-1.390 | 0.030-0.055 |
| L/R Clutch Pack Clearance | 1.00-1.74 | 0.039-0.069 |
| OD Clutch Pack Clearance | 1.103-1.856 | 0.043-0.073 |
| UD Clutch Pack Clearance | 0.84-1.54 | 0.033-0.061 |
| Reverse Clutch Pack Clearance | 0.81-1.24 | 0.032-0.049 |
| Recommended fluid | Mopar® ATF +4 | |
GENERAL
| Gear | Gear Ratio |
|---|---|
| 1ST | 3.00:1 |
| 2ND | 1.67:1 |
| 2ND PRIME | 1.50:1 |
| 3RD | 1.00:1 |
| 4TH | 0.75:1 |
| 5TH | 0.67:1 |
| REVERSE | 3.00:1 |
GEAR RATIOS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Nut, Output Shaft Flange (2WD Models equipped with flange) | 149 | 110 | |
| Fitting, cooler line at trans | 17.5 | 155 | |
| Bolt, torque converter housing to engine upper four | 41 | 30 | |
| Bolt, torque converter housing to engine lower four | 54 | 40 | |
| Bolts, transmission collar | 68 | 50 | |
| Bolt, torque converter to driveplate | 31 | 23 | 270 |
| For rear mount specifications, refer to SPECIFICATIONS or SPECIFICATIONS . | |||
| Bolt, driveplate to crankshaft | 75 | 55 | |
| Bolt, converter housing | 68 | 50 | |
| Bolt, oil pan | 12 | 105 | |
| Screw, primary fluid filter | 4.5 | 40 | |
| Nuts, transfer case | 35 | 26 | |
| Oil Filter, Cooler Return | 9.5 | 84 | |
| Bolt, oil pump | 28 | 250 | |
| Bolt, oil pump body to cover | 4.5 | 40 | |
| Screw, plate to oil pump body | 4.5 | 40 | |
| Bolt, valve body to case | 12 | 105 | |
| Plug, pressure test port | 5 | 45 | |
| Bolt, reaction shaft support | 12 | 105 | |
| Screw, valve body to transfer plate | 5.5 | 50 | |
| Screw, solenoid module to transfer plate | 6 | 50 | |
| Screw, accumulator cover | 7 | 60 | |
| Screw, detent spring | 4.5 | 40 | |
| Bolt, input speed sensor | 12 | 105 | |
| Bolt, output speed sensor | 12 | 105 | |
| Bolt, line pressure sensor | 12 | 105 | |
| Bolt, extension housing | 54 | 40 | |
| Screw, manual valve cam retaining | 4.5 | 40 | |
| Screw, manual selector shaft retaining | 28 | 250 | |
| Cross-bolt, manual selector shaft | 16 | 140 |
TORQUE SPECIFICATIONS
Scheme 180
Scheme 181
Scheme 182
Scheme 183
Scheme 184
Scheme 185
Scheme 186
Scheme 187
Scheme 188
Scheme 189
Scheme 190
Scheme 191
Scheme 192
Scheme 193
Scheme 194
Scheme 195
Scheme 196
Scheme 197
Scheme 198
Scheme 199
Scheme 200
TORQUE CONVERTER LIMIT VALVE
The torque converter limit valve serves to limit the available line pressure to the torque converter clutch.
Scheme 201
| 1 - PUMP HOUSING | 4 - REACTION SHAFT SUPPORT |
|---|---|
| 2 - OIL FILTER SEAL | 5 - PUMP VALVE BODY |
| 3 - SEAL RING (5) |
Scheme 202
Scheme 203
Scheme 204
- Remove the bolts holding the reaction shaft support (4) to the oil pump. see scheme 171
- Remove the reaction shaft support (4) from the oil pump. see scheme 171
- Remove all bolts holding the oil pump halves together. see scheme 171
- Using suitable prying tools, separate the oil pump sections by inserting the tools in the supplied areas and prying the halves apart. NOTE: The oil pump halves are aligned to each other through the use of two dowels. Be sure to pry upward evenly to prevent damage to the oil pump components. 1 - SEPARATOR PLATE 5 - DOWEL (2) 2 - DRIVEN GEAR (2) 6 - DRIVE GEAR 3 - FLAPPER VALVE 7 - SCREW 4 - PUMP HOUSING
- Remove the screws (7) holding the separator plate (1) onto the oil pump housing (4). see scheme 172
- Remove the separator plate (1) from the oil pump housing (4). see scheme 172
- Mark all gears for location. The gears are select fit and if the oil pump is to be reused, the gears must be returned to their original locations.
- Remove the oil pump flapper valve (3) from its pocket in the pump housing.
- Remove the oil pump gears (2, 6) from the oil pump housing (4). see scheme 172 1 - RETAINER 2 - T/C SWITCH VALVE 3 - OIL PUMP VALVE BODY
- Remove the oil pump valve retainers (1) and associated valve (2) and spring one at a time. see scheme 173 Mark the combination of components as a group and tag them as to the location from which they were removed. 1 - T/C REGULATOR VALVE 2 - T/C LIMIT VALVE 3 - MAIN REGULATOR VALVE 4 - OIL PUMP VALVE BODY
- Remove the T/C regulator valve (1), T/C limit valve (2), and regulator valve (3). see scheme 174
TORQUE CONVERTER CLUTCH (TCC)
In a standard torque converter, the impeller and turbine are rotating at about the same speed and the stator is freewheeling, providing no torque multiplication. By applying the turbine's piston and friction material to the front cover, a total converter engagement can be obtained. The result of this engagement is a direct 1:1 mechanical link between the engine and the transmission.
The clutch can be engaged in second, third, fourth, and fifth gear ranges depending on overdrive control switch position. If the overdrive control switch is in the normal ON position, the clutch will engage after the shift to fourth gear, and above approximately 72 km/h (45 mph). If the control switch is in the OFF position, the clutch will engage after the shift to third gear, at approximately 56 km/h (35 mph) at light throttle.
The TCM controls the torque converter by way of internal logic software. The programming of the software provides the TCM with control over the L/R-CC Solenoid. There are four output logic states that can be applied as follows
- No EMCC
- Partial EMCC
- Full EMCC
- Gradual-to-no EMCC
