TORQUE CHART 5.7L ENGINE

DESCRIPTION	N.m	Ft. Lbs.	In. Lbs.
Block Pipe Plugs
(1/4 NPT)	20		177
(3/8 NPT)	27		240
Camshaft Sprocket-Bolt	122	90
Camshaft Tensioner Plate-Bolts	28		250
Timing Chain Case Cover-Bolts	28		250
Lifting Stud	55	40
Connecting Rod Cap-Bolts	21 plus 90° Turn	15 plus 90° Turn
Main Bearing Cap
Bolts M-12	27 plus 90° Turn
CrossboltsM-8	28
Cylinder Head-Bolts
M-12 Bolts Step 1 Step 2 Step 3	34 54 Turn 90°	25 40 Turn 90°
M-8 Bolts Step 1 Step 2	20 34	15 25
Cylinder Head Cover-Bolts	8		70
Exhaust Manifold to Cylinder Head	25		220
Flexplate to crankshaft-Bolts	95	70
Flywheel to crankshaft-Bolts	75	55
Front Insulator-Through bolt/nut	95	70
Front Insulator to Support Bracket
Stud Nut (4WD)	41	30
Through Bolt/Nut (4WD)	102	75
Front Insulator to Block-Bolts (2WD)	95	70
Generator-Mounting Bolt	55	40
Intake Manifold-Bolts	Refer to Procedure
Lifter Guide Holder	12		106
Oil Pan Bolts	12		105
Oil Dipstick Tube	12		105
Oil Pan-Drain Plug	34	25
Oil Pump-Attaching Bolts	28		250
Oil Pump Pickup Tube - Bolt and Nut	28		250
Rear Seal Retainer Attaching Bolts	15		132

TORQUE SPECIFICATIONS (1 OF 2)

DESCRIPTION	N.m	Ft. Lbs.	In. Lbs.
Rear Insulator to Bracket-Through-Bolt (2WD)	68	50
Rear Insulator to Crossmember Support Bracket-Nut (2WD)	41	30
Rear Insulator to Crossmember-Nuts (4WD)	68	50
Rear Insulator to Transmission-Bolts (4WD)	68	50
Rear Insulator Bracket-Bolts (4WD Automatic)	68	50
Rear Support Bracket to Crossmember Flange-Nuts	41	30
Rear Support Plate to Transfer Case-Bolts	41	30
Rocker Arm-Bolts	22		195
Spark Plugs
Thermostat Housing-Bolts	28		250
Throttle Body-Bolts	12		105
Transfer Case to Insulator Mounting Plate-Nuts	204	105
Transmission Support Bracket-Bolts (2WD)	68	50
Vibration Damper-Bolt	176	129
Water Pump to Timing Chain Case Cover-Bolts	28		250
