COMPONENT LOCATIONS
Note. For component locations and terminal identification, refer to illustrations. (Scheme 14)- see scheme 10.
| Component | Location |
|---|---|
| Air Bag Control Module (ACM) | On Transmission Tunnel, Below Instrument Panel |
| Central Timer Module (CTM) | To Right Of Steering Column, Under Knee Bolster |
| Compass/Mini-Trip Computer (CMTC) | Front Center Of Headliner |
| Controller Anti-Lock Brake (CAB) | On Hydraulic Control Unit |
| Cylinder Lock Switch | On Appropriate Door Lock |
| Data Link Connector (DLC) | Under Left Side Of Instrument Panel |
| Door Lock Switch | On Inside Door Panel |
| Engine Control Module (ECM) | On Left Side Of Engine |
| Headlight Switch | Left Side Of Instrument Panel |
| Ignition Switch | On Steering Column |
| Junction Block | Behind Left Side Of Instrument Panel |
| Multifunction Switch | On Steering Column |
| Power Distribution Center (PDC) | Left Side Of Engine Compartment |
| Powertrain Control Module (PCM) | On Right Side Of Firewall |
| Wiper/Washer Switch | Part Of Multifunction Switch |
