1.4L Engine - Service Information: Component Locations Dodge Dart PF

SPECIAL TOOLS

10224 - Adapter, Valve Spring (Originally Shipped In Kit Number(s) 10223.) 10259B - Compressor, MultiAir® Spring 10273 - Installer, Crankshaft Front Oil Seal 10275 - Studs, Valve Spring Compressor 10276 - Tool, Crankshaft Timing Locking 10277 - Tool, Camshaft Timing Locking 10278 - Installer, Camshaft Oil Seal 10280 - Remover/Installer, Spark Plug Tube 10281 - Pins, Connecting Rod Guide 10282 - Adapter, Engine Oil Pressure 10299 - Bracket, Engine Lifting 10306 - Guide, Rear Crankshaft Oil Seal 10307 - Holder, Crankshaft Sprocket 10368 - Set, Universal Protective Cap 6847 - Holder, Camshaft Sprocket (Originally Shipped In Kit Number(s) 6849, 6880, 6882.) 7700-A - Tester, Cooling System 8225 - Alignment Fixture (Originally Shipped In Kit Number(s) 8180, 8180CC, 8263, 8263CC.) C-119 - Cylinder Indicator C-3292A - Gauge, Pressure C-3339A - Set, Dial Indicator (Originally Shipped In Kit Number(s) 9202.) C-3422-D - Compressor, Valve Spring C-3685-A - Bloc-Chek Kit C-385 - Compressor, Piston MD998772A - Compressor, Valve Spring (Originally Shipped In Kit Number(s) 8678, 8853, 8854.)

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

Scheme 232

Scheme 233

1. Disconnect the wastegate solenoid vent hose (6) from the turbocharger inlet duct.
2. Disconnect the EVAP hose quick release fitting (4) from the turbocharger inlet duct. Refer to «FITTING, QUICK CONNECT, STANDARD PROCEDURE»(ref-646230-S25407444222014072800000) .
3. Release the hose clamp (2) at the fresh air make-up hose and remove the hose.
4. Loosen the clamp (3) at the turbocharger inlet duct and remove the duct from the turbocharger.
5. Remove the bolt (5) from the air box and remove the air cleaner housing from the vehicle.
6. If necessary to access the filter element, remove the two screws (1) that hold the upper and lower halves of the housing together.
