Powertrain Control Module (PCM) - Electrical Diagnostics - 40TE Automatic Transmission: Other Dodge Avenger II facelift

WHEN MONITORED

Continuously with the ignition on and engine running.

SET CONDITION

This DTC will set if the monitored TPS voltage drops below.078 of a volt for the period of 0.48 of a second.

POSSIBLE CAUSES

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Continuously with the ignition on and engine running.

This DTC will set if the monitored TPS voltage rises above 4.94 volts for the period of 0.48 of a second.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Continuously with the ignition on and engine running.

This DTC will set if the monitored TPS throttle angle is between 6° and 120° and the value changes by more than 5° in a period of 7.0 ms or less.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Whenever the engine is running.

Immediately when an Overheat shift schedule is activated when the Transmission Oil Temperature reaches 115° C (240° F).

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Check for generic software is made at power-up.

If generic software is detected by the controller a MIL will light immediately. This DTC is designed to inform the technician that the controller still has generic software installed.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

One time after each time the ignition is turned to the run position from an off position.

The read value does not match the written value in any memory (RAM) location.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

One time after each time the ignition is turned to the run position from an off position.

If the integrity of the program memory (ROM) checksum does not match a known constant.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

After the ignition is turned to the run position and every 60 seconds thereafter.

Either of the following conditions occur 3 times in less than 590 milliseconds

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Continuously with the ignition on in the run position.

The DTC will set if an invalid PRNDL code exists for more than 100 milliseconds within one second of power-up or if the PRNDL code error does not correct itself when (or before) the shift lever is moved to a different position (P, R, N, or OD), or if the PCM sees the PRNDL code rapidly (within 7 ms) jump across more than three shift lever detent positions.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

TRS SWITCH STATES

Continuously with the ignition on and engine running.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Continuously with the ignition on and engine running.

The DTC will set when the monitored Temperature Sensor voltage drops below 0.078 of a volt for the period of 1.45 seconds. When the fault is set, calculated temperature is substituted for measured temperature, however the fault code is stored only after three consecutive occurrences of the problem identification.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 744

1. DETERMINE IF RELATED DTCS ARE PRESENT With the scan tool, read transmission DTCs. Are there any Speed Sensor DTCs present? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK IF THE DTC IS ACTIVE With the scan tool, view DTCs. Is the status Active or is the Starts Since Set counter 2 or less for this DTC? Yes Go To 3 . No Go To 5 .
3. CHECK THE PCM AND WIRING WITH THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. NOTE: Check connectors - Clean/repair as necessary. Ignition on, engine not running. With the Transmission Simulator, turn the Input/Output switch to OFF. With the scan tool, monitor the TRANS TEMP VOLTS while turning the Thermistor Voltage switch to all three positions on the Transmission Simulator. Compare the scan tool readings with the numbers listed on the Transmission Simulator. Do the readings on the Transmission Simulator match the scan tool readings ± of a 0.2 volt? Yes Replace the Transmission Temperature Sensor (in the TRS Assembly) in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T54) TRANSMISSION TEMPERATURE SIGNAL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Disconnect the PCM C1 harness connector. Disconnect the TRS harness connector. Measure the resistance between ground and the (T54) Transmission Temperature Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T54) Transmission Temperature Signal circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool perform the Quick Learn procedure. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
5. CHECK THE WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Perform any Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Continuously with the ignition on and engine running.

The DTC will set when the monitored Temperature Sensor voltage rises above 4.94 volts for the period of 1.45 seconds. When the fault is set, calculated temperature is substituted for measured temperature, however the fault code is stored only after three consecutive occurrences of the fault.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 745

Scheme 746

Scheme 747

1. CHECK TO SEE IF DTC IS CURRENT With the scan tool, view DTCs. Is the status Active for this DTC or is Starts Since Set counter 2 or less? Yes Go To 2 . No Go To 6 .
2. CHECK THE PCM AND WIRING WITH THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. NOTE: Check connectors - Clean/repair as necessary. Ignition on, engine not running. With the Transmission Simulator, turn the Input/Output switch to OFF. With the scan tool, monitor the TRANS TEMP VOLTS while turning the Thermistor Voltage switch to all three positions on the Transmission Simulator. Compare the scan tool readings with the numbers listed on the Transmission Simulator. Do the readings on the Transmission Simulator match the scan tool readings ± 0.2 of a volt? Yes Replace the Transmission Temperature Sensor (in the TRS Assembly) in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 3 .
3. CHECK THE (T54) TRANSMISSION TEMPERATURE SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Disconnect the PCM C1 harness connector. Disconnect the TRS harness connector NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the (T54) Transmission Temperature Signal circuit between the PCM C1 harness connector and the TRS harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T54) Transmission Temperature Signal circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T13) SENSOR GROUND CIRCUIT FOR AN OPEN Measure the resistance of the (T13) Sensor Ground circuit between the PCM C2 harness connector and the TRS harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T13) Sensor Ground circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 5 .
5. CHECK THE (T54) TRANSMISSION TEMPERATURE SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. With the scan tool under TIPM, actuate the Transmission. Measure the voltage of the (T54) Transmission Temperature Signal circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T54) Transmission Temperature Signal circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
6. CHECK THE WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Check for any Service Information Tune-ups or Service Bulletins for any possible causes that may apply. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Continuously with the ignition on and engine running.

The DTC will set when the monitored Temperature Sensor voltage fluctuates or changes abruptly within a predetermined period of time.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

The transmission gear ratio is monitored continuously while the transmission is in gear.

If there is an excessive change in the Input RPM in any valid gear (R, 1st, 2nd, 3rd, or 4th).

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 748

Scheme 749

Scheme 750

Scheme 751

Scheme 752

1. CHECK TO SEE IF DTC P0715 IS CURRENT Start the engine. Place the shift lever in park. With the scan tool, read the Input Speed Sensor RPM. Is the Input Speed Sensor reading below 400 RPM? Yes Go To 2 . No Go To 8 .
2. CHECK THE PCM AND WIRING WITH THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Ignition on, engine not running. With the Transmission Simulator, set the "Input/Output Speed" switch to "ON" and the rotary switch to the "3000/1250" position. With the scan tool, read the Input and Output RPM. Does the Input speed read 3000 RPM and the Output speed read 1250 RPM ± 50 RPM? Yes Replace the Input Speed Sensor in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 3 .
3. CHECK THE (T52) INPUT SPEED SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Disconnect the PCM C1 harness connector. Disconnect the Input Speed Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the (T52) Input Speed Signal circuit between the PCM C1 harness connector and the Input Speed Sensor harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T52) Input Speed Signal circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T13) SPEED SENSOR GROUND CIRCUIT FOR AN OPEN Measure the resistance of the (T13) Speed Sensor Ground circuit between the PCM C1 harness connector and the Input Speed Sensor harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T13) Speed Sensor Ground circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 5 .
5. CHECK THE (T52) INPUT SPEED SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T52) Input Speed Signal circuit. Is the resistance Below 5.0 Ohms? Yes Repair the (T52) Input Speed Signal circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T52) INPUT SPEED SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the Output Speed Sensor harness connector. Ignition on, engine not running. With the scan tool in the TIPM, actuate the Transmission. Measure the voltage of the (T52) Input Speed Signal circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T52) Input Speed Signal circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 7 .
7. CHECK THE (T13) SPEED SENSOR GROUND CIRCUIT FOR A SHORT TO VOLTAGE NOTE: Actuation of the transmission must still be active. Measure the voltage of the (T13) Speed Sensor Ground circuit. Is the voltage above 0.5 of a volts? Yes Repair the (T13) Speed Sensor Ground circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
8. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wiring and connectors while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

The transmission gear ratio is monitored continuously while the transmission is in gear.

If there is an excessive change in the Output RPM in any gear.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 753

Scheme 754

Scheme 755

Scheme 756

Scheme 757

1. CHECK IF THE DTC IS CURRENT Start the engine in park. Raise the drive wheels off of the ground. WARNING: Properly support the vehicle. Firmly apply the brakes and place the transmission selector in drive. WARNING: Be sure to keep hands and feet clear of rotating wheels. Release the brakes and allow the drive wheels to spin freely. NOTE: The drive wheels must be turning at this point. With the scan tool, read the Output RPM Is the Output RPM below 100? Yes Go To 2 . No Go To 8 .
2. CHECK THE PCM AND WIRING USING THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Ignition on, engine not running. With the Transmission Simulator, set the "Input/Output Speed" switch to "ON" and the rotary switch to the "3000/1250" position. With the scan tool, read the Input and Output RPM. Does the Input RPM read 3000 and the Output RPM read 1250 (± 50 RPM)? Yes Replace the Output Speed Sensor in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 3 .
3. CHECK THE (T14) OUTPUT SPEED SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Disconnect the PCM C1 harness connector. Disconnect the Output Speed Sensor harness connector. NOTE: Check connectors - Clean/repair as necessary. Measure the resistance of the (T14) Output Speed Signal circuit between the PCM C1 harness connector and the Output Speed Sensor harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T14) Output Speed Signal circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T13) SPEED SENSOR GROUND CIRCUIT FOR AN OPEN Measure the resistance of the Speed Sensor Ground circuit between the PCM C1 harness connector and the Output Speed Sensor harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T13) Speed Sensor Ground circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 5 .
5. CHECK THE (T14) OUTPUT SPEED SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T14) Output Speed Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T14) Output Speed Signal circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T14) OUTPUT SPEED SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. With the scan tool under TIPM, actuate the TCM output. Measure the voltage of the (T14) Output Speed Signal circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T14) Output Speed Signal circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 7 .
7. CHECK THE (T13) SPEED SENSOR GROUND CIRCUIT FOR A SHORT TO VOLTAGE NOTE: Actuation of the transmission must still be active. Measure the voltage of the (T13) Speed Sensor Ground circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T13) Speed Sensor Ground circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
8. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wiring and connectors while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Whenever the engine is running.

The Engine RPM is less than 390 or greater than 8000 for more than 2 seconds while the engine is running.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Whenever the engine is running.

The Engine RPM is less than 390 or greater than 8000 for more than 2 seconds while the engine is running.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

The Transmission gear ratio is monitored continuously while the transmission is in gear.

If the ratio of the Input RPM to the Output RPM does not match the current gear ratio when compared to the known gear ratio.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

The Transmission gear ratio is monitored continuously while the transmission is in gear.

If the ratio of the Input RPM to the Output RPM does not match the current gear ratio when compared to the known gear ratio.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

The Transmission gear ratio is monitored continuously while the transmission is in gear.

If the ratio of the Input RPM to the Output RPM does not match the current gear ratio when compared to the known gear ratio.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

The Transmission gear ratio is monitored continuously while the transmission is in gear.

If the ratio of the Input RPM to the Output RPM does not match the current gear ratio when compared to the known gear ratio.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

The Transmission gear ratio is monitored continuously while the transmission is in gear.

If the ratio of the Input RPM to the Output RPM does not match the current gear ratio when compared to the known gear ratio.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

The Torque Converter Clutch (TCC) is in FEMCC or PEMCC, Transmission temperature is hot, Engine temperature is greater than 38° C or 100° F, Transmission Input Speed greater than engine speed, TPS less than 30°, and brake not applied.

The TCC is modulated by controlling the duty cycle of the L/R Solenoid until the difference between the Engine RPM and the Transmission Input Speed RPM or duty cycle is within a desired range. The DTC is set after the period of 10 seconds and three occurrences of either: FEMCC - with slip greater than 100 RPM or PEMCC - duty cycle greater than 85%.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Initially at ignition on, then every 10 seconds thereafter. The solenoids will also be tested immediately after a gear ratio error or pressure switch error is detected.

Three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 758

Scheme 759

Scheme 760

1. CHECK FOR RELATED DTCS With the scan tool, read DTCs. Are there any Transmission Control Relay or TCM Power Input DTCs present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK IF THE DTC IS CURRENT With the scan tool, read DTCs. Is the status Active or is Starts Since Set counter set at 0 for this DTC? Yes Go To 3 . No Go To 7 .
3. CHECK THE PCM AND WIRING USING THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Ignition on, engine not running. With the scan tool, actuate the L/R Solenoid. Monitor the L/R Solenoid LED on the Transmission Simulator. Did the L/R Solenoid LED on the Transmission Simulator blink on and off during actuation? Yes Replace the Transmission Solenoid/Pressure Switch Assembly in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T20) L/R CONTROL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Disconnect the Transmission Solenoid/Pressure Switch Assembly harness connector. Measure the resistance of the (T20) L/R Control circuit between the PCM C1 harness connector and the Solenoid/Pressure Switch Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T20) L/R Control circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 5 .
5. CHECK THE (T20) L/R CONTROL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T20) L/R Control circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T20) L/R Control circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T20) L/R CONTROL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. With the scan tool in the TIPM, actuate the TCM output. Measure the voltage of the (T20) L/R Control circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T20) L/R Control circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
7. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Initially at ignition on, then every 10 seconds thereafter. The solenoids will also be tested immediately after a gear ratio error or pressure switch error is detected.

Three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 761

Scheme 762

Scheme 763

1. CHECK FOR RELATED DTCS With the scan tool, read DTCs. Are there any Transmission Control Relay or TCM Power Input DTCs present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK TO SEE IF THE DTC IS CURRENT With the scan tool, read DTCs. Is the status Active or is the Starts Since Set counter set at 0 for this DTC? Yes Go To 3 . No Go To 7 .
3. CHECK THE PCM AND WIRING USING THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Ignition on, engine not running. With the scan tool, actuate the 2/4 Solenoid. Monitor the 2/4 Solenoid LED on the Transmission Simulator. Did the 2/4 Solenoid LED on the Transmission Simulator blink on and off during actuation? Yes Replace the Transmission Solenoid/Pressure Switch Assembly in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T19) 2/4 CONTROL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Measure the resistance of the (T19) 2/4 Control circuit between the PCM C1 harness connector and the Solenoid/Pressure Switch Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T19) 2/4 Control circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 5 .
5. CHECK THE (T19) 2/4 CONTROL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T19) 2/4 Control circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T19) 2/4 Control circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T19) 2/4 CONTROL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. With the scan tool in the TIPM, actuate the Transmission. Measure the voltage of the (T19) 2/4 Control circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T19) 2/4 Control circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
7. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Initially at ignition on, then every 10 seconds thereafter. The solenoids will also be tested immediately after a gear ratio error or pressure switch error is detected.

Three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 764

Scheme 765

Scheme 766

1. CHECK FOR RELATED DTCS With the scan tool, read DTCs. Are there any Transmission Control Relay or TCM Power Input DTCs present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure(s) . No Go To 2 .
2. CHECK IF THE DTC IS CURRENT With the scan tool, read DTCs. Is the status Active or is the Starts Since Set counter set at 0 for this DTC? Yes Go To 3 . No Go To 7 .
3. CHECK THE PCM AND WIRING USING THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Ignition on, engine not running. With the scan tool, actuate the OD Solenoid. Monitor the OD Solenoid LED on the Transmission Simulator. Did the OD Solenoid LED on the Transmission Simulator blink on and off during actuation? Yes Replace the Transmission Solenoid/Pressure Switch Assembly in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T60) OD CONTROL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Measure the resistance of the (T60) OD Control circuit between the PCM C1 harness connector and the Solenoid/Pressure Switch Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T60) OD Control circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 5 .
5. CHECK THE (T60) OD CONTROL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T60) OD Control circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T60) OD Control circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T60) OD CONTROL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. With the scan tool under TIPM, actuate the Transmission. Measure the voltage of the (T60) OD Control circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T60) OD Control circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
7. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Initially at ignition on, then every 10 seconds thereafter. The solenoids will also be tested immediately after a gear ratio error or pressure switch error is detected.

Three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 767

Scheme 768

Scheme 769

1. CHECK FOR RELATED DTCS With the scan tool, read DTCs Are there any Transmission Control Relay or TCM Power Input DTCs present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK IF THE DTC IS CURRENT With the scan tool, read DTCs. Is the status Active or is the Starts Since Set counter set at 0 for this DTC? Yes Go To 3 . No Go To 7 .
3. CHECK THE PCM AND WIRING USING THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Ignition on, engine not running. With the scan tool, actuate the UD Solenoid. Monitor the UD Solenoid LED on the Transmission Simulator. Did the UD Solenoid LED on the Transmission Simulator blink on and off during actuation? Yes Replace Transmission Solenoid/Pressure Switch Assembly in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T59) UD CONTROL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Measure the resistance of the (T59) UD Control circuit between the PCM C1 harness connector and the Solenoid/Pressure Switch Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T59) UD Control circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 5 .
5. CHECK THE (T59) UD CONTROL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T59) UD Control circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T59) UD Control circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T59) UD CONTROL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. With the scan tool in the TIPM, actuate the TCM output. Measure the voltage of the (T59) UD Control circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T59) UD Control circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
7. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Whenever the engine is running.

The DTC is set if the L/R pressure switch is open or closed at the wrong time in a given gear. If the problem is identified for three successive key starts, the transmission will go into Limp-in mode and the MIL will turn on after 10 seconds of vehicle operation.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

PRESSURE SWITCH STATES

Scheme 770

Scheme 771

Scheme 772

1. CHECK FOR RELATED DTCS With the scan tool, read Transmission DTCs. Are there any Transmission Control Relay or TCM Power Input DTCs present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK FOR A LOSS OF PRIME DTC With the scan tool, read Transmission DTCs. Is the DTC P0944 present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 3 .
3. CHECK IF THE DTC IS CURRENT With the scan tool, read Transmission DTCs. Is the status active for this DTC or is the Starts Since Set counter 2 or less? Yes Go To 4 . No Go To 8 .
4. CHECK THE PCM AND WIRING WITH THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. NOTE: Check connectors - Clean/repair as necessary. Ignition on, engine not running. With the Transmission Simulator, turn the Pressure Switch selector to L/R. With the scan tool, monitor the L/R Pressure Switch state while pressing the Pressure Switch Test button on the Transmission Simulator. Did the L/R Pressure Switch state change? Yes Replace the Transmission Solenoid/Pressure Switch Assembly in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 5 .
5. CHECK THE (T50) L/R PRESSURE SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Measure the resistance of the (T50) L/R Pressure Signal circuit between the PCM C1 harness connector and the Transmission Solenoid/Pressure Switch Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T50) L/R Pressure Signal circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T50) L/R PRESSURE SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T50) L/R Pressure Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T50) L/R Pressure Signal circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 7 .
7. CHECK THE (T50) L/R PRESSURE SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. With the scan tool in the TIPM, actuate the TCM output. Measure the voltage of the (T50) L/R Pressure Signal circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T50) L/R Pressure Signal circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
8. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

In any forward gear with engine speed above 1000 RPM, shortly after a shift and every minute thereafter.

After a shift into a forward gear, with engine speed greater than 1000 RPM, the PCM momentarily turns on element pressure to the clutch circuits that don't have pressure to verify that the correct pressure switch closes. If the pressure switch does not close two times the DTC sets.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 773

Scheme 774

Scheme 775

Scheme 776

1. CHECKING FOR LOSS OF PRIME DTC With the scan tool, check for other Transmission DTCs. Is the DTC P0944 present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK FOR RELATED TRANSMISSION DTCS With the scan tool, read Transmission DTCs. Are any of the DTCs P0732, P0734 and/or P0846 present also? Yes Replace the Transmission Solenoid/Pressure Switch Assembly in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 3 .
3. CHECK FOR CONTAMINATED FLUID Check the transmission fluid for water or other contamination. Is the transmission fluid contaminated? Yes Repair the cause of the transmission fluid contamination in accordance with the Service Information. No Go To 4 .
4. CHECK IF THE DTC P0845 IS CURRENT With the scan tool, view DTCs. Is the status Active or is the Starts Since Set counter 2 or less for this DTC? Yes Go To 5 . No Go To 10 .
5. CHECK THE PCM AND WIRING WITH THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. NOTE: Check connectors - Clean/repair as necessary. Ignition on, engine not running. With the Transmission Simulator, turn the Pressure Switch selector switch to 2/4. With the scan tool, monitor the 2/4 Pressure Switch state while pressing the Pressure Switch Test button on the Transmission Simulator. Wiggle the wires leading to the PCM while pressing and holding the Pressure Switch Test button. Did the 2/4 Pressure Switch state change from open to closed when the test button was pressed, and remain closed while wiggling the wires? Yes Disassemble and inspect the Valve Body in accordance with the Service Information. If no problems are found in the Valve Body, replace the Transmission Solenoid/Pressure Switch Assembly. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T47) 2/4 PRESSURE SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Disconnect the PCM C1 harness connector. Measure the resistance of the (T47) 2/4 Pressure Signal circuit between the PCM C1 harness connector and the Transmission Solenoid/Pressure Switch Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T47) 2/4 Pressure Signal circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 7 .
7. CHECK THE (T47) 2/4 PRESSURE SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T47) 2/4 Pressure Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T47) 2/4 Pressure Signal circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 8 .
8. CHECK THE (T47) 2/4 PRESSURE SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. With the scan tool under TIPM, actuate the Transmission. Measure the voltage of the (T47) 2/4 Pressure Signal circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T47) 2/4 Pressure Signal circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 9 .
9. CHECK THE (T16) TRANSMISSION CONTROL OUTPUT CIRCUIT FOR AN OPEN NOTE: Continue actuation of the Transmission under TIPM. Using a 12-volt test light connected to ground, check (T16) Transmission Control Output circuit in the Transmission Solenoid/Pressure Switch Assembly harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Repair the Transmission Control Output circuit for an open or high resistance. If the fuse is open make sure to check for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
10. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Whenever the engine is running.

The DTC is set if the 2/4 pressure switch is open or closed at the wrong time in a given gear. If the problem is identified for three successive ignition starts, the transmission will go into Limp-in mode and the MIL will turn on after 10 seconds of vehicle operation.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

PRESSURE SWITCH STATES

Continuously while driving in a forward gear.

The Powertrain Control Module (PCM) continuously monitors Actual Line Pressure and compares it to Desired Line Pressure. If the Actual Line Pressure is more than 69 kPa (5 psi) below Desired Line Pressure while the PCS duty cycle is at or near its minimum value, this DTC will set.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 777

Scheme 778

Scheme 779

Scheme 780

1. CHECK FOR RELATED DTCS With the scan tool, check for other transmission DTCs. Is the DTC P0932 present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK IF THE DTC IS CURRENT With the scan tool, check the Starts Since Set counter for P0868. NOTE: This counter only applies to the last DTC set. Is the Starts Since Set COUNTER 2 or less? Yes Go To 3 . No Go To 10 .
3. CHECK THE PCM AND WIRING Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. On the Transmission Simulator select the "OFF" position of the "Input/Output Speed" switch. Ignition on, engine not running. With the scan tool, monitor the Line Pressure during the following steps. Using the Transmission Simulator, set the rotary knob to each of the three line pressure positions. NOTE: All three scan tool Line Pressure readings should be steady and ± 14 kPa or 2.0 psi (0.2 of a volt) of the reading specified on the Transmission Simulator. Did the Line Pressure read within ± 14 kPa or 2.0 psi (0.2 of a volt) in all three positions? Yes Go To 4 . No Go To 6 .
4. CHECK THE LINE PRESSURE SENSOR Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and reconnect all previously disconnected connectors. Install a Pressure Gauge, 0 to 2000 kPa or 0 to 300 psi to the L/R test port. Start the engine in park. Monitor the line pressure readings of both the scan tool and the pressure gauge and compare the two readings. Is the line pressure gauge reading within 34 kPa or 5 psi of the scan tool reading? Yes Go To 5 . No Replace the Line Pressure Sensor in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
5. CHECK FOR A PLUGGED TRANSMISSION OIL FILTER Turn the ignition off to the lock position. Remove and inspect the Transmission Oil Pan for excessive debris in accordance with the Service Information. Remove and inspect the Transmission Oil Filter in accordance with the Service Information. Does the Oil Pan contain excessive debris and/or is the Transmission Oil Filter plugged? Yes Repair as necessary. If the Transmission Oil Filter is plugged or there is excessive debris, refer to the Service Information for the proper Hydraulic repair procedure. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Repair internal transmission and inspect the Transmission Oil Pump in accordance with the Service Information and replace if necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
6. CHECK THE (F856) 5-VOLT SUPPLY CIRCUIT FOR A SHORT TO VOLTAGE Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Reconnect all previously disconnected connectors except the Line Pressure Sensor/Variable Force Solenoid Assembly harness connector. Ignition on, engine not running. Measure the voltage of the (F856) 5-volt Supply circuit. Is the voltage above 5.5 volts? Yes Repair the (F856) 5-volt Supply circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 7 .
7. CHECK THE (F856) 5-VOLT SUPPLY CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C2 harness connector. Disconnect the Line Pressure/Variable Force Solenoid harness connector. Measure the resistance of the (F856) 5-volt Supply circuit between the PCM C2 harness connector and the Line Pressure Sensor/Variable Force Solenoid Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (F856) 5-volt Supply circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 8 .
8. CHECK THE (F856) 5-VOLT SUPPLY CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (F856) 5-volt Supply circuit. Is the resistance below 5.0 Ohms? Yes Repair the (F856) 5-volt Supply circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 9 .
9. CHECK THE (T118) LP VFS CONTROL CIRCUIT FOR A SHORT TO ANOTHER CIRCUIT Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Ignition on, engine not running. Measure the resistance between the (T118) LP VFS Control circuit and all other circuits in the Line Pressure Sensor/Variable Force Solenoid Assembly harness connector. Is the resistance below 5.0 Ohms between the (T118) LP VFS Control circuit and any other circuit(s) in the Line Pressure Sensor/Variable Force Solenoid Assembly harness connector? Yes Repair the (T118) LP VFS Control circuit for a short to another circuit(s). Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool perform the Quick Learn procedure. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
10. CHECK THE WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Perform for any Service Bulletins that may apply. Where there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Continuously while driving in a forward gear.

The Powertrain Control Module (PCM) continuously monitors Actual Line Pressure. If the Actual Line Pressure reading is greater than the highest Desired Line Pressure ever used in the current gear, while the Line Pressure Solenoid duty cycle is at or near its maximum value (which should result in minimum line pressure), the DTC will set.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 781

Scheme 782

1. CHECK FOR RELATED DTCs With the scan tool, read Transmission DTCs. Are there any Line Pressure Sensor, TCM Power Input or Transmission Control Relay DTCs present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK IF THE DTC IS CURRENT With the scan tool, check the Starts Since Set counter for P0869. Is the Starts Since Set COUNTER 2 or less? Yes Go To 3 . No Go To 9 .
3. CHECK THE PCM AND WIRING Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. With the Transmission Simulator select the "OFF" position on the "Input/Output Speed" switch. Ignition on, engine not running. With the scan tool, monitor the Line Pressure during the following step. Using the Transmission Simulator, set the rotary switch to each of the three line pressure positions. NOTE: All three scan tool Line Pressure readings should be steady and ± 14 kPa or 2.0 psi (0.2 of a volt) of the reading specified on the Transmission Simulator. Did the Line Pressure read within ± 14 kPa or 2.0 psi (0.2 of a volt) in all three positions? Yes Go To 4 . No Go To 5 .
4. CHECK THE LINE PRESSURE SENSOR CALIBRATION Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit and reconnect all previously disconnected connectors. Install the Line Pressure Gauge (special tool #C-3293-SP, Gauge, Pressure 0-300 P.S.I.), 0 to 2000 kPa or 0 to 300 psi in the L/R pressure port. Start the engine in park. Monitor the Line Pressure readings on the scan tool and the pressure gauge. Compare the Line Pressure readings between the scan tool and the pressure gauge. Is the pressure gauge reading within 34 kPa (5 psi) of the scan tool reading? Yes Repair the internal transmission and inspect the Transmission Oil Pump in accordance with the Service Information and replace if necessary. If no problem is found, replace the Line Pressure Variable Force Solenoid in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Replace the Line Pressure Sensor per the Service information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
5. CHECK THE (T118) LP VFS CONTROL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Disconnect the PCM C1 harness connector. Measure the resistance of the (T118) LP VFS Control circuit between the PCM C1 harness connector and the Line Pressure Sensor/Variable Force Solenoid Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T118) LP VFS Control circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T118) LP VFS CONTROL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T118) LP VFS Control circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T118) LP VFS Control circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 7 .
7. CHECK THE (F856) 5-VOLT SUPPLY CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C2 harness connector. Measure the resistance of the (F856) 5-volt Supply circuit between the PCM C2 harness connector and the Line Pressure Sensor/Variable Force Solenoid Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (F856) 5-volt Supply circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 8 .
8. CHECK THE (F856) 5-VOLT SUPPLY CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (F856) 5-volt Supply circuit. Is the resistance below 5.0 Ohms? Yes Repair the (F856) 5-volt Supply circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool perform the Quick Learn procedure. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
9. CHECK THE WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Perform any technical service bulletins that may apply. Where there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

In any forward gear with engine speed above 1000 RPM, shortly after a shift and every minute thereafter.

After a shift into a forward gear, with engine speed greater than 1000 RPM, the Powertrain Control Module (PCM) momentarily turns on element pressure to the clutch circuits that don't have pressure to identify the correct pressure switch closes. If the pressure switch does not close two times the DTC sets.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 783

Scheme 784

Scheme 785

1. CHECKING FOR LOSS OF PRIME DTC With the scan tool, check Transmission DTCs. Is the DTC P0944 present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK FOR RELATED TRANSMISSION DTCS With the scan tool, read Transmission DTCs. Are any of the DTCs P0732, P0734 and/or P0846 present also? Yes Replace the Transmission Solenoid/Pressure Switch Assembly in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 3 .
3. CHECK FOR CONTAMINATED FLUID Check the transmission fluid for water or other contamination. Is the transmission fluid contaminated? Yes Repair the cause of the transmission fluid contamination in accordance with the Service Information. No Go To 4 .
4. CHECK IF THE DTC IS CURRENT With the scan tool, check Transmission DTCs. Is the status Active or is the Starts Since Set counter 2 or less for this DTC? Yes Go To 5 . No Go To 10 .
5. CHECK THE PCM AND WIRING WITH THE TRANSMISSION SIMULATOR Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. NOTE: Check connectors - Clean/repair as necessary. Ignition on, engine not running. With the Transmission Simulator, turn the Pressure Switch selector switch to OD. With the scan tool, monitor the OD Pressure Switch state while pressing the Pressure Switch Test button on the Transmission Simulator. Wiggle the wires leading to the PCM while pressing and holding the Pressure Switch Test button. Did the OD Pressure Switch state change from open to closed when the button was pressed, and remain closed while wiggling the wires? Yes Disassemble and inspect the Valve Body in accordance with the Service Information and repair or replace as necessary. If no problems are found in the Valve Body, replace the Transmission Solenoid/Pressure Switch Assembly. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T9) OD PRESSURE SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Measure the resistance of the (T9) OD Pressure Signal circuit between the PCM C1 harness connector and the Transmission Solenoid/Pressure Switch Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T9) OD Pressure Signal circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 7 .
7. CHECK THE (T9) OD PRESSURE SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T9) OD Pressure Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T9) OD Pressure Signal circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 8 .
8. CHECK THE (T9) OD PRESSURE SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. With the scan tool under TIPM, actuate the Transmission. Measure the voltage of the (T9) OD Pressure Signal circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T9) OD Pressure Signal circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 9 .
9. CHECK THE (T16) TRANSMISSION CONTROL OUTPUT CIRCUIT FOR AN OPEN NOTE: Continue actuation of the Transmission under TIPM. Using a 12-volt test light connected to ground, check (T16) Transmission Control Output circuit in the Transmission Solenoid/Pressure Switch Assembly harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Repair the (T16) Transmission Control Output circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
10. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Whenever the engine is running.

The DTC is set if the OD pressure switch is open or closed at the wrong time in a given gear. If the P0706 fault condition is also present, the transmission will go into Limp-in mode and the MIL will turn on.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

PRESSURE SWITCH STATES

When the ignition is turned from "OFF" position to "RUN" position and/or the ignition is turned from "START" position to "RUN" position.

This DTC is set when there is less than 3.0 volts present at the transmission control output circuits located in the Powertrain Control Module (PCM) when the Transmission Control System requests the power up of those circuits.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 786

Scheme 787

1. CHECK IF THE DTC P0882 IS CURRENT With the scan tool, Check the Starts Since Set counter for P0882. NOTE: This counter only applies to the last DTC set. Is the Starts Since Set counter equal to 0? Yes Go To 2 . No Go To 5 .
2. CHECK FOR TIPM RELATED DTCS With the scan tool, check TIPM DTCs. Are there any TCM Power Control Circuit DTCS present under TIPM? Yes Refer to «TIPM - DIAGNOSIS AND TESTING»(ref-485529-S21413626642012071300000) and perform the appropriate diagnostic procedure(s). No Go To 3 .
3. CHECK THE (T15) TRANSMISSION CONTROL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Disconnect the TIPM C2 harness connector. Measure the resistance between ground and the (T15) Transmission Control circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T15) Transmission Control circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T15) TRANSMISSION CONTROL CIRCUIT FOR AN OPEN Measure the resistance of the (T15) Transmission Control circuit between the PCM C1 harness connector and the TIPM C2 harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T15) Transmission Control circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
5. CHECK THE WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Where there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

When the ignition is turned from "OFF" position to "RUN" position and/or the ignition is turned from "START" position to "RUN" position.

This DTC is set if the Powertrain Control Module senses greater than 3.0 volts on the Transmission Control Relay Output circuits prior to a request from the PCM to TIPM to energize the Transmission Output circuits.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 788

Scheme 789

1. CHECK FOR TCM TIPM DTCS With the scan tool check for TIPM DTCs. Are there any TCM Power Control Circuit DTCS present under TIPM? Yes Refer to «TIPM - DIAGNOSIS AND TESTING»(ref-485529-S21413626642012071300000) and perform the appropriate diagnostic procedure(s). No Go To 2 .
2. CHECK TO SEE IF DTC P0883 IS CURRENT With the scan tool, check the Starts Since Set counter. NOTE: This counter only applies to the last DTC set. Is the Starts Since Set counter set to 0? Yes Go To 3 . No Go To 8 .
3. (T16) TRANSMISSION OUTPUT CIRCUIT SHORT TO VOLTAGE Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Disconnect the TIPM C2 harness connector. Disconnect the TIPM C10 harness connector. Ignition on, engine not running. Measure the voltage of the (T16) Transmission Control Output circuit(s). Is the voltage above 0.5 of a volt? Yes Go To 4 . No Go To 7 .
4. CHECK THE TRANSMISSION SOLENOID/PRESSURE SWITCH ASSEMBLY Turn the ignition off to the lock position. Disconnect the Transmission Solenoid/Pressure Switch Assembly harness connector. Ignition on, engine not running. Measure the voltage of the (T16) Transmission Control Output circuit(s). Is the voltage above 0.5 of a volt? Yes Go To 5 . No Replace the Transmission Solenoid/Pressure Switch Assembly in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
5. CHECK THE TRANSMISSION RANGE SENSOR Turn the ignition off to the lock position. Disconnect the Transmission Range Sensor (TRS) harness connector. Ignition on, engine not running. Measure the voltage of the (T16) Transmission Control Output circuit(s). Is the voltage above 0.5 of a volt? Yes Go To 6 . No Replace the TRS in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
6. CHECK THE LINE PRESSURE SENSOR/VARIABLE FORCE SOLENOID ASSEMBLY Turn the ignition off to the lock position. Disconnect the Line Pressure/Variable Force Solenoid Assembly harness connector. Ignition on, engine not running. Measure the voltage of the (T16) Transmission Control Output circuit(s). Is the voltage above 0.5 of a volt? Yes Repair the (T16) Transmission Control Output circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Replace the Line Pressure/Variable Force Solenoid Assembly in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
7. CHECK THE (T15) TRANSMISSION CONTROL CIRCUIT FOR A SHORT TO VOLTAGE Measure the voltage of the (T15) Transmission Control circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T15) Transmission Control circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
8. CHECK WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Where there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

One time after each controller reset.

This DTC will set if the PCM powers up and senses the vehicle in a valid forward gear (no PRNDL DTCs) with an output speed above 800 RPM, approximately 32Km/h (20mph).

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

When the ignition is turned from "OFF" position to "RUN" position and/or the ignition is turned from "START" position to "RUN" position.

This DTC is set when there is less than 3.0 volts present at the transmission control output circuits located in the Powertrain Control Module (PCM) when the Transmission Control System requests the power up of those circuits.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

One time after a reset (ignition turned to the RUN position or after cranking engine).

A fault is set if the sensed voltage on any of the pressure switch circuits is greater than 4.5 volts for the period of 7 msec before a request by the Transmission Control System requests the Transmission Control Output circuit to be energized. The transmission is placed in Limp-In and the MIL is illuminated after 10 seconds of vehicle operation.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

When the ignition is turned from "OFF" position to "RUN" position and/or the ignition is turned from "START" position to "RUN" position.

This DTC is set if the Powertrain Control Module senses greater than 3.0 volts on the Transmission Control Relay Output circuits prior to a request from the PCM to TIPM to energize the Transmission Output circuits.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Each transition from full EMCC to partial EMCC for A/C bump prevention.

DTC set if 20 occurrences of a turbine acceleration sum. Fault Set Time: 20 transitions from full EMCC to partial EMCC. Transmission will not use partial EMCC. Established for A/C bump prevention.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Continuously with the ignition on, engine running, with the transmission in gear.

The Powertrain Control Module (PCM) continuously monitors Actual Line Pressure and compares it to Desired Line Pressure. If the Actual Line Pressure reading is more than 172.4 kPa (25 psi) higher than the Desired Line Pressure, but is less than the highest Line Pressure ever used in the current gear, the DTC sets.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Continuously with the ignition on and engine running.

This DTC will set when the monitored Line Pressure Sensor voltage is less than or equal to 0.35 of a volt for 0.18 of a second.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 790

1. CHECK IF DTC IS CURRENT With the scan tool, check the Starts Since Set counter for P0934. NOTE: This counter only applies to the last DTC set. Is the Starts Since Set counter 2 or less? Yes Go To 2 . No Go To 6 .
2. CHECK THE PCM AND WIRING Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Ignition on, engine not running. With the scan tool, under Transmission Sensors, monitor the Line Pressure. Using the Transmission Simulator, set the rotary switch to each of the three line pressure positions. NOTE: All three scan tool Line Pressure readings should be steady and ± 14 kPa or 2.0 psi (0.2 of a volt) of the reading specified on the Transmission Simulator. Did the Line Pressure read within ± 14 kPa or 2.0 psi (0.2 of a volt) in all three positions? Yes Replace the Line Pressure Sensor in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 3 .
3. CHECK THE (T38) LP VFS SIGNAL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Disconnect the PCM C1 harness connector. Measure the resistance between ground and the (T38) LP VFS Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T38) LP VFS Signal circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (F856) 5-VOLT SUPPLY CIRCUIT FOR AN OPEN Measure the resistance of the (F856) 5-volt Supply circuit between the PCM C2 harness connector and the Line Pressure Sensor/Variable Force Solenoid Assembly harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 . No Repair the (F856) 5-volt Supply circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
5. CHECK THE (F856) 5-VOLT SUPPLY CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (F856) 5-volt Supply circuit. Is the resistance below 5.0 Ohms? Yes Repair the (F856) 5-volt Supply circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool perform the Quick Learn procedure. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
6. CHECK THE WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Check for any Service Bulletins that may apply. Where there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Continuously with ignition on and engine running.

This DTC will set if the monitored Line Pressure Sensor voltage is greater than or equal to 4.75 Volts for the period of 0.18 of a second.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 791

Scheme 792

Scheme 793

1. CHECK TO SEE IF DTC IS CURRENT Using the scan tool, Check the Starts Since Set counter for P0935. NOTE: This counter only applies to the last DTC set. Is the Starts Since Set counter 2 or less? Yes Go To 2 . No Go To 6 .
2. CHECK THE PCM AND WIRING Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator, (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Ignition on, engine not running. Using the scan tool, monitor the Line Pressure. Using the Transmission Simulator, set the rotary switch to each of the three line pressure positions. NOTE: All three scan tool Line Pressure readings should be steady and ± 14 kPa or 2.0 psi (0.2 of a Volt) of the reading specified on the Transmission Simulator. Did the Line Pressure read within ± 14 kPa or 2.0 psi (0.2 of a Volt) in all three positions? Yes Replace the Line Pressure Sensor in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 3 .
3. CHECK THE (T853) SENSOR GROUND CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Disconnect the PCM C1 harness connector. Measure the resistance of the (T853) Sensor Ground circuit between the PCM C1 harness connector and the Line Pressure Sensor/Variable Force Solenoid Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T853) Sensor Ground circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T38) LP VFS SIGNAL CIRCUIT FOR AN OPEN Measure the resistance of the (T38) LP VFS Signal circuit from the Line Pressure Sensor/Variable Force Solenoid Assembly harness connector to the appropriate terminal the PCM Pinout Box (special tool #8815A, Kit, NGC, 38 Position). Is the resistance above 5.0 Ohms? Yes Repair the (T38) LP VFS Signal circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 5 .
5. CHECK THE (T38) LP VFS SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. With the scan tool under TIPM, actuate the transmission Measure the voltage of the (T38) LP VFS Signal circuit. Is the voltage above 5.5 volts? Yes Repair the (T38) LP VFS Signal circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool perform the Quick Learn procedure. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
6. CHECK WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Using the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Perform any service bulletins that may apply. Where there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Every 350 msec

If the transmission begins to slip in any forward gear, and the pressure switch or switches that should be closed for a given gear are open, a loss of prime test begins. All available elements (in 1st gear LR, 2/4 and OD, in 2nd, 3rd, and 4th gear 2/4 and OD) are turned on by the Powertrain Control Module (PCM) to see if pump prime exists. The code is set if none of the pressure switches respond. The PCM will continue to run the loss of prime test until pump pressure returns. The vehicle will not move or the transmission will slip. Normal operation will continue if pump prime returns.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Whenever the engine is running.

The transmission is not in the AutoStick® position and the upshift or downshift is reporting closed - below 0.3 of a volt or if both switches are reported closed at the same time.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 794

Scheme 795

1. CHECK IF THE DTC IS CURRENT With the scan tool, check the Starts Since Set counter for P0952. NOTE: This counter only applies to the last DTC set. Is the Starts Since Set counter set at 0? Yes Go To 2 . No Go To 5 .
2. CHECKING THE AUTOSTICK® SWITCH Turn the ignition off to the lock position. Disconnect the AutoStick® Switch harness connector. Ignition on, engine not running. Measure the voltage of both the AutoStick® Upshift and Downshift Switch Signal circuits. Is the voltage above 5.0 volts on both circuits? Yes Replace the AutoStick® Switch in accordance with the Service Information. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 3 .
3. CHECK THE (T44) AUTOSTICK® DOWNSHIFT SWITCH SIGNAL CIRCUIT FOR A SHORT TO GROUND Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Measure the resistance between ground and the (T44) AutoStick® Downshift Switch Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T44) AutoStick® Downshift Switch Signal circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T5) AUTOSTICK® UPSHIFT SWITCH SIGNAL CIRCUIT FOR A SHORT GROUND Measure the resistance between ground and the (T5) AutoStick® Upshift Switch Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T5) AutoStick® Upshift Switch Signal circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
5. CHECK THE WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorts and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Whenever the engine is running.

The transmission is not in the AutoStick® position and the upshift or downshift is reporting closed - below 0.71 of a volt or if both switches are reported closed at the same time.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

In any forward gear with engine speed above 1000 RPM, shortly after a shift and every minute thereafter.

After a shift into a forward gear, with engine speed greater than 1000 RPM, the Powertrain Control Module (PCM) momentarily turns on element pressure to the clutch circuits that do not have pressure to identify that the correct pressure switch closes. If the pressure switch does not close two times the DTC sets.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

After a reset (ignition turned to the RUN position).

The checksum of the battery backed RAM does not match the stored checksum. Set Time: Less than 7 msec.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 796

Scheme 797

1. BATTERY WAS DISCONNECTED Has the battery been disconnected, lost it's charge, or been replaced recently? Yes Disconnecting or replacing the battery will set this DTC. Erase the DTC. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 2 .
2. WAS A QUICK LEARN PERFORMED Has a Quick Learn procedure been performed? Yes Performing a Quick Learn procedure will set this DTC. Erase the DTC. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 3 .
3. PCM REPLACED OR DISCONNECTED Has the PCM been replaced or disconnected? Yes Replacing or disconnecting the PCM will set this DTC. Erase the DTC. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (A209) FUSED B(+) CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. NOTE: Check connectors - Clean/repair as necessary. Using a 12-volt test light connected to ground, check the (A209) Fused B(+) circuit in the PCM C1 harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 5 . No Repair the (A209) Fused B(+) circuit for an open. If the fuse is open make sure to check for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
5. CHECK THE (Z902) GROUND CIRCUITS FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Using a 12-volt test light connected to 12-volts, check both all of the (Z902) Ground circuits in PCM C1 harness connector NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly for both ground circuits? Yes Go To 6 . No Repair the (Z902) Ground circuit(s) for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
6. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Ignition on, engine running with the gear shift selector in a valid forward gear.

This DTC sets whenever Transmission control system detects the manual valve is in the T2 range when it should be in OD. This is mainly an informational DTC.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Prior to a shift into 1st gear.

Transmission temperature must be hot. DTC is set after six unsuccessful attempts to shift into 1st gear.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 798

1. DETERMINING IF RELATED DTCS ARE PRESENT With the scan tool, read transmission DTCs. Is the DTC P0841 present also? Yes Refer to «2.4L - DIAGNOSTIC CODE INDEX»(ref-485540) or «3.6L - DIAGNOSTIC CODE INDEX»(ref-485548) and perform the appropriate diagnostic procedure . No Go To 2 .
2. CHECK TO SEE IF DTC P1775 IS CURRENT With the scan tool, read transmission DTCs. Is the status Active or is the Starts Since Set counter 2 or less for this DTC? Yes Go To 3 . No Go To 8 .
3. PCM AND WIRING Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Ignition on, engine not running. With the Transmission Simulator, turn the Pressure Switch selector switch to L/R. With the scan tool, monitor the L/R Pressure Switch State while pressing the Pressure Switch Test button. Did the Pressure Switch state change from open to closed when the test button was pressed? Yes Remove the valve body accordance with the Service Information. Inspect the Solenoid Switch Valve in accordance with the Service Information and repair or replace as necessary. If no problems are found, replace the Transmission Solenoid/Pressure Switch Assembly. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 4 .
4. CHECK THE (T16) TRANSMISSION CONTROL OUTPUT CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Disconnect the PCM C1 harness connector. Ignition on, engine not running. With the scan tool under TIPM, actuate the Transmission. Using a 12-volt test light connected to ground, check all (T16) Transmission Control Output circuits in the PCM C1 harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly on all Transmission Control Relay Output circuits? Yes Repair the (T16) Transmission Control Output circuit(s) for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 5 .
5. CHECK THE (T50) L/R PRESSURE SIGNAL CIRCUIT FOR A SHORT TO VOLTAGE Ignition on, engine not running. While still actuating the TCM output in the TIPM with the scan tool, measure the voltage of the (T50) L/R Pressure Signal circuit. Is the voltage above 0.5 of a volt? Yes Repair the (T50) L/R Pressure Signal circuit for a short to voltage. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 6 .
6. CHECK THE (T50) L/R PRESSURE SIGNAL CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the PCM C1 harness connector. Measure the resistance of the (T50) L/R Pressure Signal circuit between the PCM C1 harness connector and the Transmission Solenoid/Pressure Switch Assembly harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (T50) L/R Pressure Signal circuit for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Go To 7 .
7. CHECK THE (T50) L/R PRESSURE SIGNAL CIRCUIT FOR A SHORT TO GROUND Measure the resistance between ground and the (T50) L/R Pressure Signal circuit. Is the resistance below 5.0 Ohms? Yes Repair the (T50) L/R Pressure Signal circuit for a short to ground. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
8. CHECK WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Test drive and verify if the transmission is launching in 2nd gear and/or no TCC engagement. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Are there 2nd gear launches and/or no TCC engagement? Yes Disassemble and inspect the Valve Body in accordance with the Service Information and repair or replace as necessary. If no problems are found in the Valve Body, replace the Transmission Solenoid Pressure Switch Assembly. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Every 7 msec when operating in PEMCC or FEMCC.

Must be in partial or full EMCC. The DTC is set if L/R pressure is detected high for the fourth time.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

After a Gear Ratio Error code is stored.

After a Gear Ratio Error DTC has already been set. The DTC is set if the fault happened within 1.3 seconds of a shift. The DTC set time will vary from 1.214 seconds to 15 seconds.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Every 7 msec after a controller reset with transmission in neutral.

After a Powertrain Control Module (PCM) reset in neutral and Input and Output sensor ratio equals 2.50 to 1.0 (± 50.0 RPM).

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Scheme 799

1. PCM AND WIRING Turn the ignition off to the lock position. Remove the Ignition Switch Feed fuse from the TIPM. CAUTION: Removal of the Ignition Switch Feed fuse from the TIPM will prevent the vehicle from being started in gear. WARNING: The Ignition Switch Feed fuse must be removed from the TIPM. Failure to do so can result in possible serious or fatal injury. Install the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. NOTE: Check connectors - Clean/repair as necessary. Ignition on, engine not running. With the Transmission Simulator, set the "Input/Output Speed" switch to "ON" and the rotary switch to the "3000/1250" position. With the scan tool, monitor the Input and Output Speed Sensor readings. Does the Input Speed read 3000 RPM and the Output Speed read 1250 RPM (± 50 RPM)? Yes Go To 2 . No Go To 3 .
2. (T13) SPEED SENSOR GROUND CIRCUIT OPEN Turn the ignition off to the lock position. Disconnect the Transmission Simulator (special tool #8333A, Simulator, Transmission) and the Electronic Transmission Adapter kit. Disconnect the PCM C2 harness connector. Measure the resistance of the (T13) Speed Sensor Ground circuits between the PCM C2 harness connector and the Input and Output Speed Sensor harness connectors and the TRS harness connector. Is the resistance above 5.0 Ohms on any circuit(s)? Yes Repair the (T13) Speed Sensor Ground circuit(s) for an open. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Using the schematics as a guide, check the Powertrain Control Module (PCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for Service Information Tune-ups or Service Bulletins for any possible causes that may apply. If no problems are found, replace and program the PCM in accordance with the Service Information. With the scan tool, perform Quick Learn. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) .
3. CHECK THE WIRING AND CONNECTORS The conditions necessary to set the DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. With the scan tool, check the Event Data to help identify the conditions in which the DTC was set. Were there any problems found? Yes Repair as necessary. Perform the 40TE TRANSMISSION VERIFICATION TEST. Refer to «40/41 TE TRANSMISSION VERIFICATION TEST»(ref-485570-S08458558962012071300000) . No Test Complete.

Continuously with engine running.

If the Engine Temperature exceeds 123° C (255° F) or the Transmission Temperature exceeds 135° C (275° F) while in AutoStick® mode. Note: Aggressive driving or driving in low for extended periods of time will set this DTC.

Always perform the 40TE PRE-DIAGNOSTIC TROUBLESHOOTING procedure before proceeding. Refer to 40/41TE PRE-DIAGNOSTIC TROUBLESHOOTING PROCEDURE .

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Powertrain Control Module (ECM/PCM) for approximately two to five seconds.

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

Continuously when the ignition is on.

The battery voltage between 10.0 and 16.0 Volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.
