SPECIFICATIONS
| DESCRIPTION | SPECIFICATION |
|---|---|
| Axle Ratio | 3.07 |
| Ring Gear Diameter | 175 mm (6.9 in.) |
| Ring Gear Backlash | 0.05-0.11 mm (0.002-0.004 in.) |
| Differential Torque-to-Rotate | 190-260 N.cm (17-23 in. lbs.) |
| Pinion Housing Torque-to-Rotate | 130-260 N.cm (12-23 in. lbs.) |
| Pinion Depth Shim Size | 1.15-2.11mm (0.045-0.083 in.) Available in 0.04 mm (0.0015 in.) increments |
| Pinion Bearing Preload Spacer Size | 9.60-10.59mm (0.378-0.417 in.) Available in 0.03 mm (0.001 in.) increments |
| Differential Bearing Preload Shim Size | 1.31-2.51 mm (0.051-0.099 in.) Available in 0.04 mm (0.0015 in.) increments |
| Differential Backlash Shim Size | 1.34-2.98 mm (0.053-0.117 in.) Available in 0.04 mm (0.0015 in.) increments |
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Bolt, Axle Cover-to-Housing (M10x40) | 65 | 48 | |
| Bolt, Axle Cover-to-Housing (M8x25) | 34 | 25 | |
| Bolt, Axle Housing-to-Engine | 65 | 48 | |
| Bolt, Intermediate Shaft-to-Engine | 25 | 19 | |
| Bolt, Pinion Housing-to-Axle Housing | 34 | 25 | |
| Nut, Pinion Flange | 475 | 350 | |
| Plug, Axle Housing Fill | 30 | 22 | |
| Bolts, Axle Assembly Support Bracket | 28 | 21 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
- Raise and support vehicle. Refer to «HOISTING, STANDARD PROCEDURE»(ref-481392-S03705606742012062200000).
- Remove both front halfshafts. Refer to «REMOVAL»(ref-481402-S26056269572012062200000).
- Remove front intermediate shaft assembly. Refer to «REMOVAL»(ref-481402-S26056269572012062200000).
- Remove front propeller shaft. Refer to «REMOVAL»(ref-481401-S38279247952012062200000).
- Remove RH catalytic converter/exhaust pipe assembly. Refer to «CONVERTER, CATALYTIC, REMOVAL»(ref-481405-S13204078982012062200000).
- Separate power steering return line (3) from cradle by unfastening clips (1). (Scheme 1)
- Remove front axle housing support bracket (1). (Scheme 2)
- Remove seven front axle assembly-to-oil pan bolts. Remove axle assembly (1) from vehicle. (Scheme 3)
