Starting System: Specifications Chrysler Voyager IV

TORQUES

STARTER TORQUE SPECIFICATIONS

Scheme 1

Scheme 2

Scheme 3

1. Release hood latch and open hood (Scheme 1)
2. Disconnect and isolate the battery negative cable.
3. Disconnect solenoid wire connector from terminal (Scheme 2)
4. Remove nut holding B+ wire to terminal.
5. Disconnect solenoid and B+ wires from starter terminals.
6. Remove the lower bolt.
7. Remove the upper bolt and ground wire (Scheme 3)
8. Remove starter.

Scheme 4

Scheme 5

Scheme 6

1. Release hood latch and open hood.
2. Disconnect and isolate the battery negative cable.
3. Hoist and support vehicle on safety stands.
4. Remove nut holding B+ terminal to starter solenoid (Scheme 4)
5. Disconnect solenoid connector from starter.
6. Remove bolts holding starter to transaxle bell-housing (Scheme 5)
7. Remove starter from bellhousing (Scheme 6)
8. Separate starter spacer from transaxle bell-housing.
