DESCRIPTION
The starting system has (Scheme 7)
- Ignition switch
- Starter relay
- Transmission Range Sensor or Park/Neutral Switch
- Wiring harness
- Battery
- Starter motor with an integral solenoid
- Powertrain Control Module (PCM)
Scheme 7
OPERATION
These components form two separate circuits. A high amperage circuit that feeds the starter motor up to 300+ amps, and a control circuit that operates on less than 20 amps.
The PCM controls a double start over-ride safety that does not allow the starter to be engaged if the engine is already running.
For circuit descriptions and diagrams, refer to the Wiring Diagrams.
| WARNING | ON VEHICLES EQUIPPED WITH AIRBAGS, REFER TO AIR BAG RESTRAINT SYSTEMS ARTICLE BEFORE ATTEMPTING STEERING WHEEL, STEERING COLUMN, OR INSTRUMENT PANEL COMPONENT DIAGNOSIS OR SERVICE. FAILURE TO TAKE THE PROPER PRECAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT AND POSSIBLE PERSONAL INJURY. |
