TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Camshaft | |||
| Non - Oiled Sprocket Bolt | 122 | 90 | |
| Bearing Cap Bolts | 11 | 100 | |
| Counterbalance Shaft Retaining Bolt | 28 | 250 | |
| Timing Chain Cover Bolts | 58 | 43 | |
| Connecting Rod Cap Bolts | 27 | 20 | |
| PLUS 90° TURN | |||
| Bed Plate Bolts | Refer to Procedure | ||
| Crankshaft Damper Bolt | 175 | 130 | |
| Cylinder Head Bolts | |||
| M11 Bolts | Refer To Procedure | ||
| M8 Bolts | Refer To Procedure | ||
| Cylinder Head Cover Bolts and Studs | 12 | 105 | |
| Exhaust Manifold Bolts | 25 | 18 | |
| Exhaust Manifold Heat Shield Nuts | 8 | 72 | |
| Then loosen 45° | |||
| Flexplate Bolts | 95 | 70 | |
| Engine Mount Bracket to Block Bolts | 61 | 45 | |
| Engine to Transmission Bellhousing Bolts | 41 | 30 | |
| Rear Mount to Transmission Bolts | 46 | 34 | |
| Generator Mounting Bolts | |||
| M10 Bolts | 54 | 40 | |
| M8 Bolts | 28 | 250 | |
| Intake Manifold Bolts | 12 | 105 | |
| Refer to Procedure for Tightening Sequence | |||
| Oil Pan Bolts | 16 | 140 | |
| Oil Pan Drain Plug | 34 | 25 | |
| Oil Pump Bolts | 28 | 250 | |
| Oil Pump Cover Bolts | 12 | 105 | |
| Oil Pickup Tube Bolt and Nut | 28 | 250 | |
| Oil Dipstick Tube to Engine Block Bolt | 15 | 130 | |
| Oil Fill Tube Bolts | 12 | 105 | |
| Timing Chain Guide Bolts | 28 | 250 | |
| Timing Chain Tensioner Arm | 28 | 250 | |
| Hydraulic Tensioner Bolts | 28 | 250 | |
| Timing Chain Primary Tensioner Bolts | 28 | 250 | |
| Timing Drive Idler Sprocket Bolt | 34 | 25 | |
| Thermostat Housing Bolts | 12 | 105 | |
| Water Pump Bolts | 58 | 43 | |
TORQUE
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
Scheme 31
| 1 - CLAMP |
|---|
| 2 - AIR DUCT |
| 3 - AIR CLEANER COVER |
| 4 - LOCATING TABS |
| 5 - CLIPS (4) |
- Loosen clamp and disconnect air duct at air cleaner cover.
- Pry over 4 spring clips (5) from housing cover (3) (spring clips retain cover to housing).
- Release housing cover (3) from locating tabs on housing and remove cover (Scheme 31).
- Remove air cleaner element (filter) from housing.
- Clean inside of housing before replacing element.
Scheme 32
| 1 - CLAMP |
|---|
| 2 - AIR DUCT |
| 3 - AIR CLEANER COVER |
| 4 - LOCATING TABS |
| 5 - CLIPS (4) |
- Install filter element into housing.
- Position housing cover into housing locating tabs.
- Pry up 4 spring clips (6) and lock cover to housing. (Scheme 32)
- Install air duct to air cleaner cover and tighten hose clamp to 3 N.m (30 in. lbs.) torque.
- If any other hose clamps were removed from air intake system, tighten them to 3.4 N.m (30 in. lbs.) torque.
- If any bolts were removed from air resonator housing or air intake tubing, tighten them to 4.5 N.m (40 in. lbs.) torque.
Scheme 33
| 1 - AIR CLEANER HOUSING ASSEMBLY |
|---|
| 2 - LOCATING PINS (4) |
- Loosen clamp and disconnect air duct at air cleaner cover.
- Lift entire housing (1) assembly from 4 locating pins (2) (Scheme 33).
Scheme 34
| 1 - AIR CLEANER HOUSING ASSEMBLY |
|---|
| 2 - LOCATING PINS (4) |
- Position housing assembly (1) into 4 locating pins (2) (Scheme 34)
- Connect air duct at air cleaner cover and tighten clamp.
