Front Axle: Component Locations Dodge Charger VI

Differentials & Drive Axles 12 illustrations ~511 words

SPECIAL TOOLS

1026 - Puller (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC.) 1130 - Splitter, Bearing/Gear (Originally Shipped In Kit Number(s) 6745, 6947, 6949, 9202, 9202A-CAN, 9202CC, 9299.) 6514 - Remover, Bearing Cup (Originally Shipped In Kit Number(s) 6546.) 6958 - Wrench, Spanner (Originally Shipped In Kit Number(s) 6947, 6949, 6966, 8204, 8204CC, 8667.) 9664 - Remover, Bearing Cup (Originally Shipped In Kit Number(s) 9675, 9685, 9695.) 9665 - Installer, Bearing (Originally Shipped In Kit Number(s) 9675, 9685, 9695.) 9666 - Installer, Bearing (Originally Shipped In Kit Number(s) 9675, 9685, 9695.) 9676 - Adapter Plug (Originally Shipped In Kit Number(s) 9675, 9685, 9695.) 9677 - Installer, Seal (Originally Shipped In Kit Number(s) 9675, 9685, 9695.) 9681-1 - Gauge, Pinion Height (Originally Shipped In Kit Number(s) 9674.) 9681-2 - Plate, Gage (Originally Shipped In Kit Number(s) 9674.) 9681-4 - Disc, Arbor (Originally Shipped In Kit Number(s) 9674.) 9681-5 - Disc, Arbor (Originally Shipped In Kit Number(s) 9674.) 9682 - Backlash Measuring Tool (Originally Shipped In Kit Number(s) 9674.) C-3339A - Set, Dial Indicator (Originally Shipped In Kit Number(s) 9202.) C-4171 - Driver Handle, Universal (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC, 9299, 9299CC, 9299CC, 9300A-CAN.) C-4995A - Tool, Differential Bearing Torque C-637 - Slide Hammer, Universal (Originally Shipped In Kit Number(s) 9202.) D-115-3 - Arbor (Originally Shipped In Kit Number(s) 8667, 9516A-CAN.) D-129 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 6947, 6949, 8667.) D-130 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 9695.) D-145 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 8667, 9695.) L-4507 - Installer, Bearing (Originally Shipped In Kit Number(s) 9685, 9695.)

Scheme 33

Scheme 33: SPECIAL TOOLS

Scheme 34

Scheme 34

Scheme 35

Scheme 35

Scheme 36

Scheme 36

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 39

Scheme 39

Scheme 40

Scheme 40

Scheme 41

Scheme 41: FRONT AXLE DISCONNECT

Scheme 42

Scheme 42

Scheme 43

Scheme 43

Scheme 44

Scheme 44
  1. Raise and support the vehicle. NOTE: The intermediate shaft is serviced only as a complete assembly.
  2. Remove left halfshaft assembly (2). Refer to «REMOVAL»(ref-481402-S26056269572012062200000) .
  3. Disconnect the front axle disconnect solenoid harness connector (1).
  4. Remove the 3 bolts (5), (6), (7) from the front axle disconnect solenoid, and remove the front axle disconnect solenoid (8).
  5. Remove the 3 bolts (1), (2), (3) from the front axle disconnect bracket, and remove the front axle disconnect bracket (4).
  6. Remove four bolts (1) from the front axle disconnect (3) and remove it from the engine
  1. Raise and support the vehicle.
  2. Disconnect the front axle disconnect solenoid harness connector (1).
  3. Remove the 3 bolts (5), (6), and (7) from the front axle disconnect solenoid (8).
  4. Remove the front axle disconnect solenoid (8).
  1. Install the front axle disconnect (3).
  2. Install and torque the four front axle disconnect-to-oil pan bolts (1) to 25 N.m (18 ft. lbs.).
  3. Install the front axle disconnect solenoid (8), and the 3 bolts (5), (6) and (7).
  4. Connect the front axle disconnect solenoid harness connector (1).
  5. Install the front axle disconnect solenoid bracket (4), and the 3 bolts (1), (2), and (3).
  1. Install the front axle disconnect solenoid (8), and the 3 bolts (5), (6), (7).
  2. Connect the front axle disconnect harness connector (1).
