TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Camshaft Sprocket Bolt | 122 | 90 | |
| Camshaft Bearing Cap Bolts | 11 | 100 | |
| Timing Chain Cover Bolts | 58 | 43 | |
| Connecting Rod Cap Bolts | 27 + 90° | 20 + 90° | |
| Bed Plate Bolts | Refer to Procedure | ||
| Cylinder Head Bolts | Refer to Procedure | ||
| Crankshaft Damper Bolt | 175 | 130 | |
| Cylinder Head Cover Bolts | 12 | 105 | |
| Exhaust Manifold Bolts | 25 | 18 | |
| Exhaust Manifold Heat Shield Nuts | 8 Then loosen 45° | 72 Then loosen 45° | |
| Flexplate Bolts | 60 | 45 | |
| Engine Mount Bracket to Block Bolts | 61 | 45 | |
| Rear Mount to Transmission Bolts | 46 | 34 | |
| Generator Mounting Bolts | |||
| M10 Bolts | 54 | 40 | |
| M8 Bolts | 28 | 250 | |
| Intake Manifold Bolts | 12 | 105 | |
| Oil Pan Bolts | 15 | 130 | |
| Oil Pan Drain Plug | 34 | 25 | |
| Oil Pump Bolts | 28 | 250 | |
| Oil Pump Cover Bolts | 12 | 105 | |
| Oil Pickup Tube Bolt and Nut | 28 | 250 | |
| Block Bolt | 15 | 130 | |
| Oil Fill Tube Bolts | 12 | 105 | |
| Timing Chain Guide Bolts | 28 | 250 | |
| Timing Chain Tensioner Arm | 28 | 250 | |
| Hydraulic Tensioner Bolts | 28 | 250 | |
| Timing Chain Primary Tensioner Bolts | 28 | 250 | |
| Timing Drive Idler Sprocket Bolt | 34 | 25 | |
| Thermostat Housing Bolts | 13 | 115 | |
| Water Pump Bolts | (1) | ||
| (1) For appropriate bolt tightening specification, refer to FASTENER IDENTIFICATION . | |||
| (1) | For appropriate bolt tightening specification, refer to FASTENER IDENTIFICATION . |
Scheme 176
Scheme 177
Scheme 178
Scheme 179
Scheme 180
Scheme 181
Scheme 182
Scheme 183
Scheme 184
Scheme 185
Scheme 186
Scheme 187
Scheme 188
Scheme 189
Scheme 190
Scheme 191
Scheme 192
Scheme 193
Scheme 194
Scheme 195
Scheme 196
Scheme 197
Scheme 198
Scheme 199
Scheme 200
Scheme 201
Scheme 202
Scheme 203
Scheme 204
Scheme 205
Scheme 206
Scheme 207
| 1 - CLAMP |
|---|
| 2 - AIR DUCT |
| 3 - AIR CLEANER COVER |
| 4 - LOCATING TABS |
| 5 - CLIPS (4) |
- Loosen clamp and disconnect air duct at air cleaner cover.
- Pry over 4 spring clips (5) from housing cover (3) (spring clips retain cover to housing).
- Release housing cover (3) from locating tabs on housing and remove cover shown in illustration above .
- Remove air cleaner element (filter) from housing.
- Clean inside of housing before replacing element.
Scheme 208
| 1 - CLAMP |
|---|
| 2 - AIR DUCT |
| 3 - AIR CLEANER COVER |
| 4 - LOCATING TABS |
| 5 - CLIPS (4) |
- Install filter element into housing.
- Position housing cover into housing locating tabs.
- Pry up 4 spring clips (6) and lock cover to housing.
- Install air duct to air cleaner cover and tighten hose clamp to 3 N.m (30 in. lbs.) torque.
- If any other hose clamps were removed from air intake system, tighten them to 3.4 N.m (30 in. lbs.) torque.
- If any bolts were removed from air resonator housing or air intake tubing, tighten them to 4.5 N.m (40 in. lbs.) torque.
Scheme 209
| 1 - AIR CLEANER HOUSING ASSEMBLY |
|---|
| 2 - LOCATING PINS (4) |
- Loosen clamp and disconnect air duct at air cleaner cover.
- Lift entire housing (1) assembly from 4 locating pins (2) .
Scheme 210
| 1 - AIR CLEANER HOUSING ASSEMBLY |
|---|
| 2 - LOCATING PINS (4) |
- Position housing assembly (1) into 4 locating pins (2).
- Connect air duct at air cleaner cover and tighten clamp.
