B11E7-00-HVAC SWITCH BANK DISCONNECTED
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
WHEN MONITORED
With the ignition on.
SET CONDITION
The Integrated Center Stack (ICS) detects that the 40-Way connector is disconnected for greater than 10 seconds.
POSSIBLE CAUSES
| Possible Causes |
|---|
| BAD CONNECTION AT THE 40-WAY CONNECTOR |
| HVAC/ AUDIO SWITCH BANK |
| INTEGRATED CENTER STACK (ICS) SCREEN MODULE |
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The Integrated Center Stack (ICS) detects a closed switch for 120 seconds on the HVAC / Audio Switch Bank.
| Possible Causes |
|---|
| HVAC/ AUDIO SWITCH BANK |
B156D-00-LOW VOLTAGE DIFFERENTIAL SIGNAL (LVDS) VIDEO CABLE
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The Integrated Center Stack (ICS) detects that the Low Voltage Differential Signal (LVDS) Video Cable is disconnected for greater than 10 seconds.
| Possible Causes |
|---|
| LOW VOLTAGE DIFFERENTIAL SIGNAL (LVDS) VIDEO CABLE DISCONNECTED OR DAMAGED |
| RADIO |
| INTEGRATED CENTER STACK (ICS) SCREEN MODULE |
B156E-4B-INTEGRATED CENTER STACK (ICS) - OVER TEMPERATURE
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The Integrated Center Stack (ICS) Screen Module exceeds its operating temperature limit.
| Possible Causes |
|---|
| INTEGRATED CENTER STACK (ICS) SCREEN MODULE HIGH TEMPERATURE |
B210D-16-BATTERY VOLTAGE LOW - CIRCUIT VOLTAGE BELOW THRESHOLD
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
Scheme 138
With the ignition on.
The ICS monitors the input voltage. This Diagnostic Trouble Code (DTC) is set when the input voltage is below 9.0 volts for greater than three seconds.
| POSSIBLE CAUSES |
|---|
| (A937) FUSED B(+) CIRCUIT OPEN OR EXCESSIVE RESISTANCE |
| (Z911) GROUND CIRCUIT OPEN OR EXCESSIVE RESISTANCE |
| CHARGING SYSTEM CONCERN |
| INTEGRATED CENTER STACK (ICS) SCREEN MODULE |
B210E-17-BATTERY VOLTAGE HIGH - CIRCUIT VOLTAGE ABOVE THRESHOLD
For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
With the ignition on.
The ICS monitors the input voltage. This Diagnostic Trouble Code (DTC) is set when the input voltage is above 17.0 volts for greater than three seconds.
| POSSIBLE CAUSES |
|---|
| CHARGING SYSTEM CONCERN |
| INTEGRATED CENTER STACK (ICS) SCREEN MODULE |
Continuously when the ignition is on.
The battery voltage between 10.0 and 16.0 volts.
Body Control Module (BCM) is configured correctly.
Whenever the CAN B Bus (+) or CAN B Bus (-) circuit is open, shorted to voltage or shorted to ground.
| Possible Causes |
|---|
| CAN B BUS (+) AND (-) CIRCUIT OPEN |
| CAN B BUS (+) CIRCUIT SHORTED TO VOLTAGE |
| CAN B BUS (-) CIRCUIT SHORTED TO VOLTAGE |
| CAN B BUS (+) CIRCUIT SHORTED TO GROUND |
| CAN B BUS (-) CIRCUIT SHORTED TO GROUND |
| CAN B BUS (+) CIRCUIT SHORTED TO CAN B BUS (-) CIRCUIT |
| ANY CAN B BUS MODULE |
Continuously when the ignition is on.
The battery voltage between 10.0 and 16.0 volts.
Body Control Module (BCM) is configured correctly.
Whenever the CAN B Bus (+) or CAN B Bus (-) circuit is open, shorted to voltage or shorted to ground.
| Possible Causes |
|---|
| CAN B BUS (+) AND (-) CIRCUIT OPEN |
| CAN B BUS (+) CIRCUIT SHORTED TO VOLTAGE |
| CAN B BUS (-) CIRCUIT SHORTED TO VOLTAGE |
| CAN B BUS (+) CIRCUIT SHORTED TO GROUND |
| CAN B BUS (-) CIRCUIT SHORTED TO GROUND |
| CAN B BUS (+) CIRCUIT SHORTED TO CAN B BUS (-) CIRCUIT |
| ANY CAN B BUS MODULE |
